Owner’s Manual

DVI Over Cat5 Dual Display

Extender / Splitter

Model: B140-002-DD

1111 W. 35th Street, Chicago, IL. 60629 • www.tripplite.com/support

Package Contents 2

Product Features 2

Mounting 3

Standard Installation 4

Remote Repeater Installation 6

Troubleshooting 8

Warranty & Warranty Registration 11

WARRANTY

REGISTRATION

chance to win a FREE Tripp Lite

product www.tripplite.com/warranty

13-01-085-933287_revA.indd 1 1/30/2013 3:44:15 PM

Package Contents

Product Features

• B140-002-DD Extender / Splitter Transmitter Unit

• External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)

• Mounting Hardware

• Owner’s Manual

• Transmits a DVI-D Single-Link signal from a set of Dual DVI inputs to two

sets of Dual Displays

• A B140-Series remote receiver is needed at each monitor

• For longer distances: Use a B140-1A0 or B140-1A0-WP active receiver to

extend a 1920 x 1080 @ 60Hz signal up to 150 ft. from the transmitter

(or a 1024 x 768 @ 60Hz signal up to 200 ft. from the transmitter)

• For shorter distances: Use a B140-1P0 or B140-1P0-WP passive receiver

to extend a 1920 x 1080 @ 60Hz signal up to 50 ft. from the transmitter

(or a 1024 x 768 @ 60Hz signal up to 100 ft. from the transmitter)

• Use 24AWG, Solid Wire Cat5e/6 cable, such as Tripp Lite’s N202-Series,

to achieve maximum distance and resolution

• Further expand the range and number of monitors by adding B140-110

remote repeater units

• Add up to three repeaters on each of the B140-002-DD channels, for a

total of 4 displays per channel (An active receiver should be the last unit in

a channel)

• A 1920 x 1080 @ 60Hz signal can be extended up to 125 ft. for each repeater

added into a channel (or up to 175 ft. for a 1024 x 768 @ 60Hz signal)

• DVI 1.0 compliant

• HDCP compatible

• Mounting hardware included that allows the unit to be wall-mounted,

rackmounted, or pole mounted

• Plug and play; no software or drivers required

• Compatible with all operating systems

• Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule

purchases

13-01-085-933287_revA.indd 2 1/30/2013 3:44:15 PM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	AV forlænger
Model:	B140-002-DD
Vekselstrømsindgangsspænding:	100-240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Produktfarve:	Sort
Pakkevægt:	700 g
Pakkedybde:	164.1 mm
Pakkebredde:	214.1 mm
Pakkehøjde:	55.1 mm
HDCP:	Ja
Ethernet LAN-porte (RJ-45):	4
Maksimal opløsning:	1920 x 1080 pixel
Understøttede grafikopløsninger:	1024 x 768 (XGA), 1920 x 1080 (HD 1080)
Certificering:	TAA, RoHS
DC-in-stik:	Ja
Udgangsspænding:	5 V
Full HD:	Ja
Harmoniseret systemkode (HS):	8525.50.3035
Hovedkassen højde (udvendigt):	175 mm
Hovedkassens længde (udvendigt):	227.1 mm
Hovedkassens bruttovægt (udvendigt):	7270 g
Hovedkassens bredde (udvendigt):	573 mm
Oprindelsesland:	Taiwan
Plug and play:	Ja
Produkter pr. hovedkasse (udvendigt):	10 stk
Maksimal driftstilstand:	60.96 m
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332177510
Video porttype:	DVI
Understøttede kabeltyper:	Cat6
Antal videoporte:	2
