Side 1/22

CD5.241, CD5.241-S1

CD–Series

DC/DC Converter; 24V, 5A

Jan. 08 / Rev. 1.1 DS-CD5.241-EN / All parameters are specified at 24V, 5A and 24Vdc input at 25°C ambient unless otherwise noted.

www.pulspower.com Phone +49 89 9278 0 Germany

1/22

DC/DC CONVERTER

■ Wide Range DC Input (18-32.4Vdc)

■ Isolated 24Vdc Output

■ Efficiency up to 90.3%

■ Width only 32mm

■ 20% Output Power Reserves

■ Full Output Power Between -25°C and +60°C

■ Soft Start Function Included

■ Minimal Inrush Current Surge

■ Reverse Input Polarity Protection

■ DC-OK and Input-low Relay Contact (CD5.241-S1)

■ 3 Year Warranty

1. GENERAL DESCRIPTION

2. SHORT-FORM DATA

Output voltage DC 24V

Adjustment range 23 - 28V

Output current

5 – 4.3A

Ambient <60°C

6 – 5.1A

Ambient <45°C

Output power 120W Ambient <60°C

144W Ambient <45°C

Output ripple < 50mVpp 20Hz to 20MHz

Input voltage DC 24V 18 to 32.4Vdc

(14 to 18Vdc

with derating)

Input current typ. 5.5A At 24Vdc input

Input Inrush current typ. 1.2A peak

Efficiency typ. 90.3% At 24Vdc input

Losses typ. 12.9W At 24Vdc input

Hold-up time typ. 6ms At 24Vdc input

Temperature range -25°C to +70°C Operational

Derating 3W/°C +60 to +70°C

Dimensions 32x124x102mm WxHxD

The Dimension CD5-series offer DIN-rail DC/DC

converters in the 120W output power range in a very

compact housing.

These DC/DC converters are allowed to run from a

battery, can also be used to refresh and stabilize the

24Vdc on the end of a long cable or to isolate

specific loads from the 24V bus voltage.

The CD5.241 includes all the essential basic functions

while the CD5.241-S1 is equipped with quick-connect

spring clamp terminals, a DC-OK-contact which

monitors the output and an input-low-relay-contact.

Both devices have a power reserve of 20% and this

extra power can be used continuously up to +45°C.

CD5.241

CD5.121

CD5.242

CD5.241-S1

Spring-clamp

terminals,

Input-low,

DC-OK

contacts

CD-Series

Related products

24V->24V

24V->12V

48V->24V

3. ORDER NUMBERS

4. MARKINGS

DC/DC

Converter

CD5.241

Standard unit

CD5.241-S1

Unit with signals and

spring-clamp terminals

Accessories ZM1.WALL Wall mount bracket

IND. CONT. EQ.

18WM

LISTED

UL 508

UL 60950-1

Class I Div 2,

pending

ZM11.SIDE Side mount bracket

YRM2.DIODE Redundancy module

YR2.DIODE Decoupling module

182790

CUS

pending

Marine, pending

EMC, LVD

CD5.241, CD5.241-S1

CD–Series

DC/DC Converter; 24V, 5A

Jan. 08 / Rev. 1.1 DS-CD5.241-EN / All parameters are specified at 24V, 5A and 24Vdc input at 25°C ambient unless otherwise noted.

www.pulspower.com Phone +49 89 9278 0 Germany

2/22

INDEX PAGE

General Description ............................................1

2. Short-form Data ..................................................1

3. Order Numbers....................................................1

4. Markings..............................................................1

5. Input Voltage ......................................................3

6. Soft-start and Input Inrush Current Surge .........4

7. Output .................................................................5

8. Hold-up Time.......................................................6

9. Efficiency and Power Losses................................7

10. Functional Diagram.............................................8

11. Reliability.............................................................8

12. Front Side and User Elements.............................9

13. Terminals and Wiring..........................................9

14. DC-OK Relay Contact (CD5.241-S1) ..................10

15. Input-low Relay Contact (CD5.241-S1) .............10

16. EMC....................................................................11

17. Environment ......................................................12

18. Protection Features ...........................................12

19. Safety .................................................................13

20. Dielectric Strength ............................................13

21. Approvals...........................................................14

22. Fulfilled Standards............................................ 14

23. Used Substances ............................................... 14

24. Physical Dimensions and Weight..................... 15

25. Installation and Operation Instructions .......... 15

26. Accessory........................................................... 16

27. Application Notes............................................. 17

27.1. Peak Current Capability ......................... 17

27.2. Back-feeding Loads ................................ 17

27.3. Inductive and Capacitive Loads ............. 17

27.4. Output Circuit Breakers ......................... 18

27.5. Series Operation..................................... 19

27.6. Parallel Use to Increase Output Power . 19

27.7. Daisy Chaining of Outputs..................... 19

27.8. Parallel Use for 1+1 Redundancy........... 20

27.9. Charging of Batteries............................. 20

27.10. Requirements for the Supplying Source 21

27.11. External Input Protection....................... 21

27.12. Use in a Tightly Sealed Enclosure .......... 21

27.13. Mounting Orientations.......................... 22

INTENDED USE

The DC/DC converter shall only be installed and put into operation by qualified personnel.

This DC/DC converter is designed for installation in an enclosure and is intended for the general use, such as in

industrial control, office, communication, and instrumentation equipment. Do not use this device in aircraft, trains

and nuclear equipment, where malfunctioning of the DC/DC converter may cause severe personal injury or threaten

human life.

TERMINOLOGY AND ABREVIATIONS

PE and symbol PE is the abbreviation for Protective Earth and has the same meaning as the symbol .

Earth, Ground This document uses the term “earth” which is the same as the U.S. term “ground”.

T.b.d. To be defined, value or description will follow later.

DC 24V A figure displayed with the AC or DC before the value represents a nominal voltage with

standard tolerances included.

E.g.: DC 12V describes a 12V battery regardless whether it is full (13.7V) or flat (10V)

24Vac A figure with the unit (Vdc) at the end is a momentary figure without any additional

tolerances included.

DISCLAIMER

The information presented in this document is believed to be accurate and reliable and may change without notice.

Some parts of this unit are patent by PULS (US patent No 091662,063, Des. 424,529, …).

No part of this document may be reproduced or utilized in any form without permission in writing from PULS GmbH.
