Thank you for choosing Phase Technology

speakers. We know

there are a wide variety of choices available today, and we sincerely

appreciate your purchase of our product. Phase Technology

speakers are built to exacting standards and will provide many

years of listening enjoyment.

Our speakers are the result of over ve decades of designing

and manufacturing. We hold many key patents in loudspeaker

technology including the soft-dome tweeter. Our mission, our

passion is to constantly advance the art and science of accurate

audio reproduction. Our dedication insures your new speakers will

accurately reproduce all the impact, detail and delicacy of today’s

digital technology.

Regardless of application, serious audiophile listening or home

theater, we recommend that you take the time to read this manual

thoroughly before connecting speakers to your amplier or receiver.

In the highly unlikely event that you should experience a problem

with set-up or operation, please contact one of our authorized

dealers for assistance, or contact us directly.

Phase Technology Corporation

8005 W. 110th St., Suite 208

Overland Park, KS 66210

855.663.5600 (Domestic)

+1.913.663.5600 (International)

Fax: 913.663.3200

SAFETY INSTRUCTIONS 2

GETTING STARTED AND PRECAUTIONARY NOTES 3

HOME THEATER SPEAKER PLACEMENT 4

SUBWOOFER PLACEMENT 5

SPEAKER CONNECTIONS 5

V626 FOOT INSTALLATION & FLOOR SPIKES 6

V5520 BUMPER INSTALLATION 6

TWO-CHANNEL SPEAKER PLACEMENT 6

AMPLIFIER SETUP/BASS MANAGEMENT 7

CARING FOR YOUR SPEAKERS 7

MAINTENANCE AND SERVICE 7

WARRANTY 8

SPECIFICATIONS 8

V52

[PHASE VELOCITY FEATURES]

• Vapor Deposited Titanium (VDT

™

) woofers, low in weight and

rigid, delivers bass and mids that maintain total clarity, accuracy,

and tonal balance

• Patented Soft Dome Tweeter (US Patent #3328537) that

reproduces smooth and defined high frequencies

• Absolute Phase

Crossovers, engineered to route sound to a

particular driver and that the particular driver will only produce the

frequencies for which it was designed

• Curved Fiberboard enclosure to minimize the standing waves that

bounce parallel between the cabinet walls

PHASE VELOCITY

WNER’S MANUAL: V52 • V62 • V626 • V5520 • V-SURROUND-II

1. Read Instructions - All the safety and operating instructions

should be read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions

should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the

operating instructions should be adhered to.

4. Follow Instructions - All operating and other instructions

should be followed.

5. Water and Moisture - The appliance should not be used near

water - for example, near a bathtub, washbowl, kitchen sink,

laundry tub, in a wet basement, or near a swimming pool, etc.

6. Carts and Stands - The appliance should be used only with a

cart or stand that is recommended by the manufacturer.

PORTABLE CART WARNING

7. Wall or Ceiling Mounting - The appliance should be mounted

to a wall or ceiling only as recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its

location or position does not interfere with its proper ventilation.

For example, the appliance should not be situated on a bed, sofa,

rug, or similar surface that may block the ventilation openings;

or placed in a built-in installation, such as a bookcase or cabinet

[SAFETY INSTRUCTIONS]

that may impede the ow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources

such as radiators, stoves, or other appliances that produce heat.

10. Power Source - The appliance should be connected to

a power supply only of the type described in the operating

instructions or as marked on the appliance.

11. Power Cord Protection - Power supply cords should be

routed so that they are not likely to be walked on or pinched by

items placed up or against them, paying particular attention to

cords at plugs, convenience receptacles, and the point where they

exit from the appliance.

12. Cleaning - The appliance should be cleaned only as

recommended by the manufacturer.

13. Nonuse Periods - The power cord of the appliance should

be unplugged from the outlet when left unused for a long period

of time.

14. Object and Liquid Entry - Care should be taken so that

neither objects fall nor liquids spill into the inside of the appliance.

15. Damage Requiring Service - The application should be

serviced by qualied service personnel when:

a. the power supply cord or the plug has been damaged,

b. objects have fallen onto or liquid has been spilled into the

appliance,

c. the appliance has been exposed to rain,

d. the appliance does not appear to operate normally or exhibits a

marked change in performance, or

e. the appliance has been dropped or the cabinet damaged.

16. Servicing - The user should not attempt to service the

appliance beyond those means described in the operating

instructions. All other servicing should be referred to qualied

service personnel.

17. Grounding or Polarization - Precautions should be taken so

that the grounding or polarization means of an appliance is not

defeated.

Explanation of Graphical Symbols

The lightning ash with arrowhead symbol, within an

equilateral triangle, is intended to alert you to the presence

of un-insulated “dangerous voltage: within the product’s

enclosure that may be off sufcient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert you to the presence of important operating

and maintenance (servicing) instructions in the literature

accompanying the appliance.

APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR

USAGE

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

PLUG TO WIDE SLOT, INSERT FULLY.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE

LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE

CORRESPONDANTE DE LA PRESE ET POUSSER JUSQU AU FOND.

CAUTION: To reduce the risk of electric shock, do not remove cover

(or back). No user-serviceable parts inside. Refer servicing to qualied

service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Produkt Specifikationer

Mærke:	SoundTube
Kategori:	Højttaler
Model:	Phase Velocity V62
Bredde:	209.55 mm
Dybde:	242.1 mm
Højde:	336.55 mm
Vægt:	5870 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkedybde:	311.15 mm
Pakkebredde:	342.9 mm
Pakkehøjde:	438.15 mm
Udgangseffekt (RMS):	140 W
Husmateriale:	MDF
Pakketype:	Kasse
Anbefalet brug:	Hjem
Frekvensområde:	42 - 20000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	2-vejs
Lyd-output kanaler:	- kanaler
Højttaler, placering:	Bordplade/bogreol
Strømkilde type:	Vekselstrøm
Antal drivere:	1
Diskanthøjttaler:	Ja
Antal drivere til diskant:	2
Sensitivitet:	88 dB
Delefrekvens:	2200 Hz
Diskant diameter:	1 "
Bashøjttaler:	Ja
Antal bashøjttalerdrev:	1
Woofer diameter:	165.1 mm
Højttaler kabinet:	Porteret
Woofer diameter (britisk mål):	6.5 "
