Thank you for purchasing the Phase Technology TEATRO

TSB3.0 soundbar.

This high-denition LCR soundbar incorporates PhaseTech’s exclusive

Enhanced Voice Technology (EVT

™

) circuitry and Spatial Field Expanders

(SFE

™

) to provide outstanding dialogue clarity along with an open, wide sound

stage.

The TEATRO

TSB-3.0 soundbar speaker is a an ultra thin design made to

t seamlessly under a at panel TV. Both table top and wall mounting options

are included with the product. For on-wall applications, the mounting bracket

has adjustments for lining up and vertically leveling the speaker with the TV.

The soundbar cabinet also has threaded inserts for mounting the TSB3.0 to a

display wall bracket mechanism.

Note: please check with the display mount manufacturer for compatibility and

ensure the display mount will support a 12 pound soundbar.

Regardless of application, serious audiophile listening or home theater, we

recommend that you take the time to read this manual thoroughly before

connecting speakers to your amplier or receiver. In the highly unlikely event

that you should experience a problem with set-up or operation, please contact

one of our authorized dealers for assistance, or contact us directly.

Phase Technology Corporation

8005 W. 110th St., Suite 208

Overland Park, KS 66210

855.663.5600 (Domestic)

+1.913.663.5600 (International)

Fax: 913.663.3200

SAFETY INSTRUCTIONS 2

MOUNTING INSTRUCTIONS 3

WALL MOUNTING 3

TABLE TOP MOUNTING 4

CARING FOR YOUR SPEAKERS 5

MAINTENANCE AND SERVICE 5

TROUBLESHOOTING 5

WARRANTY 5

SPECIFICATIONS 5

CAUTION: BE VERY CAREFUL NOT TO DAMAGE THE MIDRANGE DOMES OR SFE [SPATIAL FIELD EXPANDERS

™

] DRIVERS LOCATED

ON THE SIDE OF THE CABINET WHILE HANDLING THE SOUNDBAR.

2. Mounting Bracket x2

1. TEATRO

TSB3.0

3. Mounting Pin x2

4. Leveling Screw x2

5. Table Top Mounting Feet x2

6. Table Top Mounting Feet Screws x4

7. Table Top Mounting Screws x2

8. Euroblock Connectors x3

[INCLUDED IN THE BOX]

OFFO N

EVT

TEATRO

OWNER’S MANUAL: TSB3.0

1. Read Instructions - All the safety and operating instructions should be

read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should be

retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating

instructions should be adhered to.

4. Follow Instructions - All operating and other instructions should be

followed.

5. Water and Moisture - The appliance should not be used near water -

for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet

basement, or near a swimming pool, etc.

6. Carts and Stands - The appliance should be used only with a cart or

stand that is recommended by the manufacturer.

PORTABLE CART WARNING

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall

or ceiling only as recommended by the manufacturer.

[SAFETY INSTRUCTIONS]

8. Ventilation - The appliance should be situated so that its location or

position does not interfere with its proper ventilation. For example, the

appliance should not be situated on a bed, sofa, rug, or similar surface

that may block the ventilation openings; or placed in a built-in installation,

such as a bookcase or cabinet that may impede the ow of air through the

ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as

radiators, stoves, or other appliances that produce heat.

10. Power Source - The appliance should be connected to a power supply

only of the type described in the operating instructions or as marked on the

appliance.

11. Power Cord Protection - Power supply cords should be routed so

that they are not likely to be walked on or pinched by items placed up or

against them, paying particular attention to cords at plugs, convenience

receptacles, and the point where they exit from the appliance.

12. Cleaning - The appliance should be cleaned only as recommended by

the manufacturer.

13. Nonuse Periods - The power cord of the appliance should be unplugged

from the outlet when left unused for a long period of time.

14. Object and Liquid Entry - Care should be taken so that neither objects

fall nor liquids spill into the inside of the appliance.

15. Damage Requiring Service - The application should be serviced by

qualied service personnel when:

a. the power supply cord or the plug has been damaged,

b. objects have fallen onto or liquid has been spilled into the appliance,

c. the appliance has been exposed to rain,

d. the appliance does not appear to operate normally or exhibits a marked

change in performance, or

e. the appliance has been dropped or the cabinet damaged.

16. Servicing - The user should not attempt to service the appliance

beyond those means described in the operating instructions. All other

servicing should be referred to qualied service personnel.

17. Grounding or Polarization - Precautions should be taken so that the

grounding or polarization means of an appliance is not defeated.

Explanation of Graphical Symbols

The lightning ash with arrowhead symbol, within an

equilateral triangle, is intended to alert you to the presence

of un-insulated “dangerous voltage: within the product’s

enclosure that may be off sufcient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert you to the presence of important operating

and maintenance (servicing) instructions in the literature

accompanying the appliance.

APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR

USAGE

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

PLUG TO WIDE SLOT, INSERT FULLY.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE

LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE

CORRESPONDANTE DE LA PRESE ET POUSSER JUSQU AU FOND.

CAUTION: To reduce the risk of electric shock, do not remove cover

(or back). No user-serviceable parts inside. Refer servicing to qualied

service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

“Speakers for your Life” is a trademark of MSE Audio, Overland Park, Kansas USA. Phase Technology is part of MSE Audio

. www.phasetech.com.
