Owner’s Manual

4-Port KVM Switch

with Audio, OSD

& Peripheral Sharing

Model: B006-VUA4-K-R

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

17-10-468-932947-EN.indd 1 11/17/2017 3:05:47 PM

Table of Contents

Package Contents .................................................................................................................2

Console Requirements .........................................................................................................2

Computer Requirements ......................................................................................................3

Supported Operating Systems ..............................................................................................3

Features ................................................................................................................................3

Hardware Setup ....................................................................................................................6

Rackmount Installation ........................................................................................................7

System Installation ...............................................................................................................7

Basic Operation ....................................................................................................................8

Port Switching ......................................................................................................................9

Manual Push-Buttons ...........................................................................................................9

Mouse Port Switching Functionality .................................................................................10

Hotkeys ..............................................................................................................................10

OSD ....................................................................................................................................16

OSD Operation ...................................................................................................................16

OSD Main Screen ..............................................................................................................16

OSD Main Page Functionality ...........................................................................................17

OSD Settings Page Functionality .......................................................................................19

Firmware Upgrade Utility ..................................................................................................22

Appendix ............................................................................................................................24

Warranty & Product Registration .......................................................................................27

Package Contents

• B006-VUA4-K-R KVM Switch

• (4) USB KVM Cable Kits

• USB to (x2) PS/2 Adapter Cable

• Firmware Upgrade Cable

• External Power Supply (Input: 100-240V, 0.5A, 50/60Hz Output: 5.3V, 2.4A)

• Owner’s Manual

Console Requirements

• VGA, SVGA, or Multisync monitor capable of supporting the highest resolution out of

any computer in the installation

• USB or PS/2* mouse

• USB or PS/2* keyboard

• Microphone with a 3.5 mm Male connector (If using the microphone feature)

• Speakers with a 3.5 mm Male connector (If using the microphone feature)

* The included USB to (x2) PS/2 adapter cable must be used when connecting a PS/2 keyboard and/or mouse.

17-10-468-932947-EN.indd 2 11/17/2017 3:05:47 PM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	bryter
Model:	B006-VUA4-K-R
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	200.7 mm
Dybde:	69.8 mm
Højde:	40.6 mm
Vægt:	790 g
Produktfarve:	Sort
Pakkevægt:	2220 g
Pakkedybde:	172.7 mm
Pakkebredde:	281.9 mm
Pakkehøjde:	99.1 mm
Antal USB 2.0-porte:	2
Udgange til hovedtelefoner:	1
Maksimal opløsning:	2048 x 1536 pixel
Forbindelsesteknologi:	Ledningsført
Certificering:	RoHS
Harmoniseret systemkode (HS):	8471.80.1000
Kompatible operativsystemer:	Windows, Mac, Linux, Sun, UNIX, Novell, DOS
Hovedkassen højde (udvendigt):	200.7 mm
Hovedkassens længde (udvendigt):	299.7 mm
Hovedkassens bruttovægt (udvendigt):	12020 g
Hovedkassens bredde (udvendigt):	520.7 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	5 stk
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332152890
Antal kontrollerede computere:	4
Tastatur porttype:	USB, PS/2
Video porttype:	VGA
Porte, antal:	4
Antal mikrofon-indgange:	1
