RM82

MIC LINE MIXER

Eight Channel Audio Mixer

Quick Start Guide

ROLLS CORPORATION

SALT LAKE CITY, UTAH

10/10

SPECIFICATIONS

Input Impedance: Mic: 10K Ω XLR balanced

1/4": 20K Ω unbalanced

Bus Input: 10K Ω unbalanced

Max Input Level: Mic: 0 dBV balanced

Line: +6 dBV

Input Connectors: 8: XLR, 8: 1/4" (Line), 1: RCA (Bus input)

Outputs: XLR bal., RCA unbalanced Prefade out

Max Gain: Mic: 55 dB

Line: 26 dB

Tone Control: 12 dB Treble/Bass cut

Phantom Power: +48 VDC

Output Level: +22 dBV max

Output Impedance: 51 Ω

Phase Shift: <10 degrees, 20Hz to 20 kHz

Max S/N ratio: 106 dB

THD: <.01%

CMRR: >52 dB (Mic)

Size: 19" x 1.75" x 6"

(48.3 x 4.5 x 15 cm)

Weight: 7 lbs. (3 kg)

DIP SWITCH DEFAULT SETTING: ALL OFF

JUMPER DEFAULT SETTING: 1/4” JACKS AS INPUT

MAIN OUTPUT AS LINE

OPERATION

CONFIGURING THE 1/4” INPUT JACKS AS DIRECT OUTPUTS

The eight 1/4” Input jacks come from the factory conﬁ gured as line inputs and

are electrically mixed with the XLR jacks. They may be used together if desired.

To conﬁ gure a channel’s 1/4” jack as a Direct Out, ﬁ rst remove the RM82 lid.

For each channel there are dual three-pin headers with shorting jumper on two

pins. The setting from the factory is on “IN”. By moving the shorting jumpers to

the conﬁ guration shown as “OUT” (one jumper up, the other down), the jack then

becomes a Direct Output.

CONFIGURING THE 1/4” INPUT JACKS AS INSERTS

To conﬁ gure a channel’s 1/4” jack as an Insert, ﬁ rst remove the RM82 lid and

locate the corresponding channel’s dual three-pin header. Move both shorting

jumpers down as shown below as “INSRT”, the jack then becomes an Insert.

Direct

Output

Insert Input

CONFIGURING THE OUTPUT FOR MIC OR LINE LEVEL

The RM82 ships from the factory with the XLR Main Output conﬁ gured as Line

Level (+4 dB). To change this to Mic Level (-10 dB), carefully remove the lid,

locate the Mic/Line header which is near the Main Output jack. Move the two

jumpers from the Line Level position (shown below on the right), to the Mic Level

position (shown on the left).

Mic

Level

Line

Level

JUMPER DEFAULTS

The internal jumpers are conﬁ gured from the factory as follows:

1/4” = INPUTS

MAIN OUT LEVEL = LINE LEVEL
