Acoustic Design Series

Quick Start Guide

AD-S.SUB

AD-S.SAT

TD-001547-01-A

*TD-001547-01*

EXPLANATION OF SYMBOLS

The term “WARNING” indicates instructions regarding personal safety. Failure to follow them may result in bodily injury or death.

The term indicates instructions regarding possible damage to physical equipment. Failure to follow them may result in equipment damage “CAUTION”

to equipment that may not be covered under the warranty.

The term “IMPORTANT” indicates instructions or information that are vital to the successful completion of theprocedure.

The term “NOTE” indicates additional useful information.

The lightning ﬂash with arrowhead symbol in a triangle alerts the user to the presence of uninsulated dangerous voltage within the product’s

enclosure that may constitute a risk of electric shock to humans.

The exclamation point within a triangle alerts the user to important safety, operating, and maintenance instructions in this manual.

1. Read these instructions and keep a copy for future reference.

2. Strictly follow and heed all instructions and warnings.

3. Consult a licensed and qualiﬁed professional engineer to devise and/or review an appropriate mounting scheme.

4. Do not use or submerge this loudspeaker product in or near water or liquids.

5. Clean only with a dry cloth. Do not use any aerosol spray, cleaner, disinfectant or fumigant on, near, or into the loudspeaker product.

6. Do not block any ventilation opening. Install in accordance with the manufacturer’s instructions.

7. Do not install the loudspeaker near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers).

8. Do not use any attachments, accessories, mounts, or brackets that are not speciﬁed or approved by QSC, LLC.

9. Refer all service to qualiﬁed personnel. Service is required if the hanging mechanism or loudspeaker have been damaged in any way, such as liquid

having been spilled or objects have fallen into the loudspeaker or the loudspeaker has been exposed to rain or moisture, does not operate normally,

or has been dropped.

10. Observe all applicable local codes.

11. Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.

Maintenance and Repair

Advanced technology—e.g., the use of modern materials and powerful electronics—requires specially adapted maintenance and repair methods. To

avoid subsequent damage to the equipment, personal injury, and/or creation of additional safety hazards, have all maintenance or repair work on the

equipment performed only by a QSC authorized service station or an authorized QSC International Distributor. QSC is not responsible for any injury, harm,

or related damages that arise from any failure of the customer, owner, or user of the equipment to facilitate those repairs.

Warranty

For a copy of the QSC Limited Warranty, visit the QSC website at www.qsc.com

IMPORTANT SAFETY INSTRUCTIONS

TD-001547-01-A 2

Install the AD-S.SUB Subwoofer

What's in the AD-S.SUB Box

1×

AD-S.SUB

1×

Rear

panel

cover

3×

Euro-

style plug

(4-pole)

1×

Wall mount

bracket

5×

Fasteners

4×

Adhesive

rubber feet

Warranty

TD-000453

Quick Start

Guide

TD-001547

TOP

Yes

–Figure 1–

Mount the Subwoofer

Horizontal surface

Before you place the subwoofer on a shelf, ﬂoor, or other horizontal

surface, attach the four adhesive rubber feet onto the bottom side of the

subwoofer enclosure at the corners. If you place the subwoofer on a shelf

or other raised surface, make sure it cannot "walk" off the edge because

of vibration.

Vertical surface (e.g., a wall)

Note that the wall mount bracket can be attached to the subwoofer

enclosure in several ways, allowing you to orient the ports and the

connections as desired. The bracket has two parts; Figure 1 depicts the

one that attaches to the subwoofer enclosure.

1. Remove the plugs from four of the mounting holes in the enclosure

and attach the bracket securely using four of the fasteners provided.

Whichever way you choose to orient the subwoofer, make sure the top

of the bracket is near the top of it

2. Use the template (Figure 2) on the next page to locate and mark the

six attachment points for the other part of the bracket. Use anchoring

fasteners that are appropriate for the surface. Make sure that the

surface and the fasteners can support the weight of the subwoofer

(AD-S.SUB: 10.7 kg; 23.5 lb) plus a 5× or higher safety factor (some

jurisdictions may require higher safety factors).

3. Attach the bracket to the wall or vertical surface.

4. Lower the subwoofer enclosure onto the wall bracket. Use the

remaining fastener, inserted into the top of the brackets, to secure the

bracket parts together.
