SBPMJ Parapet Mount Bracket Installaon Instrucons

Box Contents:

1 Parapet Mount and Base

1 PC x Hex Wrench for Seng Screws

6 Sets x Mounng Bolts with Expansion Anchors 63mm±0.5mm (Total Length)

9 PCS x Seng Screws Ø 6mm±0.2mm

Note: The mount shou be installed on a flat and sturdy surface. The installaon surface ld

should be capable of withstanding heavy winds and at least 3 mes the total weight of the

camera being installed.

1. Start by marking off holes in which you want to posion the mount.

2. Drill a hole in the base material with a hammer drill and a correctly sized carbide drill

bit for the anchor. See gure A.

3. Using the proper diameter and use bit, drill holes for the expansion bolts. The depth

of the hole should accommodate the length of the bolt up to the shim.

4. Clean out the hole of all debris.

5. Insert th Expansion Anchor Sleeve with bolt into the hole and ensure the sleeve is e

ush with the surface. See gure B.

6. See the mount base over the single expansion anchor, insert at washer, locking washer

and then tighten the nut of the expansion bolt. The anchor of the bolt will expand

inside the hole and lock into place. Do this for all 6 expansion bolts. See Figure C.

7. Make the camera connecons through the hollow arm and mount the camera to the

arm using the mounng collar and set screws.

8. Insert the arm to the base and use locking screws included to lock this arm in place.

① mounng holes for Metal Plate

② seng holes to x Metal Plate and Tube

Dimensions:

Tolerance ±3mm

Instrucons and specicaons are subject to change without noce.
