Planter Speakers

INSTALL INSTRUCTIONS

Ultra-Fidelity Outdoor Speakers

Contact: MSE Audio, 855.663.5600 / 913.663.5600 / sales@mseaudio.com

Please read the following instructions carefully before installing

your Rockustics

Planter speaker. If you have any questions

regarding installation that are not answered in the following

directions, please contact your local sound contractor or the

Rockustics

/MSE Audio

technical support team.

Basic Wiring & Set Up

1) ( ) Locate the speaker wires on the underside of Diagram A

the planter. If necessary, trim the wire to the appropriate length

and strip the wire ends. Use the supplied silicone wire nut to

connect the positive (red) leads of the speaker and input wires.

Repeat this step with the negative (black) leads. Rockustics

recommends using 14ga or heavier direct burial cable for the

connection between the amplier and the speakers.

2) ( ) Fill planter with pea-gravel to approximately 2” Diagram B

above the black insert box to ensure proper drainage. Gently

rock the planter from side to side so that gravel lls in the gaps,

providing ample coverage of the black insert box. After lling

with pea-gravel, top with soil, and continue planting as you

would any normal planter. Be sure to the use the proper amount

of pea-gravel and soil to ll the planter; the soil and gravel are

important to the acoustic properties of the planter and will assist

with bass reproduction.

NOTE: The provided wire nuts are meant for permanent

installation use only. If you are temporarily wiring the speakers,

do not use these wire nuts. In the event you have used the

wire nuts and need to re-wire your system, do not attempt to

unscrew the nuts. Instead, clip the wires below the nut, and

follow the steps in the section with a Basic Wiring & Set Up

new pair of waterproof wire nuts (these are available at most

hardware stores).

Optimizing Speaker Placement for Best Sound

All Rockustics speakers can generate a high SPL (sound

pressure level). Be ready to rock, but be considerate of your

neighbors! Maximum acoustic performance should be an

important factor in determining speaker placement. Here is how

to achieve it:

1) Establish where the most likely or average listening

position will be.

2) The speakers should be placed at or close to the same

distance from that point.

3) The actual distance between the listening position and

the location of the speakers is not critical. However, keep

in mind that as the distance between listening area and

speaker is increased, there will be a noticeable decrease

in perceived volume.

4) Be sure to conrm amp power matches the power rating

on the speaker. Over-driving the speaker can lead to

permanent damage that is not covered under warranty.

Diagram BDiagram A

Planter Speakers

INSTALL INSTRUCTIONS

Ultra-Fidelity Outdoor Speakers

Contact: MSE Audio, 855.663.5600 / 913.663.5600 / sales@mseaudio.com

Audio coverage patterns vary depending on the type of speaker

( ):Diagram C

Planter models provide omnidirectional coverage and are

better suited for full 360 degree audio. Use these models on

the interior of your listening area where coverage is required all

around the speaker.

Cautions and Maintenance

All Rockustics speakers are sealed and fully weatherproof.

However, DO NOT place speakers where the speaker will be in

the path of a sprinkler system. Sprinklers typically have a high

water pressure level that can damage speaker cones if hit directly.

(Diagram D) DO NOT place soil or wood chips between the

planter urn and base, where the speaker grille is located. If

the grilles accumulate a build up of soil, the speaker may

become damaged. Accumulated soil may also promote undesired

insect trafc into the speaker. Insects may eat through the

speaker surround. Chemical sprays may also cause damage to the

rubber of the speaker surround. This includes bug spray, deck

sealant, some fertilizers and oil based products. Speakers

MUST be covered when applying these treatments or chemicals

in your yard.

For environments that get snow and ice during the winter

months, be sure to check that the openings and woofer cone

are clear and there is no hard-packed snow or ice built up in

these areas before playing. If there is ice or snow present on

the cone, use a hair dryer set on a low setting to melt it away. If

the speakers are not going to be used during winter months, it

is recommended that they either be disconnected and brought

indoors, or covered with a plastic bag to help protect the

speaker components.

Wiring for 70V/100V Applications

For speakers with transformers, use to nd the propDiagram E -

er wire selection for your desired tap setting. Once the desired

tap setting is conrmed, trim the unused wires to minimize cor-

rosion. For harsh and wet environments, it is recommended to

apply a bead of silicone to the end of the unused wires for added

protection.

If daisy-chaining, follow wire preparations as outlined in the

Basic Wiring & Set Up Diagram Fsection. Review for a typical

daisy-chain wiring system for 70V and 100V applications. Be

sure to connect the wires going to the next speaker in the chain

as shown in . There should be three pairs of wires at Diagram G

each speaker, but the last speaker in the chain will only have

two pair. Follow standard protocol for polarity and make sure all

units are wired with the same polarity.

Diagram C

Planter

Diagram D

Leave Clear

Diagram E

Diagram F

Diagram G
