Side 1/6

MX422

Field Mixer

Quick Start Guide

ROLLS CORPORATION

SALT LAKE CITY, UTAH

4/12

POWER

LEFT

OUTPUT

MONITOR

INPUT

RIGHT

OUTPUT

AUX

INPUT

- 30 dB

LINE

phan low cut

1234

trim

INPUT

phan low cut

trim

INPUT

phan low cut

trim

INPUT

phan low cut

trim

INPUT

BATTERY

SELECT

MODEL MX422

SERIAL NUMBER

12 VDC

PUSH PUSH PUSH PUSH

NOTE: THIS MANUAL ASSUMES THE USER HAS A WORKING KNOWLEDGE OF AUDIO ELEC-

TRONICS, BALANCED AND UNBALANCED CONNECTIONS, AND PROPER SIGNAL LEVEL

SETTINGS.

INTRODUCTION

Thank your for your purchase of the Rolls MX422 Field Mixer; Professional ENG mixer.

Please read and review this manual carefully as it contains important information

regarding the proper use and care of the MX422.

INSPECTION

1. Unpack and inspect the MX422 box and package.

If obvious physical damage is noticed, contact the carrier immediately to make a

damage claim. We suggest saving the shipping carton and packing materials for safely

transporting the unit in the future.

2. Please visit our website at www.rolls.com and click on the Register Your Warranty

Here button, or complete the Warranty Registration Card and return it to the factory.

TABLE OF CONTENTS

Introduction 1

Inspection

Table of Contents

Hearing Safety Warnings

Features 2

Speci cations

Quick Start Guide 3

Description

Front Panel 4

Rear Panel 5

Connection 6

Rear Panel Connections

Front Panel Connections

Operation 7

Schematic 10

HEARING SAFETY WARNINGS:

While special attention has been given to your safety and hearing protection, the operator

determines proper and safe operating levels.

Please note the following:

- Always turn down the PHONES level control before plugging in your headphones.

- Always operate your headphones at the lowest practical level.

- Be especially cautious in unknown or widely varying environments.

1www.rolls.com www.rolls.com 10

SCHEMATIC
