Side 1/4
System Type
4” coax, open-ceiling, ported (20 W transformer for 25/70.7/100 V or
voice coil direct)
Impedance (Nominal)
1
16 Ω
Sensitivity dB @ 2.83 V / 1 M
82.4 dB
Sensitivity dB @ 1 W / 1 M
85.4 dB
Sensitivity dB @ 1 W / 4 M
70 dB
Frequency Response (±3 dB)
3
140 Hz - 22 kHz
Frequency Response (±10 dB)
100 Hz - 22 kHz
Max. Program Power
4
40 W
Max. Continuous Power RMS
5
20 W
Max. Power SPL @ 1 M
100 dB
Max. SPL @ 4 M
87 dB
Coverage Angle @ ±6 dB
500 Hz: 360° | 1 kHz: 200° | 2 kHz: 100° | 4 kHz: 80°
Coverage Angle (Avg. 2-10 kHz)
115°
Directivity Factor (Q)
2.8 (averaged 100 Hz - 10 kHz) | 5.5 (2 kHz)
Directivity Index (DI)
4.4 dB (averaged 100 Hz - 10 kHz) | 7.4 dB (2 kHz)
Tap Selector
6 position rotary switch with transformer bypass
Transducer: Low-Frequency Driver
102 mm (4”) polypropylene cone, butyl rubber surround
Transducer: High-Frequency Driver
19 mm (0.75”) silk dome with BroadBeam Ring
™
Low-Frequency Voice Coil
25.4 mm | 1”
Crossover Frequency
4.5 kHz
Network Type: Low Pass
12 dB per octave, 2nd order
Network Type: High Pass
6 dB per octave, 1st order
Enclosure Material
Injection molded ABS, glass fiber reinforced
Grille
Powder-coated aluminum
Inputs
4-position ceramic terminal connector
Colors
Black or white (paintable)
Height
199.6 mm | 7.9”
Diameter
189.5 mm | 7.5”
Weight
1.4 kg | 3.1 lbs
Packaging
One per box
Included Accessories
Hanging hardware, weather plug, cover plate
Certications
CE, EN54, RoHS, UL 1480A
Description
The RS42-EZ is a 4”, coaxial speaker designed
for open-ceiling applications. Hanging hardware
is included and features built-in hanging bracket
and screw on cover plate for fast, easy, and secure
installation. The unit may be mounted direct-to-
conduit via the locking cover plate (see installation
instructions for additional information). The RS42-EZ
speaker incorporates 4-position ceramic terminal
block input connector and a 6-position tap switch with
transformer bypass position.
Features
• One 4” (102 mm) coaxial driver with BroadBeam
Ring
™
technology for consistently smooth high-
frequency directivity.
• Weatherized components for indoor and outdoor
applications.
• Includes hanging hardware with galvanized steel
cables and hanging bracket for fast, easy,
and secure installation. Unit may be hung or
mounted direct-to-conduit via locking cover
plate.
• Enclosure constructed of injection molded ABS
with glass ber reinforcement for lasting
durability in indoor or outdoor applications.
• 16 Ω impedance for easy daisy chaining in low
voltage systems
• Aluminum grille with protective powder-coated
nish.
• Built-in thermal fuse.
• Unit ships in eco-friendly, recyclable packaging.
• UL 1480A
• High-quality black or white paint nish. Speaker is
paintable.
• Included accessories: hanging hardware, weather
plug, cover plate.
Impedance listed per IEC 60268-5
1 W/1 M sensitivity determined using nominal impedance
Frequency response measured in half or full space as dictated
by speaker mounting conguration
Max program power is 3 dB above max continuous power
Continuous power rating, EIA-426-B test
Max output based on max continuous power
The specications data was measured in an anechoic
chamber, according to EN 54-24.
Reference axis: Axis is on the center of speaker grille
and perpendicular to the speaker grille.
Reference plane: Plane is on the speaker grille and
perpendicular to the reference axis.
Horizontal plane: Plane is containing the reference
axis and perpendicular to the reference plane.
RS42-EZ PRODUCT SPECIFICATIONS
RS42-EZ
Open-Ceiling Speaker
standards using EASERA, TEF and MLSSA. Full balloon data including both
phase and magnitude is compiled into a variety of formats including EASE
4.x, GLL and CLF.
Architectural Specifications
The loudspeaker shall consist of one 102 mm (4”) low-frequency driver
and one 19 mm (0.75”) high-frequency driver. The low-frequency voice coil
diameter shall be 25.4 mm (1”).
Performance specications of a typical production unit shall be as follows:
usable frequency response shall extend from 100 Hz - 22 kHz (±10 dB).
Measured in sensitivity (2.83 V input, 1 M) shall be at least 82.4 dB. The
speaker shall have a nominal impedance of 16 Ω. The speaker shall be
available for 25, 70.7, and 100 V modes and shall include a six-position tap
switch with a transformer bypass position. Rated power capacity shall be at
least 20 W continuous (RMS) and conform to EIA-426-B testing. Maximum
continuous output at 1 M shall be 100 dB.
The low-frequency transducer shall have a polypropylene cone with a butyl
rubber surround. The high-frequency transducer shall have a silk dome
tweeter with BroadBeam Ring™ technology.
Installation shall be by galvanized steel cable attached to the speaker
chassis via xed cable end that interlocks with integrated mounting bracket.
The external wiring input connector shall be a four-position ceramic terminal
block for low impedance or distributed systems and shall accept from 10 -
22-gauge wire. The system shall be for indoor and outdoor applications and
shall have a weather-resistant plug protecting all wire connectors inside the
cover plate.
The enclosure shall be constructed of injection-molded ABS. The grille shall
be constructed of powder-coated aluminum for lasting performance in the
elements. Overall cabinet dimensions shall be no more than 199.6 mm
(7.9”) in height by 189.5 mm (7.5”) in diameter. The unit shall weigh no
more than 1.4 kg (3.1 lbs) and shall include hanging hardware and weather-
resistant cover plate plug.
The system shall be the SoundTube RS42-EZ with hanging hardware for
both low and high impedance applications.
SoundTube
®
13720 W. 109th St.
Lenexa, KS 66215
Phone: 913.663.5600
Fax: 913.663.3200
Toll Free: 855.663.5600
www.mseaudio.com
All SoundTube speakers come with a 5-year limited warranty and 3-year
warranty on all electronics.
Applications
Designed for superior off-axis performance and easy installation, the
RS42-EZ offers attractive styling in an economical speaker for open-ceiling
uses. The RS42-EZ includes hanging cables and a built-in mounting plate
for suspending the speaker and a threaded opening to top of its cover
plate for direct-to-conduit mounting. Cost-effective engineering with high-
performance sound makes the RS42-EZ speaker ideal for music and paging
applications in retail, grocery stores, restaurants, hotels, casinos, museums,
trade shows, and conference rooms. For applications where additional bass
is required, SoundTube’s RS1201i-II-T 10” subwoofer may be used.
Patented Technologies
SoundTube Entertainment and the MSE Audio Group constantly develop
new technologies which enhance audio product performance. SoundTube
Entertainment innovations are protected by multiple U.S. and international
patents, which explicitly cover SoundTube dome, enclosure and dispersion
technologies. The MSE Audio Group actively defends its patents in order to
protect SoundTube resellers and end-users.
Technical Data and Specification Tools
SoundTube Entertainment strives to provide complete and effective technical
information and data to dealers, engineers and designers. All data is
available from SoundTube Entertainment or at www.soundtube.com.
Technical data and downloads include:
• EASE
™
data - 3-D polar plots.
• EASE
™
Address - 2-D modeling for distributed systems
• AutoDesk
®
Revit
®
software
• Tech Sheets - technical information and architectural specs for system
engineers
• SoundTubeSPEC
™
- Proprietary speaker placement software
Independent Data Acquisition and Verification
All data for SoundTube speakers is independently collected from and veried
by NWAA Labs (www.nwaalabs.com) using their proprietary MACH testing
system. All data is collected and analyzed according to ASTM, ISO and AES
RS42-EZ
Open-Ceiling Speaker
Transformer Taps
70.7 V 100 V 25 VOutput Output Output
20 W
100 dB
218 Ω
20 W
100 dB
459 Ω
2.5 W
91 dB
218 Ω
10 W
97 dB
459 Ω
10 W
97 dB
926 Ω
1.3 W
88 dB
459 Ω
5 W
94 dB
926 Ω
5 W
94 dB
1815 Ω
0.63 W
85 dB
926 Ω
2.5 W
91 dB
1815 Ω
2.5 W
91 dB
3397 Ω
0.31 W
82 dB
1815 Ω
1.3 W
88 dB
3397 Ω
