Side 1/2

solaredge.com

SolarEdge EV Charger

For Europe

Residential EV charging solution that seamlessly integrates with the

full SolarEdge Home ecosystem

Utilizes excess PV to charge EV from the sun,

for reduced homeowner electricity bills

Charge smarter with our custom scheduling

feature, allowing automatic charging during

low-rate periods, including at night

Suitable for single and three phase

installations, for both indoor and outdoor use

Control and monitoring via the mySolarEdge

app, including remote operations, charging

schedules, and charging history

Integrated optional RFID card authentication

and MID meter

SMART ENERGY

YEAR

WARRANTY

All other trademarks mentioned herein are trademarks their respective owners. Date: July 13, 2023 -000191- . Subject of DS EU to change without notice.

SolarEdge EV Charger

For Europe

SPECIFICATIONS

Rated AC Power Output

4.6 / 7.4 / 11 / 22

Rated Current (configurable)

10 / 13 / 16 / 20 / 25 / 32 Single Phase or Three Phase

Nominal AC Output Voltage

3 x 230 / 400

Line Frequency

Mains Forms

TT / TN / IT

Internal Consumption

Idle: 4; plugged in: 5; charging: 7

Charge Mode

Mode 3 in accordance with IEC 61851-1 AC charging

Over-Voltage Category

III, in accordance with EN 60664

Protection Class

IP54

Protection Against Mechanical Impact

IK10

Rated Short-Circuit Current

< 10 (effective value in accordance with EN 61439- 1)

Residual Direct Current Detecting Device (RDC-DD)

≥ 6 (characteristic in accordance with IEC 62955, < 10 s)

Ventilation

Compatible Inverters

All SetApp-enabled residential inverters (up to SE15K) (1)

AC TERMINALS

Cable Feed

Top (surface); back side (flush)

Type

Spring-type terminal

Cross-section

Rigid / flexible

0.2 – 16

mm2

Flexible with wire end sleeve

with / without plastic sleeve

0.25 – 10

mm2

Stripping Length

Connection Cross-section

of the Supply

Suggested minimum cross-section:

16 A rated current

5 x 2.5

mm2

32 A nominal current

5 x 6.0

mm2

Temperature Rating

105

°C

CABLE / SOCKET

Type

Type 2: up to 32 A / 400 V AC in accordance with EN 62196-1 and VDE- -E 2623-2-2 AR

Cable Length (for variants with cable)

AMBIENT CONDITIONS

Installation Environment

Indoor and outdoor

Operating Temperature @16 A

-25 to +50 (without direct sunlight)

°C

Operating Temperature @32 A

-25 to +40 (without direct sunlight)

°C

Storage Temperature

-25 to +80

°C

Relative Air Humidity

5 to 95 (non-condensing)

Altitude

Max. 2000 above sea level

COMMUNICATION INTERFACE

Ethernet 1

LSA+® terminals

Data Transfer Rate

10 / 100

Mbit/s

Ethernet 2

RJ45 alternative to Ethernet 1

WLAN/WI- FI

IEEE 802.11 b,g,n, 2.4 GHz

WLAN/WI-FI Supported Modes

AP Ad-hoc-Mode, Client Mode Frequency 2400- 2483.5 MHz, EIRP ≤ 20 dBm

ADDITIONAL CAPABILITIES

RFID Card

MIFARE card /tag according to ISO 14443 or ISO 15693

Frequency 13.553- -7 dBm 13.567 MHz, EIRP ≤

OCPP Backend

SolarEdge OCPP pre-configured

STANDARD COMPLIANCE

CE Declaration of Conformity

Yes

MID

Optional, Accuracy Class B (according to EN 50470-1 / - 3)

DIMENSIONS AND WEIGHT

Height (Cable / Socket) X Width Depth X

643 / 495 X 142 X 240

Weight (Cable / Socket)

7.8 / 5

(1) Excluding the Single Phase Inverter with Compact Technology.

ORDERING INFORMATION

PART NUMBER

DESCRIPTION

SE-EVK22C00- 01

SolarEdge EV Charger, 22 kW, 6m Cable, Type 2

SE-EVK22CRM- 01

SolarEdge EV Charger, 22 kW, 6m Cable, Type 2, RFID, MID

SE-EVK22SRM- 01

SolarEdge EV Charger, 22 kW, Socket, Type 2, RFID, MID

SE-ACCRF10- 01

Kit of 10 SolarEdge RFID cards
