Developed specifically for the unique
requirements of professional motion
picture playback, the SC-222X extends
QSC’s commitment to the cinema market.
As a member of the DCS Digital Cinema
Speaker Series, the SC-222X is a passive,
2-way screen channel loudspeaker
system comprised of two main units—the
HF-75CX2 high-frequency system and the
LF-2215 low-frequency system.
The HF-75CX2 high-frequency system
features a 3” (75mm) titanium diaphragm
compression driver mounted on a
custom designed high-frequency cinema
horn with an adjustable pan and tilt
bracket. The HF-75CX2 includes a driver
protection and equalization network. DC
blocking capacitors protect against DC
or low-frequency signals that would likely
destroy an unprotected driver. Power
limiter circuitry protects the driver from
overpowering and a response correction
filter smooths the frequency response of
the horn/driver combination. The driver
and equalization network provides for
more reliable operation, ensuring the
show will go on. LF-2215 dual 15” (381
mm) low-frequency enclosure is designed
specifically to address the extended low-
frequency response required for cinema
applications.
LF-2215 covers the frequency range from
37 Hz to 1000 Hz, depending upon the
high-frequency system requirements.
Close Coupled Woofers (CCW), with their
tight spacing between woofers, improves
coupling and keeps coverage angles wide
over a greater frequency range than more
widely spaced designs.
The SC-222X is designed for ease of
installation. The HF-75CX2 components
come pre-assembled to reduce field
assembly time. Three bolts are all that are
required to secure the HF-75CX2 to the
top of the LF-2215 enclosure.
Features
• Passive, 2-way, screen
channel system
• HF-75CX2 provides 90°
horizontal by +20° to -35°
vertical coverage
• LF-2215 is constructed of
MDF and features single
woofer chambers
• Low-distortion waveguide
provides highly articulate
dialogue
• Shallow depth (20”) facilitates
installation behind the screen
SC-222X
SC-222X
Cinema Loudspeaker System
1) Maximum input power tested in accordance with IEC 60268-5 recommendations, 50 Hz to 20 kHz band limiting.
Specifications SC-222X
Nominal Coverage 90° horizontal x +20° to -35° vertical
Frequency Range 37 Hz – 16 kHz (-6 dB)
Impedance 4Ω
Sensitivity 1 watt /1 meter, half space 98 dB
Maximum Input Power
1
Maximum Input Power
1
2 hours of 6 dB crest factor pink noise
50 Hz - 20k Hz, AES method
Recommended Amplifier Power
300 W RMS
1200 W RMS maximum
Recommended Processing Subsonic filter below 30 Hz, > 18 dB per octave
LF-2215 HF-75CX2
Connectors Barrier strip screw terminals accept up to #10 AWG stranded wire Barrier strip screw terminals accept up to #10 AWG stranded wire
Transducers Two 15" (381mm) high efficiency, extended bass woofers featuring
3” copper voice coils
1.5” (38mm) exit, 3” titanium diaphragm compression driver
Enclosure Quasi B4 alignment, ported enclosure with fully flared ports,
symmetrical port design constructed of MDF
and heavily braced. Features vandal resistant woofer mounting bolts.
Tilt/Pan Bracket
±10° vertical tilt
±10° horizontal pan
Dimensions (HWD) 35.75” x 30” x 20.3” (908 mm x 762 mm x 516 mm) 16” x 30” x 20” (406 mm x 762 mm x 508 mm)
Weight – Net 172 lb (78 kg) 40 lb (18.4 kg)
System Weight 212 lb (96.4 kg)
Baffle Cut-Out 53”x32”
SC-222X Details
Preliminary Specifications subject to change without notice.
