Box contents

1 Speaker

2 SpeedClamps™

1 Release key (small hex wrench)

1 Hanging cable

1 Safety cable

4 Zip ties

Tap sw ch it

UL Liste 0Ad 148

1.855.663.5600

www.soundtube.com

Do not spec or install speaker near support beam, ventilation duct or

other structure that may interfere with speaker function or dispersion.

Warning Warning

SoundTube speakers ust be stalled by ofe sional audio in taller/contracto m in a pr s s r. s y and r For afet fo

optim dio performance, talle follow all di ection sued Souum au ins r must r s is by ndTube Ente tai ment r n .

MM43-BGM and MM32-EZ speakers

Mighty Mite

™

S y ca afet blewith clip Hanging ca leb with clip

H iang ng or sa tyfe cab le

S e a r ecur ncho po nti

S epe dCl mpa ™

Transformer Taps

70.7 V

30 W

15 W

7.5 W

3.75 W

Output

98.5 dB

95.5 dB

92.5 dB

89.5 dB

100 V

30 W

15 W

7.5 W

Output

98.5 dB

95.5 dB

92.5 dB

10. Use zip or twis st-lock tie

to secure safe cab &ty le signal

wire to main han ging cables.

Ca leb cover available for

as het tic applications (SLT-10).

7. Adjust speaker hanging

height with SpeedClamp™

mechanism. Pull to tighten &

insert release key (small hex

wrench) into SpeedClamp ™

as shown to loosen or adjust.

6. Thread cable end(s)

through SpeedClamp™

mechanisms as shown.

5. Attach the hanging cable

by securing it and the safety

cable to structure as shown.

8. Attach hanging cable to

the center hole in the

speaker hanging bracket.

MM43-BGM and MM32-EZ speakers

Mighty Mite

™

1.855.663.5600

www.soundtube.com

9. Att tach he safety cable to

one of the secondary holes in

the hanging bracket.

4. Thread hanging or safety

cable through SpeedClamp™

mechanisms as shown.

2. Conne sict gnal wire to

screw-down terminal block.

Tighten use min un d ter al

screws. Use in de sit si po ive

a neg ve inp nd ati uts for

either oice v r coil o

d t buted sy e . is ri st ms

Source

3. When daisy chaining, wire

the outside terminals to the

inside terminals of the next

speaker. This step only applies

to tap settings using the

transformer and not when the

speaker is used on bypass.

1. Remove the

magnetically-attached grille

from the front of the speaker to

reveal the rotary tap switch.

Select tap position on rotary

switch. Switch is preset to

maximum tap setting in 70.7V

mode.

Produkt Specifikationer

Mærke:	SoundTube
Kategori:	Højttaler
Model:	MM43-BGM
Højde:	556 mm
Vægt:	5960 g
Antal pr. pakke:	1 stk
Produktfarve:	Hvid
Udgangseffekt (RMS):	30 W
Husmateriale:	Acrylonitrilbutadienstyren
Pakketype:	Kasse
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	3-vejs
Højttaler, placering:	Kan monteres i loftet
Certificering:	CE, RoHS, UL1480, UL2239
Strømkilde type:	Vekselstrøm
Diameter:	188 mm
Diskanthøjttaler:	Ja
Delefrekvens:	2500 Hz
Bashøjttaler:	Ja
