The switch actuator REG-K/12x230/16 with manual

mode (referred to below as the actuator) can switch

twelve loads via separate, floating make contacts.

You can also manually switch the connected loads with

manual switches on the actuator without bus voltage.

The actuator has a bus coupler. It is installed on a DIN

rail, with the bus connection made via a bus connecting

terminal. It is supplied with power from the bus voltage.

A data rail is not required.

For your safety

HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR

ARC FLASH

Safe electrical installation must be carried out only by

skilled professionals. Skilled professionals must prove

profound knowledge in the following areas:

• Connecting to installation networks

• Connecting several electrical devices

• Laying electric cables

• Connecting and establishing KNX networks

• Safety standards, local wiring rules and regulations

Failure to follow these instructions will result in

death or serious injury.

RISK OF FATAL INJURY FROM ELECTRIC SHOCK

The output may carry electrical current even when the

load is switched off.

• When working on the device: Always disconnect the

device from the supply by means of the fuse in the in-

coming circuit.

• Even if the manual switch is in the „OFF“ position, a

KNX telegram can switch the connections to being

live at any time. Before working on the device, always

diconnect the fuse in the incoming circuit from the

supply.

Failure to follow these instructions will result in

death or serious injury.

The device may be damaged!

• Always operate the product in compliance with the

specified technical data.

• Only install devices with at least basic insulation next

to the device.

Failure to follow these instruction can result in

equipment damage.

Getting to know the switch actuator

ABus connecting terminal, max. 4 core pairs

BProgramming LED (red LED)

CProgramming button

DCable cover

EOperating LED (green LED)

FManual switch

GScrew terminals

1Set the actuator onto the DIN rail.

2Connect KNX.

WARNING

Risk of fatal injury from electrical current. The

device could become damaged.

Safety clearance must be guaranteed in

accordance with IEC 60664-1. There must be at

least 4 mm between the individual cores of the

230 V supply cable and the KNX line.

Connections, displays and operating

elements

Mounting the actuator

RISK OF FATAL INJURY FROM ELECTRIC SHOCK

Voltage may be present at the outputs when the mains

voltage is connected to the system.

If subjected to strong vibrations during transportation,

the switch contacts might change to the enabled state.

After connecting the bus voltage, set the relays of the

channels to the position desired simply by switching

„On/Off“ or by changing the manual switch to „OFF“.

Failure to follow these instructions will result in

death or serious injury.

L L LL LL LL LL LL LL L LL LL LL L

ABD

5 6 7 8 9 10 11 121 2 3 4

1 2

5 mm

230 V

4 mm

KNX

3Connect the bus voltage.

4Switch the relays of the channels on and off

manually once with the manual switches.

5Connect the load.

The cables to the loads as well as the system voltages

(L1, L2 or L3) are connected via screw terminals for

max. 16 A. Every two L connections are bridged

internally.

6Connect the mains voltage.

Now you can check the functionality of the actuator and

the connected loads without having to load the

application from the ETS. (See the "Operating the

actuator" section.)

1Press the programming button.

The programming LED lights up.

2Load the physical address and application into the

device from the ETS.

The programming LED goes out.

The operating LED lights up: The application was loaded

successfully, the device is ready for operation.

The device may be damaged!

• Protect the switch contacts with a series-connected

16 A circuit breaker.

Failure to follow these instruction can result in

equipment damage.

Putting the actuator into operation

KNX L1 L2 L3 N

16 A 16 A16 A

SpaceLogic KNX

Switch actuator REG-K/12x230/16 with

manual mode

Operating instructions

Art. no. MTN648493

L L LL LL LL LL LL LL L LL LL LL L

5 6 7 8 9 10 11 121 2 3 4

Normally, you control connected devices using push-

buttons or by remote control. However, you can

manually switch each of the actuator's channels on and

off directly at the manual switches.

Schneider Electric Industries SAS

35 rue Joseph Monier

Rueil Malmaison 92500

France

If you have technical questions, please contact the Cus-

tomer Care Centre in your country.

se.com/contact

Operating the actuator

Technical data

External auxiliary

voltage: None

Power supply from

bus:

DC 24 V/max. 10 mA

Insulation voltage: AC 4 kV between bus and

230 V AC

Switch contacts: 12 x make contacts, floating

Nominal voltage: AC 230 V, 50 to 60 Hz

Nominal current: 16 A, cos = 0.6

Connected load

Incandescent lamps: AC 230 V, max. 3600 W with

10,000 switching cycles

Halogen lamps: AC 230 V, max. 2500 W with

10,000 switching cycles

Fluorescent lamps: AC 230 V, max. 2500 VA,

parallel-compensated,

with 5,000 switching cycles

Capacitive load: AC 230 V, 16 A max. 200 F

with 5,000 switching cycles

Minimum loads:  24 V DC, 100 mA

Switching frequency: max. 10 per minute at nominal

load

Ambient temperature

Operation: -5 °C to +45 °C

Storage: -25 °C to +55 °C

Transport: -25 °C to +70 °C

Environment: The device is designed for use

at a height of up to 2000 m

above sea level (MSL).

Max. humidity: 93 %, no moisture

condensation

Operating elements: Programming button,

twelve manual switches for

manual operation

Display elements: Red LED for programming

check,

green LED to indicate device

availability

Connections

Bus: via two 1 mm pins for bus

connecting terminal

Outer conductor: eleven 3-gang screw

terminals (1–11) and one 2-

gang screw terminal (12) for

each max. 2.5 mm2

Installation width: 12 depth units = approx.

216 mm

EC guidelines: Corresponds to Low-Voltage

guideline 73/23/EEC and EMC

guideline 89/336/EEC

Schneider Electric -Contact

Schneider Electric Limited

Telford, TF3 3 BL, UK

UK Representative

Stafford Park 5

V6484-562-02 11/21
