SoundTube PS1290i Manual

SoundTube Højttaler PS1290i

Læs gratis den danske manual til SoundTube PS1290i (1 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 21 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 11 anmeldelser. Har du et spørgsmål om SoundTube PS1290i, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

System Type

12” Multi-Purpose, High-Performance,

Weatherized 2-Way Passive Loudspeaker

Impedance (Nominal)

8 ohm

Sensitivity dB @ 2.83 V / 1 M

94 dB

Sensitivity dB @ 1 W / 1 M

94 dB

Frequency Response ( ±3 dB)

62 Hz - 20 kHz

Frequency Response ( ±10 dB)

44 Hz

Max. Program Power

600 W

Max. Continuous Power RMS

300 W

Tap Selector

n/a

Transducer: Low-Frequency Driver

12” High-Efficiency Weather Treated Woofer

Transducer: High-Frequency Driver

1” Titanium Compression Driver with

90 x 90 Horn Flare

Low-Frequency Voice Coil

2 in. / 50.8 mm

Crossover Frequency

2 kHz

Network Type: Low Pass

12 dB per octave, 2nd order

Network Type: High Pass

12 dB per octave, 2nd order

Enclosure Material

Reinforced Radiata Pine with Weatherized

Urethane Bed-Liner Coating

Grille

Weather-Treated Electro-Plated & Powder-Coated

Steel Grille (passed MIL-STD-810G test,

Method 509)

Inputs

4-pin, 5.08 mm Euroblock for individual or daisy

chain connection

Colors

Black, White

Length

16 in / 406.4 mm

Width

15 in / 381 mm

Height

22.75 in / 577.9 mm

Weight

45 lbs / 20.4 kg

Packaging

One per box

Included Accessories

Weather-Proof Terminal Cover Plate,

Water-Tight Cable Glands

Optional Accessories

Pan & Tilt Surface-Mount Bracket, Fly Mount Kit

IP Rating

IP55

Certications

CE, RoHS, MIL-STD-810G

TAA Compliant (Trade America)

Yes

BAA Compliant (Made in USA)

Yes

PS1290i PRODUCT SPECIFICATIONS

12” Multi-Purpose, High-Performance,

Weatherized 2-Way Passive Loudspeaker

PS1290i

rev. 6.7.24

Impedance listed per IEC 60268-5 with a minimum less than

80% the nominal impedance

1 W/1 M sensitivity determined using nominal impedance

Frequency response measured in half or full space as dictated

by speaker mounting conguration

Max program power is 3 dB above max continuous power

Continuous power rating, EIA-426-B test

Max output based on max continuous power

PRELIMINARY

INFORMATION

Description

The PS1290i is a high-output, passive 8 ohm speaker with a

high-efciency, weather-treated 10-inch woofer and an advanced

compression driver with a 90x90° horn are to deliver pristine highs

and robust bass. With 300 W continuous (600 W peak) of power

handling and 94 dB sensitivity, the PS1290i speaker is equipped for

the most demanding live or installed audio applications. The PS1090i

and PS1290i models are further enhanced by an outdoor IP55

rating, making them suitable for both indoor and outdoor use.

Designed for foreground and background applications in nightclubs,

live venues, houses of worship or any space that requires powerful

installed or portable sound, these speakers blend high performance

with exceptional versatility.

Features

• One 12” weather-treated, high-efciency woofer

• One 1” compression driver with 90x90° horn are

• Weather-Treated Electro-Plated & Powder-Coated Steel Grille

(passed MIL-STD-810G test, Method 509)

• Reinforced radiata pine enclosure

• Durable urethane bed-liner coating, available in

Black or White

• Optional Accessories: Pan & Tilt Surface-Mount

Bracket, Fly Mount Kit

• TAA & BAA Compliant -- Proudly made in the USA

Produkt Specifikationer

Mærke:	SoundTube
Kategori:	Højttaler
Model:	PS1290i
