Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions mentioned
herein.
Microphone WMic-TS
User Manual
Caring For Your SYNCO Product
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
Transmitter
Receiver
Screen Display
Product Instruction
Specications
Transmitter (TX)
Receiver (RX)
① 3.5mm Mic Input
② IR Indicator
③ Built-in Mic
④ Function Selection Button △
⑤ Function Selection Button ▽
⑥ OLED Screen
① 3.5mm Audio Output Socket
② IR Indicator
③ 3.5mm Audio Monitoring Socket
④ Function Selection Button △
⑤ Function Selection Button ▽
⑥ OLED Screen
⑦ Menu
⑧ Power Button
⑨ Antenna
⑩ Belt Clip
⑪ Type-C Port
⑫ Reset (Help with Eject Pin)
⑦ Menu
⑧ Power Button
⑨ Antenna
⑩ Belt Clip
⑪ Type-C Port
⑫ Reset (Help with Eject Pin)
Channels
Group A Wireless Frequency
Group B Wireless Frequency
Working Distance
Latency
RF Output Power
Stray Radiation
Input
Low-cut Filter
Battery
Working Time
Charging Time
Antenna
Dimensions
Weight
Operating Temperature
Storage Temperature
60
525.000MHz~539.750MHz
540.000MHz~554.750MHz
150m (LOS), 80m (NLOS)
＜20ms
15dBm
<-60dBc
Built-in Mic/External Mic
100Hz
1300mAh Rechargeable Li-ion Battery
8.5H
3H
PCB Antenna
75.5×64×21.5mm
62g
-20℃~70℃
-20℃~70℃
◆
Transmitter (TX)
Signal Strength High
Group A
Group B
Muting
Normal Recording
Muting（Locking）
Muting（Unlocking）
Power Indicator
Audio Dynamic Display Bar Channel Frequency
Signal Strength Low
Group A/B
Channel
Group A Signal Strength
Display Bar
Group B Signal Strength
Display Bar
Power Indicator
Group A Receiving Audio
Status Indicator
Group B Receiving
Audio Status Indicator
Group A
Frequency
Group BChannel of Group A
Group A Transmitter Power
Group B Transmitter
Power
Channel of Group B
Frequency
Please unfold the TX & RX antennas when using for optimal performance.
