Digalox DPM72-MPPA

Instruction manual (Rev-2020-09)

Graphical panel meter with RGB backlight for analogue signal 2 × 0/4 - 20 mA

Package contents: Panel meter Digalox DPM72-MPPA, mounting bracket,

5 jumpers, 2 instruction manuals (EN + DE)

1. Safety instructions

•Read instruction manual carefully before operating the device! Keep for later

reference.

•Mounting and installation must be carried out by suitably qualified and competent

persons only.

•When working on the device hazardous voltages must not be connected to

the device! The terminals J1-J12 are not isolated from the measuring

circuit.

•The device must not be used as the only protective device or protective

shutdown.

•The device is not intended to protect persons or facilities against harm. Specific

devices must be used to guarantee safety (protection relays, cut-off switches,

etc.).

•When connecting switches to the terminals J1-J6, only switches must be used

whose isolation voltage is at least twice the maximum occurring measurement

voltage. For example, when measuring 30;V DC switches must be isolated for at

least 60;V.

•Do not open the housing!

•Do not use the device in the presence of explosive or flammable substances!

•All cables carrying hazardous voltages must be secured with external separators.

2. Meaning of symbols

General warning sign

(Attention, observe the documentation!)

Warning of an electrical hazard

----- ----- 1 / 8

3. Intended use

•Measurement of current in the specified measuring range for process signals

•Indoor use non condensing, non corrosive.

•Panel mounting.

•In operation, supply the device preferably via screw terminals with 12 to 24;V

AC/DC. If the device is supplied via USB in operation, USB supply voltage must

be at least 5;V.

•Failure to comply with these instructions will void all guarantee and warranty.

4. Description

The measurement mode analogue signal 0/4 to 20 mA DC is supported at two

measurement inputs. The multi display with RGB backlight is able to display up to

four parameters simultaneously. Thresholds can be associated with individual

warning colours. The unit can be switched between measurement modes via an

external switch. Minimum and maximum values are recorded and can be displayed

and reset via jumper or an external switch. Measured values are recorded over a

timespan of 36 seconds up to 14 days. The timebase as well as the display of the

measuring history can be activated by an external switch. The measured values

remain stored as long as the device is supplied with voltage.

The following parameters can be adjusted using the configuration software “Digalox

Manager”: scale endpoint, scale caption, display style (pointer, tachometer, bar

graph, and more), splash image, backlight colour, thresholds for alarm output,

threshold warning colour (light, blink), hysteresis, and more. Recorded

measurement values can be read and a continuous transmission of the actual

measuring value can be enabled. Using the software, values can be viewed and

exported as CSV. Depending on the model, measured values can be transmitted via

USB, XBEE radio technology or RS485 Modbus interface. In addition, the devices

feature a counting function with data retention. This enables operating-hours-

counters or time-counters for exceeding and falling below threshold values.

Visit to download the software “Digalox Manager”.www.digalox.com
