Important: You will need the SM3-PRO’s unique MAC Address and Challenge Key (provided on the 2 labels

attached to the cover of the Quick Start Guide which is included in the SM3-PRO packaging). One label is

permanently adhered to the Quick Start Guide and the other is removable for your convenience.

10005610-A 2/19/15

BANK 1

ETHERNET 1

SM3-PRO SYSTEM MANAGER

ETHERNET 2

BANK 2

UNSAFE

VOLTAGE

WIRING

FAULT

BlueBOLT ACC 1 ACC 2

RESET

Power Management with Remote Cloud-based Control and Monitoring.

• 15 Amp Capacity

• 3 Rear Panel Outlets in 2 Controllable and Monitored banks

• Fully Programmable

• Enabled

• AVM & Protect-or-Disconnect Circuitry

• 2-Port 10/100 Ethernet Switch

• Linear Filtration,-18.7dB@10kHz, -50.5dB@100kHz, -43.9dB@1MHz

• Accessory Inputs for External Sensors

• Rear Panel Circuit Breaker

• Universal Mounting Bracket Included

• Detachable 2 ft. Power Cord

SM3-PRO Instructions

Congratulations for purchasing the Panamax SM3-PRO Power Management with remote, cloud based control and monitoring. The SM3-PRO features

Panamax’s revolutionary AVM (Automatic Voltage Monitoring) circuit, and our exclusive Linear Filtering Technology (LiFT). Together, these technologies

comprise precisely what our customers have come to expect from Panamax: uncompromised AC protection and puriﬁcation.

Outlets: Rear panel outlets are controlled in two power ﬁltered banks. They are grouped into two (2) switched banks. BlueBOLT® is included, providing

secure, hosted IP system control and monitoring for the SM3-PRO.

Introduction

BANK 1

ETH ERNET 1

SM3-PRO SYSTEM MANAGER

ETH ERNET 2

BANK 2

UNSAFE

VOLT AGE

WIRING

FAULT

BlueBOLT ACC 1 ACC 2

RESET

Feature Descriptions......................................................................................................................................................................................... pg. 1

Important Safety Instructions, Front Panel Features Overview.............................................................................................................................. pg. 2

Rear Panel Features Overview, Bubble of Protection.......................................................................................................................................... pg. 3

BlueBOLT® Setup, Registration, Trouble Shooting............................................................................................................................................. pg. 4

Outlet Sequencing and SM3-PRO Speciﬁcations................................................................................................................................................... pg. 5

Diagram to Identify Connected Equipment, Additional Notes...............................................................................................................................pg. 6

Advanced Operation, Communication and Messaging Protocol .......................................................................................................................pgs. 7- 13

FCC Notice, Contacting Customer Service.......................................................................................................................................................... pg. 13

Limited Product Warranty and Connected Equipment Policy............................................................................................................................. pg. 14

Box should contain the following, including the Quick Start Guide:

Before You Begin Inspect Upon Receipt.

1. SM3-PRO 3. Universal

Mounting

Bracket

Panamax, 1800 S. McDowell Blvd., Petaluma, CA 94954 • www.panamax.com • 800-472-5555 • 707-283-5900 • Fax 707-283-5901
