For Style VAN1716OK VAN2816OKand
Installation Guide
Crossbar Assembly
x 1
A
Package Contents
PARTS BAG
Ceiling
Canopy
x 1
D
6”L Rod
x 2
E
12”L Rod
x 2
H
F
Table of
Contents
STEP 1
For angled ceilings,
Swivel opening towards wall.
90 Degree Swive
1 2 3
Step 1
Install crossbar assembly
Step 2 - 3
Test fitting ceiling canopy to
mounting screws
Preparation: Identify and inspect all parts
before beginning the installation.
Missing or damaged parts? Contact your
original place of purchase.
Tools Required
Warnings and Cautions
Turn off the electricity at the circuit breaker
before installation. Consult a licensed
electrician if in doubt about installation.
Turn off power to the fixture and allow the
bulbs to cool before replacing.
Fixture Height
Adjustable14” to 52”
Light Source
BULB BASE TYPE
Candelabra (E12)
BULB SHAPE
TYPE B
60W
MAX
3 BULBS REQUIRED
BULBS NOT INCLUDED
Outlet Box Screw
x 2
B
Wire Connector
x 3
C
Fixture Body
x 1
G
Swivel
x 1
Crossbar Assembly Downrod Wiring Bulb
STEP 1 STEP 2 STEP 4 STEP 6
Ceiling Canopy
STEP 5
Lanyard
STEP 3
2of2
2019 QuoizelInc.
visit us on-line at www.quoizel.com
STEP 2
Optional
Rods
8’ ceiling:
9’ ceiling:
(1) 6”L + (1)
12”L rods
(1) 6”L + (2)
12”L rods
STEP 6
1 2
STEP 5
STEP 4
*Green Ground Screw on crossbar optional
White wire (neutral)
from outlet box White wire
from fixture
Black wire
from fixture
Ground wire
from Fixture
Black or Red wire (hot)
from outlet box
Bare or Green ground wire
from outlet box
OPTION 1 OPTION 2
OPTION 2OPTION 1
3
STEP 3
