CM31-EZ

Do not spec or install speaker near support beam, ventilation duct or

other structure that may interfere with speaker function or dispersion.

Warning

SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for

optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.

Grille

Installation aid/paint mask

Baffle

SpeedWing™ mounting arms

Speaker seismic restraint hole

Tile bridge

Flexible conduit clamp

Signal wires

Grille safety clip

1. Nail or screw bracket to

joists.

2. Finish installing ceiling.

8. Remove paint mask

unless painting is required.

In that case, follow steps

9-12 when painting is

complete.

9. Adjust tap switch to

proper setting. Switch is

preset to the highest setting

in the 70.7-volt mode.

10. Attach grille safety clip

by placing the large end of

the clip over snap-fit post (1),

then sliding clip until small

end snaps into place around

post (2).

5. Feed speaker wires

through conduit clamp and

connect with wire nuts.

Push wire nuts into backcan

and affix conduit clamp.

3. Use RotoZip or other tool

to cut hole.

7. Insert speaker into

mounting hole. Tighten both

bolts on the baffle face to

actuate the mounting wings.

DO NOT OVERTIGHTEN.

6. If required, attach

seismic restraint system to

the sheet-metal tab on the

rear panel of the speaker,

then to reinforced structure

(safety cable not included).

11. Align tabs on snap-fit

grille with slots in baffle,

gently press grille into place.

1. Unpack speaker. Leave

paint mask in place until

after speaker is installed or

painting is complete.

4. Unpack speaker. Leave

paint mask in place until

after speaker is installed or

painting is complete.

2. Use included tile bridge

to mark cutout on

sheetrock. Tile bridge ships

in separate box.

3. Use RotoZip or other tool

to cut hole. Hole diameter:

5.6 in. (142 mm).

4. Feed speaker wires

through conduit clamp and

connect with wire nuts.

Push wire nuts into backcan

and affix conduit clamp.

8. Adjust tap switch to

proper setting. Switch is

preset to the highest

setting in the 70.7-volt

mode.

5. If required, attach seismic

restraint system to hole in

clamping arm, then to

reinforced structure (safety

cable not included).

2. Use included tile bridge

to mark cutout on tile.

1. Unpack speaker. Leave

paint mask in place until

after speaker is installed or

painting is complete. Tile

bridge ships in separate box.

3. Use RotoZip or other tool

to cut hole. Hole diameter:

5.6 in. (142 mm).

4. Insert speaker into

mounting hole on ground

with tile bridge and paint

mask in place. Tighten both

screws on the baffle face to

actuate the mounting wings.

Firmly secure both screws,

DO NOT OVERTIGHTEN.

Put assembly into tile grid.

5. Feed speaker wires

through conduit clamp and

connect with wire nuts.

Push wire nuts into backcan

and affix conduit clamp.

6. If required, attach seismic

restraint system to hole in

clamping arm, then to

reinforced structure (safety

cable not included).

8. Adjust tap switch to

proper setting. Switch is

preset to the highest setting

in the 70.7-volt mode.

9. Attach grille safety clip by

placing the large end of the

clip over snap-fit post (1),

then sliding clip until small

end snaps into place around

post (2).

10. Align tabs on snap-fit

grille with slots in baffle,

gently press grille into place.

11. Done! 11. Done! 12. Done!9. Attach grille safety clip by

placing the large end of the

clip over snap-fit post (1),

then sliding clip until small

end snaps into place around

post (2).

10. Align tabs on snap-fit

grille with slots in baffle,

gently press grille into place.

7. Remove paint mask

unless painting is required.

In that case, follow steps

8-11 when painting is

complete.

7. Remove paint mask

unless painting is required.

In that case, follow steps

8-11 when painting is

complete.

6. Insert speaker into

mounting hole with paint

mask in place. Tighten both

bolts on the baffle face to

actuate the mounting wings.

Firmly secure both bolts,

DO NOT OVERTIGHTEN.

Box contents

1 Speaker

1 Grille

1 Paint mask

2 Wire nuts

1 UL-listed conduit clamp

Note: Tile bridge included, ships in separate box.

Install Instructions For:

CM31-EZ speaker

1.435.647.9555

| | 800.647.TUBE

www.soundtube.com

CM31-EZ

Pre-Construction Bracket Instructions For:

CM31-EZ speaker (Pre-construction bracket sold separately)

1.435.647.9555

| | 800.647.TUBE

www.soundtube.com

CM31-EZ

Sheetrock Installation Instructions For:

CM31-EZ speaker

1.435.647.9555

| | 800.647.TUBE

www.soundtube.com

CM31-EZ

Drop-tile Installation Instructions For:

CM31-EZ speaker

1.435.647.9555

| | 800.647.TUBE

www.soundtube.com

CM31-EZ

Produkt Specifikationer

Mærke:	SoundTube
Kategori:	Højttaler
Model:	CM31-EZ
Kode for international beskyttelse (IP):	IP54
Vægt:	1400 g
Antal pr. pakke:	1 stk
Brugervejledning:	Ja
Produktfarve:	Aluminium, White
Pakkevægt:	1680 g
Pakkedybde:	203.2 mm
Pakkebredde:	184.15 mm
Pakkehøjde:	209.55 mm
Bluetooth:	Ingen
Udgangseffekt (RMS):	20 W
Husmateriale:	Acrylonitrile butadiene styrene (ABS), Aluminium
Pakketype:	Kasse
Anbefalet brug:	Universel
Frekvensområde:	115 - 22000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	- kanaler
Højttaler, placering:	I væggen/i loftet
Certificering:	CE, RoHS, UL1480A, UL2043
Bæredygtighedscertifikater:	CE, RoHS
Diskanthøjttaler:	Ja
Sensitivitet:	85 dB
Diskant diameter:	3 "
Forstærker:	Ingen
