Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 02/10/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1 x VS421DP video switch

• 1 x IR Remote Control

• 1 x Power Adapter

• 1 x Installation Guide

System Requirements

• DisplayPort enabled display device (i.e. monitor/projector/etc.)

• DisplayPort enabled video sources (i.e. computer systems)

• Available power outlet

VS421DP

4 Port DisplayPort Video Switch w/ Audio & IR Remote Control

*actual product may vary from photos

Installation

1. Make sure all devices are turned o before beginning the

installation.

2. Connect a DisplayPort cable from the “Out” connector on the

switch to the DisplayPort enabled display device.

Connect a DisplayPort cable from up to four dierent DisplayPort

video sources to each of the inputs (1 ~ 4) on the switch.

3. Connect the power adapter from an electrical outlet to the switch.

The port 1 Selection LED should light up to indicate the currently

active input.

4. Power on the display device, followed by the video source on port

5. Once video output is conrmed, switch to the next port by

pressing the switching button and power up the next video

source. Repeat this process for each video source.

6. To switch between the inputs on the switch, the front panel

button or the IR remote control can be used.

Specications

Bus Interface DisplayPort revision 1.1

Number of Ports 4

Connectors

5 x DisplayPort

1 x DC Power

LEDs 4 x Selection Indicator

Maximum Video Resolution 2560x1600@60Hz

Maximum Cable Length 10m / 33ft

Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)

Humidity 0 ~ 80% RH

Power Adapter 5VDC, 2A, center positive

Dimensions 131.0mm x 65.0mm x 26.0mm

Weight 500g

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Audio/video konverter
Model:	VS421DP
Vægt:	500 g
Brugervejledning:	Ja
Produktfarve:	Hvid
Pakkevægt:	600 g
Pakkedybde:	270 mm
Pakkebredde:	186 mm
Pakkehøjde:	80 mm
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 80 %
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	2560 x 1600 pixel
Indgangsspænding for vekselstrømsadapter:	110 - 240 V
Udgangsspænding for vekselstrømsadapter:	5 V
Dimensioner (BxDxH):	131 x 65 x 26 mm
Materiale:	Aluminium
Fjernbetjening inkluderet:	Ja
DC-in-stik:	Ja
LED-indikatorer:	Ja
AC-adapter inkluderet:	Ja
Bæredygtighedscertifikater:	RoHS
Antal DisplayPorts:	4
Vekselstrømsadapterens udgangsstrøm:	2 A
Strømstiktype:	Type M
Fjernbetjeningstype:	IR
DC indgang:	5V
Video porttype:	DisplayPort
Antal videoporte:	4
Understøttelse af lyd:	Ja
