Universal Intel P4/AMD Athlon

Heatsink and Fan

UNIVERSALHSF

Thank you for purchasing a Universal Intel

P4/AMD Athlon heatsink with fan.

Designed to fit a wide range of Intel and

AMD processors, this extra-large heat sink

and 7cm ball bearing fan provides maximum

heat dissipation for your hard-working

CPU. The UV-reactive fan looks great in

modded cases and offers 27.9 CFM of

airflow.

The UNIVERSALHSF is designed

for the following processors:

• Intel P4 3.2 GHz

• Intel PIII

• AMD Athlon XP 3000+

• AMD K7 and K8

Note: For maximum efficiency, use the included thermal compound with your

UNIVERSALHSF.

Warning! Remove the protective plastic cover from the bottom

of the heatsink before installation.

Technical Specifications

AMD K8 (Athlon 64)

1. Release the screws from the

plastic plates on the bottom of the

heatsink and remove the plates.

2. Attach the diamond-shaped plastic

plate to the bottom of the

motherboard.

3. Fasten the other plastic retention

plate to your motherboard using

screws.

4. Hook the clip to the retention

plate from one side.

5. Connect the power wire to a

power source on your

motherboard.

6. Installation is now complete.

The Professionals’ Source For Hard-to-Find Computer Parts

Processor Compatibility Intel P4 3.2GHz (Socket 478), Intel PIII (Socket 70),

AMD Athlon XP 3000+, AMD Athlon K8,

AMD Athlon K7 (Socket 462)

Heatsink Dimensions 3.3 x 2.9 x 1.7” (84 x 74 x 42 mm)

Fan Dimensions 70 x 70 x 15 mm

Fan Speed 3500 RPM

Power Consumption 2.1 Watts (0.18A)

Airflow 27.9 CFM

Noise 28 dBA

Weight 0.71 lbs (0.32 kg.)

Safety Standard CE

AMD K7 (Socket 462) and PIII (Socket 370)

1. Release the screws from the plastic plates

on the bottom of the heatsink and remove

the plates.

2. Remove the fan from the heatsink by

releasing the two clips on either side of

the fan.

3. Remove the existing clip and replace

it with the clips for K7/PIII.

4. Reattach the fan to the heatsink.

5. Apply an appropriate amount of

thermal compound to your CPU.

6. Attach the cooler to the motherboard,

making sure the cooler is sitting flat

and attached securely.

7. Connect the power wire to a power

source on your motherboard. 8. Installation is now complete.

Pentium 4 (Socket 478)

1. Release the screws from the plastic

plates on the bottom of the heatsink and

remove the plates.

2. Remove the fan from the heatsink by

releasing the two clips on either side of

the fan.

3. Remove the existing clip. 4. Reattach the fan to the heatsink.

5. Apply an appropriate amount of

thermal compound to your CPU.

6. Attach the cooler to the motherboard,

making sure the cooler is sitting flat

and attached securely.

7. Connect the power wire to a power

source on your motherboard. 8. Installation is now complete.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of busi-

ness, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some

states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclu-

sions contained in this statement may not apply to you.

Call StarTech.com tech support for help. Support hours: Monday to Friday 8:30AM to 6:00PM EST (except holidays)

USA/Canada: UK/Ireland/Europe: 1-800-265-1844 00-800-7827-8324
