Side 1/14

Important: You will need the BlueBOLT-CV1’s unique MAC address and challenge key (provided on the 2 labels

attached to the cover of the Quick Start Guide which is included in the M4315-PRO packaging). One label is

permanently adhered to the Quick Start Guide and the other is removable for your convenience.

1 2 3 4 5 6 7 8

UNSAFE VOLTAGE

BREAKER

WIRING FAULT

TEMPERATURE

15 A

BRIGHTNESS

OUTLET STATUS

REBOOT 1 REBOOT 2

M4315-PRO

BLT

Blue

™

EN AB LED

VOLTS

Power Management with Control System Interactive Functionality.

• 15 Amp Capacity M4315-PRO

• 8 Individually Controllable Rear Panel Outlets

• Fully Programmable

• TCP/IP (BlueBOLT™) Installed

• RS-232 Card (Included, not installed)

• Linear Filtration with 3 Isolated LiFT Filter Banks, 76db (5 kHz - 250 kHz), 46 db (250 kHz - 1 MHz)

• One Isolated Filter Bank for High Current Devices, 60db (5 kHz - 450 kHz), 46 db (450 kHz - 1 MHz)

• Front Panel Circuit Breaker

• Integrated Front Rack Ears

• 12 Volt Input Triggering

• Detachable 10 ft. Power Cord

• AVM & Protect-or-Disconnect Circuitry

M4315-PRO Instructions

INS00859 REV. D 5/10

BLT

Blue

™



ENABLED

Thank you for purchasing a Panamax M4315-PRO Power Management with control system interactive functionality, and congratulations on your choice.

The M4315-PRO features Panamax’s revolutionary AVM (Automatic Voltage Monitoring) circuit, and our exclusive Linear Filtering Technology (LiFT). To-

gether, these technologies comprise precisely what our customers have come to expect from Panamax: uncompromised AC protection and puriﬁcation.

Outlets: all rear panel outlets are separately controlled. They are grouped into four (4) ﬁlter-isolated banks. BlueBOLT™ is included, providing secure,

hosted IP system control and monitoring for the M4315-PRO.

Introduction

1 2 3 4 5 6 7 8

UNSAFE VOLTAGE

BREAKER

WIRING FAULT

TEMP ERATUR E

15 A

BRIGHTNESS

OUTLET STATUS

REBOOT 1 REBOOT 2

M4315-PRO

BLT

Blue

™

ENABLED

VOLTS

RS232

Table of Contents

Feature Descriptions....................................................................................................................................................................................... ..pg. 1

Important Safety Instructions, Front Panel Features Overview..............................................................................................................................pg. 2

Preset Proﬁle Information.................................................................................................................................................................................pg. 3

Rear Panel Features Overview, Bubble of Protection.......................................................................................................................................... pg. 4

BlueBOLT™ Setup, Registration, Trouble Shooting.............................................................................................................................................pg. 5

Diagram to Identify Connected Equipment, Additional Notes................................................................................................................................pg. 6

RS-232 Installation, RS-232 and Telnet Command Set / Protocol Speciﬁcations.............................................................................................pgs. 7, 8, 9, 10, 11

Product Speciﬁcations, FCC Notice, Contacting Customer Service..........................................................................................................................pg. 12

Box should contain the following, including the Quick Start Guide:

Before You Begin Inspect Upon Receipt.

1. M4315-PRO
