Side 1/2

211.0 mm (8.31”)

195.0 mm (7.68”)

65.5 mm (2.58”)

92.0 mm (3.62”)

196.0 mm (7.72”)

Dimensions Mounting

Parts included

1. 1 x NAC™ -3 Autopilot Computer - IPX5

2. 4 x Fixing screws

3. 1 x Micro-C Drop cable (male) - 0.6 m

4. 1 x Micro-C T-Joiner

5. 7 x Connectors

6. 1 x 30 Amp fuse

7. Warranty card & literature pack

NAC

™

-3

INSTALLATION GUIDE

Trademark

®Reg. U.S. Pat. & Tm. Oﬀ, and ™ common law marks.

Visit www.navico.com/intellectual-property to review

the global trademark rights for Navico Holding AS.”

*988-11145-003*

For setup instructions, commissioning guide,

product manuals, technical speciﬁcations,

certiﬁcates and declarations,

refer to the product website:

www.simrad-yachting.com

www.bandg.com

System wiring example

AUTOPILOT

CONTROLLER

NMEA 2000® Backbone

Micro-C Drop cable

Micro-C Power cable

Micro-C T-Joiners

Micro-C Terminator, 120 Ohm

Rudder drive & Feedback cable

T T

MFD

12/24V DC

12V DC

NAC™ -3

COMPASS

GPS

SENSOR

DRIVE UNIT

Power

NMEA 2000® Backbone

Micro-C Drop cable

Rudder Drive & Feedback cable

RUDDER

FEEDBACK

IPX5

-2

MOTOR

CLUTCH / BYPASS

DRIVE

30 A FUSE

POLARITY LEDS

DRIVE

ENGAGE

SUPPLY

NMEA0183

ALARM

MODE

SCREEN

TERMINATION

REMOTE

SIMNET

RUDDER

Terminal access Drive units (Max 8A/12A Continuous/Peak)

Rudder Feedback

External Alarm

Mode/Function Selector

External I/O

NMEA 0183

Terminal layout Grounding

Network Remotes

Power

2 3 3

CONNECT WIRES

CHECK POLARITY INSTALL FUSE POWER ON

POWER SWITCH

TO VESSELS

MAIN

GROUND

Ground the NAC

™ -3 before

any other connectors

SCREEN

TERMINATION

POWER SWITCH

OFF

SIMNET / NMEA 2000®

REMOTE

RUDDER

DRIVE DRIVE

DRIVE

ENGAGE

DRIVE

ALARM

RUDDER

FEEDBACK

SENSOR

NMEA 2000 ®

BACKBONE

POWER SWITCH

OFF

12/24 V DC

DO NOT

INSTALL FUSE

FUSE NOT

INSTALLED

INSTALL

FUSE

INSTALLED

RED

BLK

WHT

BLU

NET-S

NET-C

NET-H

NET-L

GND

PORT

STBD

LAMP

SIM

SIMR

RAD

S35

SIMRAD

R3000X

STBY AUTO

FRQ +

FRQ -

MOTOR

SOL-1

MOTOR

SOL-2

SOL GND

SOL

SOL-1

MOTOR

SOL-1

MOTOR

SOL-2

SOL

GND

CMD

RET

MOTOR

SOL-1

MOTOR

SOL-2

REVERSIBLE PUMP HYDRAULIC LINEAR

DRIVE

ROTARY DRIVE

SOLENOID VALVE*

* Solenoid valves, 12 or 24V DC,

powered from NAC-3 Autopilot

NOTE:

NAC™ -3 Autopilot cannot operate externally powered solenoids unless installing isolating relays.

NAC™ -3 Autopilot ne peut pas commander des électrovannes sans utiliser un relais isolé.

NAC™ -3 Autopilot kann keine extern gespeisten Magnetventile ansteuern sofern keine isolierten Relais installiert sind.

NAC™ -3 Autopilot kan ikke kobles mot magnetventiler med eksternt tilført spenning uten at man benytter eksterne releer.

NMEA0183

Rx_A

Rx_B

Tx _A

Tx_B

IEC61162-1/2

(NMEA0183)

DEVICES

RET

(Frequency rudder feedback)

MODE

SYSSEL

MANUAL

AUTOPILOT

RET

SYSSEL

RET

STEADYSTEER™

DISENGAGE

SWITCH

OPTION 1

OPTION 2

SYSSEL

RET

DRIVE

ENGAGE

ENGAGE SIGNAL

CMD

RET

CMD

RET

Supply

RX1

Option 1 - Disengage switch

• OPEN – Normal operation, can be controlled by controller.

• CLOSED to OPEN – Activates Auto mode, regardless of previous state.

• CLOSED - Disengaged. Cannot be controlled by controller.

Option 2 - SteadySteer™

• Manual steering overrides the active mode.

• If Auto mode or NoDrift mode was active before going into manual

steering, they will automatically re-engage at the new course.

• For any other modes, the autopilot goes into Standby mode.
