Quick Installation Guide

AX1800 Dual-Band Wi-Fi 6 VDSL/ADSL Modem Router

Archer VX1800v

Connect your analog phone to the port on the modem router's PHONE

back panel.

Connect the modem router to

the DSL splitter.

Modem Router

Connect the DSL splitter to the phone jack.

Note: If you won’t use the traditional landline phone service, you

can directly connect the modem router to the phone jack.

DSL Splitter

Phone Jack

PHONE MODEM

LINE

Push in to turn on the

modem router.

Attach the antennas.

Wait about 1 minute until the DSL LED

turns solid on.

please wait a little longer. If the DSL LED still does

not turn solid on, please refer to Q3 of the FAQ.

Power Adapter

Note: If the DSL LED is still ashing after one minute,

Set up the Modem Router

Connect the Phone

ON/OFF

PHONE

7106510218

Q1. What should I do if I cannot access the web management page?

Q2. What should I do if I cannot access the internet?

http://tplinkmodem.net http://192.168.1.1 or

Q3. What should I do if the DSL LED does not turn solid on?

Q4. What should I do if I forget my password?

For the web management page:

For the Wi-Fi network:

Basic > Wireless

Q5. How do I restore the modem router to its factory default settings?

Advanced > System

Tools > Backup & Restore

Before You Start

Safety Information

Most internet service providers (ISPs) will provide a username and password for their service when you first sign up with them. If you are unsure, please check with your ISP.

If you are using telephony function, you’ll need to register your phone number on the modem router. Please find your phone information before continuing.

Congure the Modem Router

LEDs

Quick Flashing

Flashing

On (Green)

On (Orange)

O

Flashing

Status Indication

LAN

Internet

Wireless

DSL

Phone

LED

System initialization is complete.

WPS connection is in progress (about 2 minutes).

The system is initializing or the rmware is being upgraded.

Do not disconnect or power o the modem router.

Slow Flashing

Power is o.

Power

The phone is o-hook.

The phone is on-hook.

The phone is ringing.

The 2.4GHz/5GHz wireless radio band is enabled.

DSL/WAN port is connected but internet service is unavailable.

Internet connection is incorrect, DSL synchronization failed,

or the modem router is operating in Bridge mode.

The 2.4GHz/5GHz wireless radio band is disabled.

For technical support, replacement services, user guides, and other information,

please visit https://www.tp-link.com/support, or simply scan the QR code.

To enjoy a more complete service from TP-Link, bind your TP-Link ID to the

router.

1. Connect your device to the router wirelessly or with an Ethernet cable.

3. Follow the step-by-step instructions to set up the internet connection,

Let’s Get Started

http://tplinkmodem.net

Method TWO: Via a Web Browser

2. Launch a web browser, and enter http://tplinkmodem.net or

http://192.168.1.1 in the address bar. Create a password to log in.

Note: If the login window does not appear, please refer to in this guide.Q1 of Need Help?

Method ONE: Via TP-Link Tether App

1. Download the Tether app.

Scan for Tether Tether

2. Open the Tether app and log in with your TP-Link ID.

3. Tap the button in the Tether app and select DSL Modem Router. Follow

the steps to complete the setup and connect to the internet.

Note: If you don’t have an account, create one first.

The default wireless network names (SSIDs) and password are printed on the label at the

bottom of the router.

Model: Archer AX3000

Wireless Password/PIN:XXXXXXXX

SSID:TP-Link_XX XX

SSID:TP-Link_XX XX_5G

Connect an Ethernet cable (RJ45) from your ber or cable modem to the WAN

port of the modem router to use it as a wireless router. Refer to the User Guide

for wireless router conguration.

The USB port can be used for le and media sharing, both locally over your home

network and remotely over the internet using the modem router’s built-in FTP

server capability.

Connect a 3G/4G USB mobile broadband modem to the router’s USB port to

get wireless internet access through 3G/4G mobile networks. The USB dongle

can be congured as a backup to enhance network reliability. Refer to the User

Guide for instructions.

Features

Ethernet WAN Connection

3G/4G Connectivity

USB Features

Choose Your Device Type

Gaming Router

Range Extender

DSL Modem Router

Wireless Router

Produkt Specifikationer

Mærke:	TP-Link
Kategori:	Router
Model:	Archer VX1800v
Bredde:	260.2 mm
Dybde:	135 mm
Højde:	41.6 mm
Produktfarve:	Sort
Produkttype:	Bordplade router
USB-port:	Ja
Opbevaringstemperatur (T-T):	-40 - 60 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 90 %
Ethernet LAN-porte (RJ-45):	4
Antal USB 2.0-porte:	1
Ethernet LAN:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Forældrekontrol:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Sikkerhedsalgoritmer:	WPA-Enterprise, WPA-PSK, WPA-Personal, WPA2-Enterprise, WPA2-PSK, WPA2-Personal, WPA3
Hurtig start guide:	Ja
Kabler inkluderet:	LAN (RJ-45), Phone (RJ-11)
Pakketype:	Kasse
Ethernet WAN:	Ja
DSL WAN:	Ja
SIM-kort slot:	Ingen
3G/4G kompatibilitet USB-modem:	Ingen
WAN forbindelsestype:	RJ-11/RJ-45
Wi-Fi-bånd:	Dual-band (2,4 GHz / 5 GHz)
Bedste Wi-Fi standard:	Wi-Fi 6E (802.11ax)
WLAN dataoverførselshastighed (maks):	1800 Mbit/s
WLAN dataoverførselshastighed (første bånd):	574 Mbit/s
WLAN dataoverførselshastighed (anden bånd):	1201 Mbit/s
Ethernet LAN-grænsefladetype:	Gigabit Ethernet
Kabelteknologi:	10/100/1000Base-T(X)
Netværksstandarder:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN-support:	OpenVPN, PPTP VPN, IPSec VPN
Portvideresendelse:	Ja
DC-in-stik:	Ja
DHCP-klient:	Ja
DHCP-server:	Ja
Universal Plug and Play (UPnP):	Ja
Antennedesign:	Ekstern
Antenner, antal:	4
Webbaseret administration:	Ja
Knap til nulstilling:	Ja
WPS trykknap:	Ja
LED-indikatorer:	LAN, Power, WAN
Kan monteres på væggen:	Ja
Strømkilde type:	DC
AC-adapter inkluderet:	Ja
Bæredygtighedscertifikater:	CE, RoHS
Overholdelse af bæredygtighed:	Ja
Antal produkter inkluderet:	1 stk
MIMO:	Ja
Antal RJ-11-porte:	2
ADSL:	Ja
Adgangskontrolliste (ACL):	Ja
Dynamisk DNS (DDNS):	Ja
Understøttelse af DMZ:	Ja
ADSL2:	Ja
VDSL2:	Ja
Automatisk kanalvalg:	Ja
Antal gæstenetværk (2,4 GHz):	1
Antal gæstenetværk (5 GHz):	1
Antal VPN-tunneler:	10
Statisk rute:	Ja
MU-MIMO-teknologi:	Ja
ADSL2 +:	Ja
Port udløsning:	Ja
