Side 1/20
MSP 315
HDMI Extender
USER MANUAL
Article No: RGB-RD-UM-MSP315 E001
Revision No: V1.0
MSP 315 User Manual
1
CONTENTS
CONTENTS....................................................................................................................................... 1
Declarations.......................................................................................................................................2
FCC/Warranty........................................................................................................................... 2
Operators Safety Summary.................................................................................................... 3
Installation Safety Summary...................................................................................................4
Chapter 1 Your Product................................................................................................................... 5
1.1 In the Box............................................................................................................................ 5
1.2 Product Overview.............................................................................................................. 6
1.3 Dimension........................................................................................................................... 7
Chapter 2 Installing Your Product.................................................................................................. 8
2.1 Operation Steps................................................................................................................. 8
Chapter 3 Questions and Troubleshoot........................................................................................ 9
3.1 Power indicator light is off and no respond................................................................... 9
3.2 Peripheral device image has shadows.......................................................................... 9
3.3 Control terminal cannot control the device....................................................................9
3.4 Communication port is out of order................................................................................ 9
Chapter 4 Ordering Codes............................................................................................................10
4.1 Product.............................................................................................................................. 10
Chapter 5 Support ........................................................................................................................ 11
5.1 Contact Us........................................................................................................................ 11
Chapter 6 Appendix....................................................................................................................... 12
6.1 Specification..................................................................................................................... 12
6.2 Terms & Definitions......................................................................................................... 14
6.3 Revision History............................................................................................................... 19
MSP 315 User Manual
3
commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to
influences not agreed upon in the contract, all guarantee claims of the purchaser will be
rendered invalid. Not included in the guarantee coverage are system failures which are
attributed to programs or special electronic circuitry provided by the purchaser, e.g.
interfaces. Normal wear as well as normal maintenance are not subject to the guarantee
provided by RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations
specified in this manual must be complied with by the customer.
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose
dangerous voltages. To avoid personal injury, do not remove the top cover. Do not operate
the unit without the cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230
volts rms between the supply conductors or between both supply conductor and ground. A
protective ground connection by way of grounding conductor in the power cord is essential
for safe operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid
electrical shock, plug the power cord into a properly wired receptacle before connecting to
the product input or output terminals. A protective-ground connection by way of the
grounding conductor in the power cord is essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord
that is in good condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current
rating characteristics. Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
MSP 315 User Manual
4
Installation Safety Summary
Safety Precautions
For all MSP 315 processor installation procedures, please observe the following important
safety and handling rules to avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the
ground wire provided in the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.
Unpacking and Inspection
Before opening MSP 315 processor shipping box, inspect it for damage. If you find any
damage, notify the shipping carrier immediately for all claims adjustments. As you open
the box, compare its contents against the packing slip. If you find any shortages, contact
your sales representative.
Once you have removed all the components from their packaging and checked that all the
listed components are present, visually inspect the system to ensure there was no
damage during shipping. If there is damage, notify the shipping carrier immediately for all
claims adjustments.
Site Preparation
The environment in which you install your MSP 315 should be clean, properly lit, free from
static, and have adequate power, ventilation, and space for all components.
MSP 315 User Manual
5
Chapter 1 Your Product
1.1 In the Box
Power Adapter
Certification
MSP 315 User Manual
6
1.2 Product Overview
MSP 315 Extender for HDMI over one CAT5 / CAT6 consists of a Sender (MSP 315
Tx) and a Receiver (MSP 315 Rx) unit, MSP 315 supports resolution up to 4K x 2K (3840
x 2160 @30Hz) and 1080p Full HD, as well as the pass-through of HDCP and High Bit
Rate (HBR) lossless audio formats such as Dolby® TrueHD and DTS-HD Master
Audio™ .
3D content is supported when a 3D-capable display and 3D source are connected.
DVI-D is also supported when used with HDMI to DVI adapters, providing greater flexibility
and options when integrating several different commercial displays.
This Extender features RGBlink implementation of HDBaseT® Lite technology. Its
uncompressed digital transmission method insures 100% signal integrity. The use of
standard CAT-5e cable makes HDMI signal extension easier to install within a room or
through walls.In addition,the MSP 315 Extender also support bi-directional IR and 12V
POE power supply to make it more easily and convenient.
MSP 315 System Connection Diagram
MSP 315 User Manual
8
Chapter 2 Installing Your Product
2.1 Operation Steps
1. Connect the output of signal sources such as computers to the "HDMI IN" of the MSP
315 HDMI extender TX with HDMI/HDMI-DVI cable;connect the "HDMI OUT" of the MSP
315 HDMI extender RX to display devices such as LED display/LCD/projector, or to video
processers with HDMI/HDMI-DVI cable.
2. Connect the HDBaseT TX output port of MSP 315 HDMI Extender TX to the HDBaseT
RX input port of MSP 315 HDMI Extender RX with single CAT5 or CAT6 cable.
3. MSP 315 Extender provides bidirectional IR control, connecting as needed: one
transmitter connects to the IR receiver, the other transmitter connects to the IR transmitter,
or both the IR receiver and the IR transmitter
4. Connect the RS232 control device to the RS232 interface of any transmitter (either
transmitter or receiver, the data is bidirectional) and the RS232 interface of the controlled
device to the RS232 interface of another transmitter . A 12V 1A adapter is connected to
the 12V power port of the transmitter or receiver, or to the 12V power port of the
transmitter and receiver.
It is recommended to use universal T568B twisted pair with direct twisted pair.
MSP 315 User Manual
9
Chapter 3 Questions and
Troubleshoot
3.1 Power indicator light is off and no
respond
1. Check whether plug in the power cord, and has power supply;
2. Check whether the power cable is connected and in good connection.
3.2 Peripheral device image has shadows
1. Check whether the input/output wires are qualified for HDMI 1.4 standard;
2. Check whether the connection device is correct and in good connection.
3.3 Control terminal cannot control the
device
1. Check whether the connection between control equipment and
communication serial port (distinguish between control and local control);
2. Check whether the communication port is loose or damaged;
3. Check whether the communication protocol settings are as follows: baud
rate: 9600 data bits: 8 stop bits: 1 check bits: none.
3.4 Communication port is out of order
1. Sending equipment to professional personnel for maintenance.
MSP 315 User Manual
10
Chapter 4 Ordering Codes
4.1 Product
611-0315-02-0 MSP 315
MSP 315 User Manual
11
Chapter 5 Support
5.1 Contact Us
