Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

I T: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

P T: Guia do usuário - pt.startech.com

Manual Revision: 09/10/2013

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x HDD Dock

• 1x USB 3.0 Cable

• 1x Instruction Manual

• 1x Universal Power Adapter

• 3x Power Cords (NA/UK/EU)

System Requirements

• USB enabled computer system with available USB port

• Available AC electrical outlet

• Microsoft® Windows® XP/ Server 2003/ Vista/ Server 2008 R2/ 7/ 8

(32/64-bit), or Apple® Mac OS® X, or Linux®

SDOCKU33HW / SDOCKU33HB

USB 3.0 to 2.5/3.5in SATA HDD Dock with USB Hub

*actual product may vary from photos

USB Hub

Port 1

Power

Switch

Power

Adapter

Port

USB 3.0

Port

USB Hub

Port 3

Power

Management

Switch

USB Hub

Port 2 / Fast

Charging

Port

Charge

Switch

Hard Drive

Slot

WARNING! Hard drives and storage docks require careful handling,

especially when being transported. If you are not careful with

your hard disk, lost data may result. Always handle your hard drive

and storage device with caution. Be sure that you are properly

grounded by wearing an anti-static strap when handling computer

components or discharge yourself of any static electricity build-up

by touching a large grounded metal surface (such as the computer

case) for several seconds.

Hardware Installation

1. Ensure the power switch is set in the o position. Connect the

included power adapter from an available AC power outlet to the

Power Adapter Port on the back of the SDOCKU33HW/B.

2. Connect the included USB 3.0 cable from the USB Port 3.0 port on

the SDOCKU33HW/B your computer system.

3. Connect the 2.5” or 3.5” HDD you would like to dock into the Hard

Drive Docking Port.

4. Press the power switch to the “On” position, the SDOCKU33HW/B

is now ready to use.

Hardware Operation

Hard Drive Docking Station

SDOCKU33HW/B Once the docking station has been attached to a

computer, and the necessary software will automatically install and

the docked hard drives will be accessible as though it were installed

within the system.

USB 3.0 Hub

The included USB hub allows you to connect up to 3 additional

USB 3.0 (backward compatible with USB 2.0/1.1) devices to your

computer system through the SDOCKU33HW/B.

NOTE: The USB Hub will remain active and powered even if the Hard

Drive Dock is turned o.

USB Charging Port

The USB Hub Port 2/Charging Port (front right port) is a battery

charging port capable of providing up to 5 volts, 2 amps to any USB

mobile device connected through the port. This allows for devices

to charge faster than they typically would through a standard USB

3.0 port. The Port also allows for data communication at the

same time.

NOTE: Certain devices may not support charging and syncing

simultaneously. In these instances disconnect the device, and set

the charge only switch to “on”, then reconnect the device.

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Vugge/dockingstation
Model:	SDOCKU33HB
Vekselstrømsindgangsspænding:	100-240 V
Bredde:	130 mm
Dybde:	72 mm
Højde:	55 mm
Vægt:	350 g
Brugervejledning:	Ja
Produktfarve:	Sort, sølv
Pakkevægt:	962.75 g
Pakkedybde:	163 mm
Pakkebredde:	92 mm
Pakkehøjde:	173 mm
Opbevaringstemperatur (T-T):	-20 - 50 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Driftstemperatur (T-T):	5 - 35 °C
Kabler inkluderet:	AC, USB
Materiale:	Aluminium, Plastic
LED-indikatorer:	Activity, Power
Udgangsspænding:	12 V
Udgangsstrøm:	3 A
AC-adapter inkluderet:	Ja
Understøttede Windows-operativsystemer:	Windows 7 Home Basic, Windows 8, Windows Vista Home Basic, Windows XP Home
Understøttede Mac-operativsystemer:	Ja
Understøttede Linux-operativsystemer:	Ja
Maksimal dataoverførselshastighed:	5 Gbit/sek.
Standard grænseflader:	USB 3.2 Gen 1 (3.1 Gen 1)
Indgangsstrøm:	1 A
Opbevaringsmedietype:	HDD, SSD
Grænseflade til lagerdisk:	Serial ATA, Serial ATA II, Serial ATA III
Antal understøttede lagerdiske:	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) -porte:	4
Maksimal lagerkapacitet:	4 TB
Understøttede lagerdisk størrelser:	2.5, 3.5 "
Chipsæt:	VIA812+ASM1053E
