MX44 PRO

4-CHANNEL STEREO MIXER

Quick Start Guide

Rolls Corporation

Salt Lake City, UT

4/17

MX44 PRO

4-Channel Stereo Mixer

• Four stereo inputs to one stereo output

• Stereo RCA and 1/8" TRS Stereo high-impedance inputs

• Stereo RCA and 1/8" TRS Stereo high-impedance output

• Battery or AC operation (Rolls PS27s power supply is included)

SPECIFICATIONS

Input Impedance: 10K Ohm

Output Impedance: 100 Ohm

Gain: 30 dB

Connectors: Input: 4 ea.; RCA and 1/8" (3.5mm) unbal.

Output: 1 ea.; RCA and 1/8" (3.5mm) unbal.

Power: 9V battery, or

Rolls PS27s 15VDC adapter (included)

9-15 VDC - 100mA to 500mA

Current Draw: 15mA no load

DC Jack: 2.1X5.5 mm Tip Negative

Signal to noise ratio: 85 dB

Bandwidth: 20 Hz to 30 Khz

Size: 4.5"w x 1.5"h x 4"d

Weight: 1 lb

Four Channel Portable stereo mixer

BATTERY-9V

MX44 PRO

3.5mm

RCA

STEREO OUTPUTS

pwr

POWER

STEREO INPUTS

CH.1 CH.2 CH.3 CH.4

75889 44010

6 2

OPERATION

To connect various devices to the MX44 Pro, you'll need

the proper cables.

- Connecting most CD, Cassete, and Video units will

require a stereo RCA to stereo or 1/8" (3.5mm) cable. A

stereo plug consists of tip, ring and sleeve.

- Most stereo instruments have individual Right and Left

outputs. Therefore, you'll need an "Insert" type cable. This

cable has two 1/4" or 1/8" Tip-Sleeve jacks on one end to

connect to the stereo instrument, and a single Tip-Ring-

Sleeve stereo 1/8" jack on the other end to connect to

the MX44. For assistance on cable selection, contact your

local professional audio dealer.

- Some devices have stereo 1/4" outputs that can be con-

nected to the 1/8" inputs of the MX44. These devices will

require a 1/4" TRS stereo to RCA or 1/8" TRS stereo cable.

- While the MX44 is not a headphone amplier, the out-

puts have sucient level to drive a pair of headphones or

earphones for limited monitoring.

- NOTE: PLUGGING A TIP-SLEEVE MONO PLUG INTO THE

MX44 WILL NOT DAMAGE THE UNIT. HOWEVER, THE

SIGNAL WILL BE HEARD ON ONLY THE LEFT SIDE. DO NOT

PLUG A MONO JACK INTO THE - THIS WILL DAMOUTPUT -

AGE THE UNIT.

TO SEND A MONO SIGNAL TO THE MX44, USE A TRS JACK

WITH THE TIP AND RING CONNECTED TOGETHER.

BATTERY

LIFT TO WITHDRAW

Four Channel Portable stereo mixer

BATTERY-9V

MX44 PRO

3.5mm

RCA

STEREO OUTPUTS

pwr

POWER

STEREO INPUTS

CH.1 CH.2 CH.3 CH.4

INTRODUCTION

Thank you for your purchase of the MX44 Pro 4 Channel Stereo Mixer. This unit

is designed to mix up to four stereo line-level signals such as smart phones,

instruments, CD players, DVD players, MP3 players, laptop computers, etc. to a

single stereo output.

WARRANTY REGISTRATION

For complete warranty information, please visit our website at www.rolls.com

and click on the "Register Your Warranty Here" text, and follow the link and

instructions.

OUTPUTS: 1/4" and 1/8" (3.5 mm)Tip-Ring-Sleeve

jack for connection to a mixer input, amplier or

other input device.

ON/OFF: Latching push button switch for apply-

ing power to the MX44.

9-15 VDC: Power jack - connects to the included

Rolls PS27s 15VDC AC adapter.

BATTERY: Removable compartment for housing

a 9 volt alkaline battery.

pwr: LED - Indicates that the MX44 is connected

to a power source, and the unit is on.

1 - 4: Volume controls - adjust the level of the

signals coming from Inputs 1 - 4.

IN 1 - 4: Stereo RCA and 1/8" (3.5mm)Tip-Ring-

Sleeve stereo unbalanced jacks for connection to

line level devices.

This is a MONO jack

and should never be

plugged into the out-

put of a MX44 Pro.

This is a TRS or

stereo jack that is

compatible with the

MX44 Pro output.
