Side 1/40

AcousticPerformance (AP)

User Guide

AP-5102 — 10" Two-way Trapezoidal Loudspeaker with 105˚axisymmetric coverage

AP-5122 — 12" Two-way Trapezoidal Loudspeaker with 90˚axisymmetric coverage

AP-5152 — 15" Two-way Trapezoidal Loudspeaker with 75˚axisymmetric coverage

AP-5122m — 12" Two-way Multi-purpose Loudspeaker with 90˚axisymmetric coverage

*TD-000369-00*

TD-000369-00-B

EXPLANATION OF SYMBOLS

The term “WARNING!” indicates instructions regarding personal safety. If the instructions are not followed the result may be bodily injury or death.

The term “ ” indicates instructions regarding possible damage to physical equipment. If these instructions are not followed, it may result in CAUTION!

damage to the equipment that may not be covered under the warranty.

The term “IMPORTANT!” indicates instructions or information that are vital to the successful completion of the procedure.

The term " " is used to indicate additional useful information.NOTE

The intent of the lightning ﬂ ash with arrowhead symbol in a triangle is to alert the user to the presence of un-insulated "dangerous"

voltage within the product's enclosure that may be of sufﬁ cient magnitude to constitute a risk of electric shock to humans.

The intent of the exclamation point within a triangle is to alert the user to the presence of important safety, and operating and

maintenance instructions in this manual.

IMPORTANT SAFETY INSTRUCTIONS

WARNING!:

While it is possible for one person to lift a loudspeaker, it is important to use proper lifting techniques. Suggested

reading: OSHA Technical Manual on Back Disorders and Injuries

(http://www.osha.gov/dts/osta/otm/otm_vii/otm_vii_1.html#app_vii:1_2).

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with a dry cloth.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁ ers) that produce heat.

• Only use attachments/accessories speciﬁ ed by the manufacturer.

• Refer all servicing to qualiﬁ ed service personnel.

• Adhere to all applicable, local codes.

• Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.

ENG

TD-000369-00-B

Warranty (USA only; other countries, see your dealer or distributor)

QSC Audio Products 3 Year Limited Warranty

QSC Audio Products, LLC (”QSC”) guarantees its products to be free from defective material and/or workmanship and will replace defective parts

and repair malfunctioning products under this warranty when the defect occurs under normal installation and use, provided the unit is returned to

our factory, one of our authorized service stations or an authorized QSC International Distributor via pre-paid transportation with a copy of proof

of purchase (i.e., sales receipt). This warranty provides that the examination of the return product must indicate, in our judgment, a manufacturing

defect. This warranty does not extend to any product which has been subjected to misuse, neglect, accident, improper installation, or where the

date code has been removed or defaced. QSC shall not be liable for incidental and/or consequential damages. This warranty gives you speciﬁ c legal

rights. This limited warranty is freely transferable during the term of the warranty period. The warranty on QSC products is NOT VALID if the products

have been purchased from an unauthorized dealer/online e-tailer, or if the original factory serial number has been removed, defaced, or replaced in

any way. Damage to, or loss of any software or data residing on the product is not covered. When providing repair or replacement service, QSC will

use reasonable efforts to reinstall the product’s original software conﬁ guration and subsequent update releases, but will not provide any recovery or

transfer of software or data contained on the serviced unit not originally included in the product.

Customers may have additional rights, which vary from state to state or from country to country. In the event that a provision of this limited warranty is

void, prohibited or superseded by local laws, the remaining provisions shall remain in effect.

The QSC limited warranty is valid for a period of three (3) years from date of purchase in the United States and many (but not all)

other countries.

For QSC warranty information in countries other than the United States, contact your authorized QSC international distributor. A list of QSC

International distributors is available at www.qscaudio.com.

To register your QSC product online, go to www.qscaudio.com and select ”Product Registration”. Other questions regarding this warranty can be

answered by calling, e-mailing or contacting your authorized QSC distributor.

Phone: 1-800-854-4079 within US and Canada, +1-714-754-6175 international, warranty@qscaudio.com, Email: Website: www.qscaudio.com.

Installing the AcousticPerformance Loudspeakers

Suspending the AP Loudspeakers

WARNING!:

Read and follow these instructions carefully. If the loudspeakers are not suspended properly, they could fall,

causing personal injury and damage to the equipment.

Rules for Suspension

• Consult a Professional Mechanical or Structural Engineer, licensed in the jurisdiction of the sound system installation, to review, verify, and approve

all attachments to the building or structure.

• Employ the services of a Professional Rigger for hoisting, positioning, and attaching the equipment to the supporting structure.

• Correct use of all suspension hardware and components is imperative in sound system suspension and deployment.

• Always calculate suspended loads before lifting to make sure suspension components and hardware are used within their respective load limits.

• Consult local codes and regulations to fully understand the requirements for suspended loads in the venue in which you will suspend

the equipment.

• Use only the recommended yoke or the M10 installation points with the M10 installation kit for suspending the loudspeaker.

• Be absolutely certain of the integrity of any structural member intended to support suspended loads. Hidden structural members can have hidden

structural weakness.

• Never assume anything! Owner or third-party supplied suspension attachment points may not be adequate for suspending the loads.

• Before lifting, always inspect all components (enclosures, suspension brackets, pins, frames, bolts, nuts, slings, shackles, etc.) for cracks, wear,

deformation, corrosion, missing, loose, or damaged parts that could reduce the strength of the assembly. Discard any worn, defective, or suspect

parts and replace them with new appropriately load-rated parts.
