Extended Holding Bin

General Market Series

Operation

Manual

Extended Holding Bin

General Market Series

LIMITED WARRANTY

This product is warranted to be free from defects in material and/or workmanship for

a period of one year from date of original installation (with the exception of racks,

pans, and covers). Any component which proves to be faulty in material and/or

workmanship will be replaced or repaired (at the option of Prince Castle, Inc.) with-

out cost to the customer for parts or labor. This warranty covers on location service

(i.e. trip charges and/or mileage). Travel mileage is limited to 100 miles (200 kilome-

ters -International) round trip (one trip warranty) from an authorized service agency

or its sub-service agency.

This warranty is subject to the following exceptions/conditions:

• Use of any non-genuine Prince Castle parts voids this warranty.

• All labor shall be performed during regular work hours. Overtime premium will

be charged to the buyer.

• Damage caused by carelessness, neglect, and/or abuse (e.g., dropping, tam-

pering or altering parts, equipment damaged in shipment, by fire, flood or an

act of God) is not covered under this warranty.

355 EAST KEHOE BLVD. ~ CAROL STREAM, IL, 60188, USA

PHONE: 630-462-8800 ~ TOLL FREE: 1-800-PCASTLE

FAX 630-462-1460 ~ WWW.PRINCECASTLE.COM

TABLE OF CONTENTS

Model Identification…………………………………………………… 2

Model Specifications…………………………………………………. 2

Safety Information……………………………………………………. 2

Configurations………………………………………………………... 3

Product Identification………………………………………………… 4

Installation…………………………………………………………….. 4

Operation……………………………………………………………… 5

Setting Product Location……………………………………………. 6

Cleaning………………………………………………………………. 6

Setting the Temperature……………………………………………. 7

Calibrating the Heaters……………………………………………... 8

Changing the Hold and Cook More Times……………………….. 9

Changing Product Names………………………………………….. 10

Changing Temperature Scale……………………………………… 11

Adjusting Alarm Volume……………………………………………. 11

Choosing a Language………………………………………………. 12

Default Menu………………………………………………………… 13

Zone Layouts………………………………………………………... 14

Dayparts……………………………………………………………... 15

Troubleshooting……………………………………………………... 16

Diagnostics…………………………………………………………… 17

Wiring Diagrams……………………………………………………... 18

Exploded Views……………………………………………………... 20

ATTENTION: Read the instructions before using the machine.

Extended Holding Bin

General Market Series

STYLE MODEL NO. WIDTH (mm) HEIGHT (mm) DEPTH (mm) WEIGHT (kgs) VOLTAGE AMPS___

2H X 2W EHB22R1-GMSXX 19.7 (500) 11.4 (290) 14.1 (358) 35 lbs. (16.0) 110-120 6.5-7.0

2H X 2W EHB22R2-GMSXX 19.7 (500) 11.4 (290) 14.1 (358) 35 lbs. (16.0) 208-240 3.8-4.4

4H X 2W EHB42R1-GMSXX 19.7 (500) 20.6 (523) 14.1 (358) 57 lbs. (26.0) 110-120 13.1-14.0

4H X 2W EHB42R2-GMSXX 19.7 (500) 20.6 (523) 14.1 (358) 57 lbs. (26.0) 208-240 7.7-8.8

2H X 4W EHB24R2-GMSXX 33.2 (843) 11.4 (290) 14.1 (358) 55 lbs. (25.0) 208-240 9.0-10.4

3H X 4W EHB34R2-GMSXX 33.2 (843) 18.1 (460) 14.1 (358) 94 lbs. (43.0) 208-240 13.6-15.7

2H X 3W EHB23R2-GMSXX 27.2 (691) 11.4 (290) 14.1 (358) 45 lbs. (20.0) 208-240 13.6-15.7

NOTE: All Model Numbers above with “R” are for double-sided units (with auxiliary timer bars).

If unit above has “R” in part number, it can be substituted for an “F” to get the single-sided version.

NOTE: Weight (kgs) is shipping weight.

NOTE: See kits starting on Page 20 for power cord type.

NOTE: 110-120V SKUs are indicated with an “R1” or “F1” for use in US/CANADA. 208-240V SKUs indicated by “R2” or “F2”.

Model Identification

Model Specifications

Safety Information

WARNING

Indicates information important to the proper operation of the unit.

Failure to observe may result in damage to the equipment and/or

severe bodily injury or death.

CAUTION

Indicates information important to the operation of the unit.

Failure to observe may result in damage to the equipment.

Important

Prince Castle reserves the right to change specifications and

product design without notice. Such revisions do not entitle

the buyer to corresponding changes, improvements,

additions or replacements for previously purchased

equipment.

EHB24R2-GMS16

Unit Name

Number of

Pans per

Shelf

Three Leer

Customer Code

Indicates Power Cord

Type

“R” for Front and

Rear Timer Bars,

“F” for Front

Only

“2” for 220V

Version, “1”

for 120V

Version

Number of

Shelves

Produkt Specifikationer

Mærke:	Prince Castle
Kategori:	Ikke kategoriseret
Model:	EHB24R2-GMS16
