Pioneer PRS-D1200M Manual

Pioneer Modtager PRS-D1200M

Læs gratis den danske manual til Pioneer PRS-D1200M (68 sider) i kategorien Modtager. Denne vejledning er vurderet som hjælpsom af 28 personer og har en gennemsnitlig bedømmelse på 4.8 stjerner ud af 14.5 anmeldelser. Har du et spørgsmål om Pioneer PRS-D1200M, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/68

ENGLISH ESPAÑOL

PORTUGUÊS (B)

CLASS D MONO AMPLIFIER

Owner’s Manual

PRS-D1200M

WOÐdF«

Before Using This Product ...................... 1

Visit our website ................................................ 1

In case of trouble .............................................. 2

About This Product ............................................ 2

CAUTION ........................................................ 2

WARNING ........................................................2

Setting the Unit .......................................... 3

Power Indicator ................................................ 3

Top Cover .......................................................... 3

Subsonic Select Switch .................................... 3

Bass Boost Control ............................................ 3

BFC (Beat Frequency Control) Switch ............ 3

MODE SELECT Switch .................................. 4

Gain Control ...................................................... 4

Cut Off Frequency Control for LPF .................. 4

Input Switch ...................................................... 4

POWER MODE Switch .................................... 4

Setting the Gain properly ....................................5

Connecting the Unit .................................. 6

Connection Diagram ........................................ 7

Solderless Terminal Connections........................8

Connecting the Power Terminal ........................ 8

Connecting the Speaker Output Terminals ...... 9

Using the Speaker Input .................................... 9

Connecting the Speaker Wires ........................ 10

Installation ................................................ 14

Attaching the Bass boost remote control ..........15

Example of installation on the floor mat

or on the chassis ...................................... 15

Replacing the top cover .................................. 15

Specifications .......................................... 16

Visit our website

Visit us at the following site:

http://pioneer.jp/group/index-e.html

• We offer the latest information about

Pioneer Corporation on our website.

Contents Before Using This Product

Produkt Specifikationer

Mærke:	Pioneer
Kategori:	Modtager
Model:	PRS-D1200M
Vægt:	2800 g
Dimensioner (BxDxH):	304 x 195 x 56 mm
Frekvensområde:	10 - 240 Hz
Impedens:	4 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Udgangseffekt:	600 W
Antal kanaler:	1 kanaler
Signal/støjforhold:	92 dB
Linie ud:	Ja
Line-in:	Ja
Udgangseffekt (DIN):	600
Maksimalt indgangsniveau:	6.5 V
