Wiring Tools

User’s Guide

StarTech.com has the tools you need to get any cable job finished,

including the DUCTCUTTER, our sharp solution for cutting through,

you guessed it, plastic wiring ducts. This StarTech.com tool is specially

designed for manipulating RJ-45 and RJ-11 connectors and saves

valuable time and effort on any related cable job.

RJ45 and RJ11 Strip & Crimp Tool

RJ4511TOOL

Lock

Stripper

Cutter

Handles

Safety

Modular Plug

Holder for 6

Position Use

Modular Plug

Holder for 8

Position Use

1. Hold the RJ4511TOOL with “Safety” side towards you.

Insert the cable you wish to cut in the cutter section of the

tool. Squeeze handles together to cut the wire.

2. Take the newly cut end and place it in the stripper

section of the tool. For a longer strip to remove place the

end of the cable at the backstop, for a shorter strip place it

at the tab. Squeeze handles together and release slightly.

Pull off the stripped insulation.

3. Insert the cable and outer jack into the appropriate

modular plug holder. Squeeze handles firmly. Release and

remove the terminated plug.

Openning the Tool: Squeeze hanle firmly. The lock will

release. The tool is now ready to be used.

Locking the Tool: Squeeze handles together with one

hand. Push the lock in with the other hand and release the

handles. The tool is now secured.

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Tang
Model:	RJ4511TOOL
Pakkevægt:	343 g
Pakkedybde:	76 mm
Pakkebredde:	207 mm
Pakkehøjde:	27 mm
Kabeltype:	RJ45, RJ11
