Side 1/2

1of2

Assembly Instruction Sheet #IS-BCN1716WT

For Style BCN1716WT

6 CORPORATE PARKWAY

GOOSE CREEK SC 29445

www quoizel com

, .

. .

Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700

or visit us on-line at www.quoizel.com

2015 QuoizelInc.

Crossbar Assembly

x 1

STEP 1 Install Crossbar Assembly-

A. Pass the supply wires through the Crossbar

Assembly (A). Attach the Crossbar

Assembly (A) to the Outlet Box with the

head of the Green Ground Screw facing

you. Secure it with Outlet Box Screws (not

included). Tighten until snug.

August2015

STEP 2 Fit Ceiling Canopy to

Crossbar Assembly

eiling canopy of the Socket

Assembly to the

ceiling

Remove mounting balls from the

Crossbar Assembly (A). Fit the

(B) Crossbar

Assembly (A) and secure with

mounting balls. Note: The

should be snug against the

and the mounting balls. If

Not, adjust the length of the nipple

on the Crossbar Assembly (A) by

unscrewing the preassembled hex

nut and lock washer and then

screwing the mounting screws in

ceiling

canopy of the Socket Assembly

(B)

or out of the crossbar until the correct length is achieved. Once the

is secure, remove the

mounting ball and Socket Assembly (B) and proceed to Step 3.

ceiling canopy of the Socket Assembly (B)

Package Contents

Mounting Screw

Hex Nut and

Lock Washer

Mounting Ball

STEP 3 - Wire Connections

A. Use standard wire connectors (not included) to make all wire

connections. (Connectors are not included with fixture.) Twist

connectors until wires are tightly joined together. Wrap each

connection with approved electrical tape and carefully stuff all the

connected wires into the Outlet Box.

White wire

from fixture

Black wire

from fixture

Ground wire

from fixture

White wire

from supply

Black wire from

supply (or Red)

Ground wire

from supply

Supply Wires

with Ground Wire

Outlet Box Screws

(not included)

Outlet

Box

Please go to for product cleaning tips. Go to the selection.

(3) A19 Medium Base 100W Maximum. Alternate Bulbs (3) 23W CFL.

30-45 minutes

Identify and inspect all parts before beginning installation. Check package content list and diagrams below to be sure all parts are

present. If any parts are missing or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer service for replacement

parts.

www.quoizel.com Care + Maintenance

Light Source:

Estimated Assembly Time:

Preparation:

Tools Required: Flathead screwdriver, Phillips screwdriver, pliers, wire cutters, wire strippers, electrical tape, safety glasses.

Warnings and Cautions

Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.

These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly

recommend that a licensed, professional electrician perform the installation.

Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal. Do not subject

glass parts to any shock while in operation or shattering may result.

Socket

Assembly

x 1

Side Arm

x 3

Shade

x 1

Cage

x 1

Figure 1

Figure 2

Figure 3

STEP 4 Install Fixture Body-

A. Carefully tuck all wires into the

outlet box and position the ceiling

canopy of the Socket Assembly

(B) over the outlet box. Align the

holes in the ceiling canopy of the

Socket Assembly (B) with the

mounting screws, then attach the

ceiling canopy using the

previously removed mounting

balls. Hand tighten until snug.

Mounting

Screw

Mounting

Ball

Figure 4

STEP 5 Assemble Shade, Cage and Bulbs-

A. Place the Shade (D) inside of the Cage (E).

B. Attach one ends of Side Arms (C) to Hooks on the side of the Socket

Hook

Bulb

Socket

Assembly (B). Lift the Cage with

Shade upward and attach another

ends of Side Arms (C) to Hooks

on the top edge of the Cage (E).

Carefully release your hands

after all Side Arms (C) are hung

properly.

C. This fixture uses standard bulb

with standard screw base.

Maximum 100 watts. Insert bulb

and screw snugly into place.

Your fixture is now assembled

and ready to use. Enjoy!

Figure 5
