Side 1/44
9113/9128
GB
HOW DOES THIS SALTER SCALE WORK? This Salter scale uses BIA (Bio Impedance
Analysis) technology which passes a tiny electrical impulse through the body to
determine fat from lean tissue, the electrical impulse cannot be felt and is perfectly
safe. Contact with the body is made via stainless steel pads on the platform of the
scale.
This method simultaneously calculates your personal weight, body fat, total body
water and BMI giving you a more accurate reading of your overall health and fitness.
This scale stores the personal data of up to 8 users. As well as being an analyser
scale, this scale can be used as a conventional scale.
NEW FEATURE! This scale features our convenient step-on operation. Once
initialised the scale can be operated by simply stepping straight on the platform – no
more waiting!
PREPARING YOUR SCALE 1. Open the battery compartment on the scale underside.
2. Remove isolating tab from beneath the battery (if fitted) or insert batteries
observing the polarity signs (+ and -) inside the battery compartment. Close the 3.
battery compartment. For use on carpet attach enclosed carpet feet. Position 4. 5.
scale on a firm flat surface.
INITIALISING YOUR SCALE 1. Press the platform centre and remove your foot.
2. ‘0.0’ will be displayed. To change weight mode (kg/lb/st) press the or button.3.
4. The scale will switch oand is now ready for use.This initialisation process must
be repeated if the scale is moved. At all other times step straight on the scale.
WEIGHT READING ONLY 1. Step on and stand very still while the scale computes
your weight. Your weight is displayed. Step o. Your weight will be displayed 2. 3.
for a few seconds. The scale will switch o.4.
PERSONAL DATA ENTRY
1. Press the button to turn the scale on.
2. While the user number is flashing, select a user number by pressing the or
buttons. Press the button to confirm your selection.
3. The male or female symbol will flash.
Press button until the correct symbol is flashing, then press the button.
4. The age display will flash.
Press and as necessary to set your age, then press the button.
Child Mode: When the age is set from 6-12 years child mode is automatically
selected.
NOTE: In child mode only weight, body fat and body water are displayed.
5. The height display will flash.
Press or as necessary to set your height, then press the button.
Athlete Mode: When the age is set from 15-50 years Athlete Mode is available.
To select Athlete Mode press the button until is displayed, then press the
button. An athlete is defined as a person who is involved in intense physical
activity of approximately 12 hours per week and who has a resting heart rate of
approximately 60 beats per minute or less.
6. The display will show your settings, then switch o. The memory is set.
7. Repeat procedure for a second user, or to change user details.
Note: To update or overwrite the memorised data, follow the same procedure,
making changes as required.
WEIGHT & BODY FAT READINGS
Position the scale on a flat level surface.
1. Press the button to turn the scale on.
2. Select your user number by pressing the or buttons.
3. WAIT while the display reconfirms your personal data then shows a zero reading.
4. When zero is displayed, WITH BARE FEET, step onto the platform and stand still.
Ensure your feet are in good contact with the metal pads on the platform.
5. After 2-3 seconds your weight will be displayed.
6. Remain standing on the scale while your other readings are taken.
7. Your weight will be displayed followed by your body fat percentage, total body
water percentage and BMI.
BODY FAT -WHAT DOES IT MEAN? The human body is made up of, amongst other
things, a percentage of fat. This is vital for a healthy, functioning body - it cushions
joints and protects vital organs, helps regulate body temperature, stores vitamins
and helps the body sustain itself when food is scarce. However, too much body fat
or indeed too little body fat can be damaging to your health. It is dicult to gauge
how much body fat we have in our bodies simply by looking at ourselves in the mirror.
This is why it is important to measure and monitor your body fat percentage. Body fat
percentage gives you a better measure of fitness than weight alone – the composition
of your weight loss could mean you are losing muscle mass rather than fat - you
could still have a high percentage of fat even when a scale indicates
‘normal weight’.
GLASS ANALYSER
Instructions and Guarantee
E
IMPÉDAN CEMÈTRE • KÖRPER-ANALYSE-WAAGE • BÁSCULA ANALIZADORA DEL CUERPO
PESAPERSONE RILEVA-GRASSO • BALANÇA DE ANÁLISE CORPORAL • KROPPSANALYSEVEKT
LICHAAMSANALYSE WEEGSCHAAL • KEHON KOOSTUMUKSEN ANALYYSIVAAKA • KROPPSANALYSVÅG
KROPSANALYSEVÆGT • TESTZSÍRANALIZÁTOROS MÉRLEG • VÁHA PRO ANALÝZU TĚLA
VÜCUT ANALİZ TARTISI • ΖΥΓΑΡΙΑ ΜΕ ΑΝΑΛΥΤΗ ΣΩΜΑΤΟΣ • ВЕСЫ-АНАЛИЗАТОР
WAGA BODY ANALYSER • OSOBNÁ VÁHA S ANALYZÁTOROM
2
NORMAL HEALTHY RANGE OF BODY FAT PERCENTAGE
BODY FAT % RANGES FOR BOYS*
Age Low Optimal Moderate High
6 ≤12.4 ≥22.712.5 -19.5 19.6 - 22.6
7 ≤12.6 ≥24.112.7 - 20.4 20.5 - 24.0
8 ≤12.7 ≥25.512.8 - 21.3 21.4 - 25.4
9 ≤12.8 ≥26.812.9 - 22.2 22.3 - 26.7
10 ≤12.8 ≥27.912.9 - 22.8 22.9 - 27.8
11 ≤12.6 ≥28.312.7 - 23.0 23.1 - 28.2
12 ≤12.1 ≥27.912.2 - 22.7 22.8 - 27.8
13 ≤11.5 ≥27.011.6 - 22.0 22.1 - 26.9
14 ≤10.9 ≥25.911.0 - 21.3 21.4 - 25.8
15 ≤10.4 ≥25.010.5 - 20.7 20.8 - 24.9
16 ≤10.1 ≥24.310.2 - 20.3 20.4 - 24.2
17 ≥23.9 ≤9.8 9.9 - 20.1 20.2 - 23.8
18 ≥23.6 ≤9.6 9.7 - 20.1 20.2 - 23.5
BODY FAT % RANGES FOR GIRLS*
Age Low Optimal Moderate High
6 ≤14.4 ≥26.214.5 - 23.0 23.1 - 26.1
7 ≤14.9 ≥28.015.0 - 24.5 24.6 - 27.9
8 ≤15.3 ≥29.715.4 - 26.0 26.1 - 29.6
9 ≤15.7 ≥31.215.8 - 27.2 27.3 - 31.1
10 ≤16.0 ≥32.216.1 - 28.2 28.3 - 32.1
11 ≤16.1 ≥32.816.2 - 28.8 28.9 - 32.7
12 ≤16.1 ≥33.116.2 - 29.1 29.2 - 33.0
13 ≤16.1 ≥33.316.2 - 29.4 29.5 - 33.2
14 ≤16.0 ≥33.616.1 - 29.6 29.7 - 33.5
15 ≤15.7 ≥33.815.8 - 29.9 30.0 - 33.7
16 ≤15.5 ≥34.115.6 - 30.1 30.2 - 34.0
17 ≤15.1 ≥34.415.2 - 30.1 30.2 - 34.3
18 ≤14.7 ≥34.814.8 - 30.8 30.9 - 34.7
BODY FAT % RANGES FOR MEN**
Age Low Optimal Moderate High
19 - 39 8.1 - 19.9 20 - 24.9≤8 ≥25
40 - 59 11.1 - 21.9 22 - 27.9≤11 ≥28
60+ ≤13 ≥3013.1 - 24.9 25 - 29.9
BODY FAT % RANGES FOR WOMEN**
Age Low Optimal Moderate High
19 - 39 21.1 - 32.9 33 - 38.9≤21 ≥39
40 - 59 23.1 - 33.9 34 - 39.9≤23 ≥40
60+ ≤24 ≥4224.1 - 35.9 36 - 41.9
*Source: Derived from; HD McCarthy, TJ Cole, T Fry, SA Jebb and AM Prentice: “Body fat reference curves for
children”. International Journal of Obesity (2006) 30, 598–602.
**Source: Derived from; Dympna Gallagher, Steven B Heymsfield, Moonseong Heo, Susan A Jebb, Peter
R Murgatroyd, and Yoichi Sakamoto: “Healthy percentage body fat ranges: an approach for developing
guidelines based on body mass index1–3”. Am J Clin Nutr 2000;72:694–701.
The Body Fat % ranges published are for guidance only. Professional medical guidance should always be
sought before embarking on diet and exercise programs.
BODY WATER -WHY MEASURE IT? Body water is the single most important
component of body weight. It represents over half of your total weight and almost
two thirds of your lean body mass (predominantly muscle). Water performs a number
of important roles in the body:
All the cells in the body, whether in the skin, glands, muscles, brain or anywhere
else, can only function properly if they have enough water. Water also plays a vital
part in regulating the body’s temperature balance, particularly through perspiration.
The combination of your weight and fat measurement could appear to be ‘normal’ but
your body hydration level could be insucient for healthy living.
NORMAL HEALTHY RANGE OF BODYWATER PERCENTAGE
BODY WATER CHART***
BF % Range Optimal BW % Range
Men 4 to 14% 70 to 63%
15 to 21% 63 to 57%
22 to 24% 57 to 55%
25 and over 55 to 37%
Women 4 to 20% 70 to 58%
21 to 29% 58 to 52 %
30 to 32 % 52 to 49%
33 and over 49 to 37%
***Source: Derived from Wang & Deurenberg: “Hydration of fat-free body mass”. American Journal Clin Nutr
1999, 69 833-841.
Body water measurement results are influenced by the proportion of body fat and
muscle. If the proportion of body fat is high, or the proportion of muscle is low
then the body water results will tend to be low. It is important to remember that
measurements such as body weight, body fat and body water are tools for you to use
as part of your healthy lifestyle. As short term fluctuations are normal, we suggest
you chart your progress over time, rather than focus on a single days reading.
The Body Water % ranges published are for guidance only. Professional medical
guidance should always be
sought before embarking
on diet and exercise
programmes.
WHAT DOES MY BMI VALUE
MEAN?
Body Mass Index (BMI) is an
index of weight-for-height
that is commonly used
to classify underweight,
overweight and obesity in
adults. This scale calculates
your BMI value for you. The
BMI categories shown in
the chart and table below
are recognised by the WHO
(World Health Organisation)
and can be used to interpret your BMI value.
Your BMI category can be identified using the table below.
BMI Category Health Risk Based Solely On BMIBMI Value Meaning
< 18.5 UnderweighttModerate
18.6-24.9 Normal Low
25-29.9 Overweight Moderate
30+ Obese High
IMPORTANT: If the chart/table shows that you are outside of a ‘normal’ healthy
weight range, consult your doctor before taking any action. BMI classifications are for
adults (age 20+ years) only.
QUESTIONS & ANSWERS
How exactly is my body fat and water being measured?
This Salter Scale uses a measurement method known as Bioelectrical Impedance
Analysis (BIA). A minute current is sent through your body, via your feet and legs.
This current flows easily through the lean muscular tissue, which has a high fluid
content, but not easily through fat. Therefore, by measuring your body’s impedance
(i.e. its resistance to the current), the quantity of muscle can be determined. From
this, the quantity of fat and water can then be estimated.
What is the value of the current passing through me when the measurement is
taken? Is it safe?
The current is less than 1mA, which is tiny and perfectly safe. You will not be able
to feel it. Please note however, that this device should not be used by anyone with
an internal electronic medical device, such as a pacemaker, as a precaution against
disruption to that device.
If I measure my body fat and water at dierent times during the day, it can
vary quite considerably. Which value is correct?
Your body fat percentage reading varies with body water content, and the latter
changes throughout the course of the day. There is no right or wrong time of the day
to take a reading, but aim to take measurements at a regular time when you consider
your body to be normally hydrated. Avoid taking readings after having a bath or
sauna, following intensive exercise, or within 1-2 hours of drinking in quantity or
eating a meal.
My friend has a Body Fat Analyser made by another manufacturer.
When I used it I found that I got a dierent body fat reading. Why is this?
Dierent Body Fat Analysers take measurements around dierent parts of the body
and use dierent mathematic algorithms to calculate the percentage of body fat.
The best advice is to not make comparisons from one device to another, but to use
the same device each time to monitor any change.
6’6
6’4
6’2
6
5’10
5’8
5’6
5’4
5’2
5
4’10
2.00
1.88
1.68
1.52
1.76
1.96
1.84
1.64
1.48
1.92
1.72
1.56
1.80
1.60
6 10
40 50 60 70 80 90 100 130110 140120 150
20 2515
ft
st
kg
m

Produkt Specifikationer

Mærke: Salter
Kategori: Vægten
Model: 9113 GY3R

Har du brug for hjælp?

Hvis du har brug for hjælp til Salter 9113 GY3R stil et spørgsmål nedenfor, og andre brugere vil svare dig


Vægten Salter Manualer

Salter

Salter 9193 BK3R Manual

12 Januar 2025
Salter

Salter 9221 BK3R Manual

6 September 2024
Salter

Salter 9113 GY3R Manual

6 September 2024
Salter

Salter 9192 BK3R Manual

6 September 2024
Salter

Salter 9113 SV3R Manual

6 September 2024
Salter

Salter SA 9193 GN3R Manual

21 August 2024
Salter

Salter SA 9216 WD3R Manual

21 August 2024
Salter

Salter 9500 Manual

20 August 2024
Salter

Salter BAMBOU Manual

19 August 2024
Salter

Salter 9206 SVWH3R Manual

19 August 2024

Vægten Manualer

Nyeste Vægten Manualer

Kern

Kern PCD 300-3 Manual

1 April 2025
Kern

Kern FCE 3K-3A Manual

30 Marts 2025
Kern

Kern TEFS 500-2-A Manual

30 Marts 2025
Kern

Kern MPL 200K-1P Manual

30 Marts 2025
Kern

Kern TGC 500-1S05 Manual

29 Marts 2025
PCE Instruments

PCE Instruments PCE-BSK 5100 Manual

28 Marts 2025
PCE Instruments

PCE Instruments PCE-PB 150N Manual

14 Marts 2025
PCE Instruments

PCE Instruments PCE-BSH 10000 Manual

14 Marts 2025
PCE Instruments

PCE Instruments PCE-MA 202 Manual

14 Marts 2025
PCE Instruments

PCE Instruments PCE-PCS 6 Manual

14 Marts 2025
