Instruction Manual

Thank you for choosing this Wyrestorm product.

Please read these instructions carefully before installing to avoid complications later.

Wyrestorm Extender Set

Solutions

Part Number EX-1UTP-IR-100-EDID

Part Number EX-1UTP-IR-100-POH

HDMI® Extension over Cat5e/6/7 with Full HDBaseT™

up to 100m incl. bidirectional IR control, RS232 1:2

HDMI splitting capabilities, EDID management and

Power-over-HDBaseT*

Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

Contents 1. Introduction

CONTENTS AND INTRODUCTION

Wyrestorm HDBaseT™ extender sets comprise of

a transmitter and receiver to lengthen distribution

of uncompressed 1080p HD video @60Hz and

HD multi-channel audio, high speed internet and

control up to 100m (328ft) via single category

cable, regardless of HDCP source encryption.

The EX-1UTP-100-POH and EX-1UTP-IR-100-EDID

extenders retain the rock-solid reliability of HDBaseT™

transmission technology with bidirectional control of

source and display from either location via IR and

RS232. Both models contain EDID management to

manually handle device communication issues during

installation and include the added advantage of 1:2

splitting capabilities to duplicate the receiver HDMI

output, allowing connection to an additional display or

projector.

Ethernet pass-through allow both models to be fully

cascaded up to 7 times to further expand distribution,

while the EX-1UTP-100-POH also features Power-

over-HDBaseT to enable true 5-play convergence

for distribution of video, audio, control, Ethernet and

Power through a single Cat5e/6 cable.

Wyrestorm HDBaseT™ extenders offer incredible

exibility and stability of signal distribution combined

with innovative features and an ease of use that

provides solutions where stable HD transmission

and control over distance is required, whilst also

eliminating the need for additional control and video

cables on installation, whether in a residential or

commercial setting.

For further information on this product and other

Wyrestorm ranges, visit our website or download our

Produkt Specifikationer

Mærke:	WyreStorm
Kategori:	AV forlænger
Model:	EX-1UTPIR100POH
Type:	AV sender & modtager
Tænd-/slukkontakt:	Ja
Understøttede videotilstande:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
3D:	Ja
Relativ luftfugtighed ved drift (H-H):	5 - 90 %
HDCP:	Ja
Ethernet LAN:	Ja
Driftstemperatur (T-T):	-5 - 35 °C
Maksimal opløsning:	1920 x 1200 pixel
Hurtig start guide:	Ja
Understøttede grafikopløsninger:	1280 x 1024 (SXGA), 1920 x 1200 (WUXGA)
Lyd-output kanaler:	7.1 kanaler
Strømforbrug (maks.):	17 W
LED-indikatorer:	Ja
AC-adapter inkluderet:	Ja
Farvedybde:	48 Bit
Modtager vægt:	420 g
Lydsystem:	Multikanal
Driftsspænding:	5 V
Maksimal overførselsafstand:	100 m
HDMI-version:	1.4
Monteringsbeslag inkluderet:	Ja
HSMI-indgang:	2
RJ-45 indgangs-porte:	1
Antal HDMI-udgange:	2
Modtager dimensioner (BxDxH):	130 x 106 x 29 mm
RS-232 indgangsporte:	1
Fjernbetjening (IR) indgang:	2
Fjernbetjening (IR) udgang:	2
RS-232 udgangsporte:	1
Understøttede kabeltyper:	Cat5e, Cat6, Cat7
Senderdimensioner (BxDxH):	145 x 105 x 29 mm
Transmitter vægt:	440 g
Båndbredde:	10.2 Gbit/sek.
RJ-45 udgangs-porte:	1
IR blaster inkluderet:	Ja
IR-modtager inkluderet:	Ja
