Page 1

Installation Guide |

EG97023 Series Layer 3 Hardened Managed Ethernet Switch

08/30/2022

Unpacking

Open the carton and unpack the items. Your package should include:

▪ EG97023 Ethernet switch with RJ-45/SFP/USB dust covers installed

▪ 2 Mounting brackets

▪ 12 Mounting screws

▪ 1 RJ-45 Console cable

▪ 1 AC Power Cord (optional)

▪ Quick install guide

What Else You Need

▪ Shielded twisted pair cables and corresponding shielded RJ45 connectors

▪ Appropriate SFP cable and SFP modules for SFP ports

Select a Location

Equipment is intended for

installation in Restricted

Access Location

Les matériels sont destinés à être installés

dans des EMPLACEMENTS À ACCÈS

RESTREINT

▪ Installation: Rack mount. Use the enclosed brackets and screws to mount the

switch in an open or enclosed 19” rack.

▪ Select a power source within 6 feet (1.8 meters).

▪ Choose a dry area with ambient temperature between -40 and 75°C (Models

EG97023-2VX (X = WR, CR, WR-CC or CR-CC), (CR and CR-CC use in US/CSA

only)); -40 and 65 °C for (Models EG97023-2VX (X = CR or CR-CC)).

▪ Keep away from heat sources, sunlight, warm air exhausts, hot-air vents, and

heaters.

▪ Be sure there is adequate airflow.

Caution

Shock hazard

Disconnect all power

sources

Mise en garde

Risque d'électrocution

Débranchez toutes les sources

d'alimentation

Connect to the Data Ports

The EG97023 has the following ports:

▪ 8 x 100/1000 BASE dual rate SFP ports

▪ 12 x 1/10G dual rate SFP+ ports

▪ 1 x RJ-45 management port with dust cover

▪ 1 x RJ-45 console port with dust cover

▪ 1 x USB console port

▪ 1 x USB backup/load configuration port

Use category 5e or higher UTP/STP cable for TX ports. For SFP and SFP+ ports,

ensure that the same type of transceiver is used at both ends of the link and that

the correct type of fiber cable is used.

Connect Power

Caution

Shock hazard

Connect to earth before

connecting to supply

Mise en garde

Risque d'électrocution

Connectez à la terre avant de

connecter à l'alimentation

Power Input Interfaces

VWR, VWR-CC – 100-240VAC / 100-250VDC Redundant (Terminal Block)

VCR, VCR-CC – 100-240VAC Redundant (AC Inlet)

If your EG97023 comes with AC power cables, connect the cables into the power

modules at the back of the switch. If your switch comes with an AC terminal block

(no cable), then connect the switch to a suitable power supply using 10 to 18

AWG wire. Redundant power supply is supported. However, only one power

input is required to operate the switch. Input voltage is 100 – 240 VAC.

Relay Output Alarm

The switch provides one dry contact for signaling of a user-defined power or port

failure. The alarm relay default is “open” and forms a closed circuit when the

event occurs. The relay output can be connected to an alarm signaling device.

Relay output current is 30VDC / 0.6A.

NOTE: The initial normal state of the relay is open, and if switch loses *all* power,

then this state will come into effect. This is important to remember when using

the relay to indicate a power failure. The relay will close in an alarm state when

there is redundant power input and an alarmed input fails.

Front Panel LEDs

LED Panel Layout

Power 1 & 2

Green Power on, Off No power

Link/Act

Green: Network connection established

Flashing: Port sending or receiving data

Red: Link down or power down

Reset Button: Press and hold for less than 10 seconds to reboot the switch. Press

and hold for more than 10 seconds to reset the switch to the default password.

Console Configuration

Connect to the switch using the enclosed Ethernet cable to connect a serial port

on a PC to the RJ-45 Management port located on the front panel next to the USB

port. The IP address of VLAN 1 is 192.168.1.10.

Configuration via CLI

If using a terminal-emulation program such as Putty, configuration settings are:

Baud rate: 115,200bps, Data bits: 8, Parity: none, Stop bit: 1, Flow control: none.

The default login name is “root,” no password.

Web Configuration

192.168.2.10 via the RJ-45 management port) in the address bar. Enter the

default login ID: root (no password) and click “Login.”

USB Port

The switch is equipped with one USB port (Type A connector) for configuration

file and syslog backup. The USB port can be used to save the configuration and

Syslog to a (FAT32) USB storage device.

Plug the device into the USB port, and use the “Save Configuration” command in

the web interface, or “copy running-config startupconfig” in the CLI. Use the

“Export Logs to USB” command in the web interface, or “export logs” in the CLI.

Other Information

The power cord must be connected to a properly earth grounded outlet.

Rack Mount Instructions - The following or similar rack-mount instructions are

included with the installation instructions:

Elevated Operating Ambient - If installed in a closed or multi-unit rack

assembly, the operating ambient temperature of the rack environment

may be greater than room ambient. Therefore, consideration should be

given to installing the equipment in an environment compatible with the

maximum ambient temperature (Tma) specified by the manufacturer.

Reduced Air Flow - Installation of the equipment in a rack should be such

that the amount of air flow required for safe operation of the equipment

is not compromised.

Mechanical Loading - Mounting of the equipment in the rack should be

such that a hazardous condition is not achieved due to uneven

mechanical loading.

Circuit Overloading - Consideration should be given to the connection of

the equipment to the supply circuit and the effect that overloading of the

circuits might have on overcurrent protection and supply wiring.

Appropriate consideration of equipment nameplate ratings should be

used when addressing this concern.

Reliable Earthing - Reliable earthing of rack-mounted equipment should

be maintained. Particular attention should be given to supply connections

other than direct connections to the branch circuit (e.g. use of power

strips).

The socket-outlet shall be installed near the equipment and shall be easily

accessible.

▪ Do not disable the power cord grounding plug. The grounding plug is an

important safety feature

▪ Plug the power cord into a grounded (earthed) electrical outlet that is easily

accessible at all times.

▪ The means of power cord of adapter should be connected to a socket-outlet

with earthing connection.

▪ This equipment is intended to be used in a restricted access location and be

used by a qualified person.

▪ This equipment is not suitable for use in locations where children are likely to

be present.

▪ The power cord shall be IEC 60227 certified, rated 0.75 mm2 x 3C or UL

recognized minimum 18AWG

AC Inlet
