For Technical Support: www.panduit.com/resources/install_maintain.asp

INSTALLATION INSTRUCTIONS

FS119A

LC Fiber Optic Connectors

Field Polish Termination - Singlemode and Multimode

ITEM PART NUMBER DE CRIPTIONS

1 CST-115 Fiber C ble Ja acket tripperS

2 FALC Alcohol Bottle (empty)

3 S u SFBF P Fiber B ffer tripper

4 FLPT LC Crimp Tool

5 FS a SCRIBE C rbide cribe

6 FGLS Safety Gl eass s

7 FLCPK LC Poli hing P ck (1.25mm Ferr le)s u u

8FJPMR Primer

9 a sFJPXY An erobic Adhe ive

FH CT (or)S

FH CT-WS

He t hrink C ring Tool (110VAC / 60Hz for 1.6mm/2.0mm in t ll tion)a S u s a a

He t hrink C ring Tool (2 0VAC / 50Hz for 1.6mm/2.0mm in t ll tion)a S u 3 s a a

11 FK ArS amid Yarn S a she r

12 FPP5-L 5µm Poli hing Film (Als u

min m Oxide)u

1 FPF1-V 1µm Di mond Poli hing Film3 a s

14 FLCPAD 5 D rometer Poli hing P8 u s ad

15 F CDVR crewdriverS S

16 F COPE 200x Micro copeS s

17 FLCA CP 1.25mm Ad pter for F COPES a S

1 F TY fety for fiber cr8 S Sa Stickers s a sp

1 F WB-C Cle ning w b9 S a S a s

20 F YR-X yringe with needle tipS S s s

21 FTWZR Tweezers

22 FWP-C Cloth Wipes

2 PFX-0 Indelible Ink M rking Pen3 a

24 FLOUPEX10 Eye Lo pe 10X Poweru

25 -- I opropyl Alcohol (Re gent Grs a a 9 ude, 0% minim m concentration; not av ila

able from Pa und it)

26 FLCFPLF-X .05µm L pping Film (For inglemode termin tion only) a s a s

27 FWBTL Distilled Water Bottle (empty)

-- -- Distilled Wa ater (not va ail ble from Pa und it)

OPTIONAL PN 5* LC Connector 33 Stripping Template

DUPLEX

Duplex Clip

CONNECTOR ASSEMBLY

ITEMS REQUIRED FOR TERMINATION

SIMPLEX

Dust cap

Connector Body

Backbone

Crimp Sleeve

900µm Boot

Jacketed Boot

with heat shrink

tubing

READ ALL INSTRUCTIONS COMPLETELY BEFORE PROCEEDING

Page 1 of 11

COMPONENT IDENTIFICATION

* denotes stripping template revision letter.

For Technical Support: www.panduit.com/resources/install_maintain.asp

INSTALLATION INSTRUCTIONS

FS119A

TABLE OF CONTENTS Page(s)

Safety Precautions 2

900µm Tight-Buffered Fiber Termination 3-6

1.6mm - 2.0mm Jacketed Ca le Termination 7-11b

1. SAFETY GLASSES

WARNING: IT IS STRONGLY RECOMMENDED THAT SAFETY GLASSES BE

WORN WHEN HANDLING BARE OPTICAL FIBER. THE BARE FIBER IS VERY

SHARP AND CAN EASILY DAMAGE THE EYE.

2. ISOPROPYL ALCOHOL

WARNING: ISOPROPYL ALCOHOL IS FLAMMABLE. CONTACT WITH THE

ALCOHOL CAN CAUSE IRRITATION TO THE EYES. IN CASE OF CONTACT

WITH THE EYES, FLUSH WITH WATER FOR AT LEAST 15 MINUTES. ALWAYS

USE ISOPROPYL ALCOHOL WITH PROPER LEVELS OF VENTILATION. IN

CASE OF INGESTION, CONSULT A PHYSICIAN IMMEDIATELY.

3. RECOMMENDED ADHESIVE AND PRIMER

WARNING: THE RECOMMENDED ADHESIVE (PANDUIT PART# FJPXY) MAY

CONTAIN MALEIC ACID AND METHACRYLIC ESTER. IN CASE OF EYE

CONTACT, FLUSH WITH WATER FOR 15 MINUTES AND GET MEDICAL

ATTENTION. WASH SKIN AFTER CONTACT. REQUEST M.S.D.S. FOR

FURTHER SAFEGUARDS. CHECK “USED BY” DATE ON BOTTLE TO ENSURE

BEST PERFORMANCE.

WARNING: THE RECOMMENDED PRIMER (PANDUIT PART# FJPMR) MAY

CONTAIN ACETONE. THE PRIMER IS HARMFUL IF INHALED OR

SWALLOWED. IN CASE OF CONTACT WITH EYES OR SKIN, FLUSH WITH

WATER. GET MEDICAL ATTENTION IN CASE OF INGESTION OR CONTACT

WITH EYES. DO NOT INDUCE VOMITING. CHECK “USED BY” DATE ON

BOTTLE TO ENSURE BEST PERFORMANCE.

4. DISPOSAL OF BARE FIBERS

WARNING: PICK UP AND DISCARD ALL PIECES OF BARE FIBER WITH

STICKY TABS. DO NOT LET CUT PIECES OF FIBER STICK TO CLOTHING OR

DROP IN THE WORK AREA WHERE THEY ARE HARD TO SEE AND CAN

CAUSE INJURY.

5. LASER LIGHT PROTECTION

WARNING: LASER LIGHT IS INVISIBLE. THE INVISIBLE LIGHT IS POWERFUL

ENOUGH TO DAMAGE YOUR EYES. SERIOUS DAMAGE TO THE RETINA OF

THE EYE IS POSSIBLE. NEVER LOOK INTO THE END OF A FIBER WHICH MAY

HAVE A LASER COUPLED TO IT. SHOULD ACCIDENTAL EYE EXPOSURE TO

LASER LIGHT BE SUSPECTED, ARRANGE FOR AN EYE EXAMINATION

IMMEDIATELY.

6. CABLE HANDLING

WARNING: FIBER OPTIC CABLE CAN BE DAMAGED BY EXCESSIVE

PULLING, TWISTING, CRUSHING OR BENDING STRESSES. CONSULT THE

APPROPRIATE SPECIFICATION SHEETS AS PROVIDED BY YOUR CABLE

VENDOR. ANY DAMAGE MAY DECREASE OPTICAL PERFORMANCE.

CLASS II LASER

Page 2 of 11

SAFETY PRECAUTIONS
