Owner’s Manual

PowerVerter

Portable

AC Inverters with USB Charging

Models: PV100USB, PV200CUSB, PV200USB, PV400USB

Introduction

Congratulations! Your new PowerVerter Portable AC Inverter with USB Charging will give you years of

reliable, carefree service. Use it to convert DC (battery) power into 110V AC (household) power to run

a variety of electronics: tablets, smartphones, laptop computers, game systems, small TVs/DVD players

and more! The Inverter’s PWM (Pulse Width Modulated) sinusoidal wave is suitable for almost all loads.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

Important Safety Instructions

SAVE THESE INSTRUCTIONS!

This manual contains important instructions and warnings that should be followed during

the installation, operation and storage of all Tripp Lite Inverters.

Warning!

• Use of this equipment in life support applications where failure of this equipment can reasonably

be expected to cause the failure of the life support equipment or to signiﬁcantly affect its safety

or effectiveness is not recommended. Do not use this equipment in the presence of a ﬂammable

anesthetic mixture with air, oxygen or nitrous oxide.

• Do not operate your Inverter near ﬂammable materials, fumes or gases.

Caution!

• Since the Inverter requires adequate ventilation during operation, do not block fan or cooling vents

or cover the Inverter, and do not operate near vehicle heating vents or in direct sunlight. Keep the

Inverter dry at all times and disconnect when not in use.

• Turn OFF connected equipment before starting your engine. DO NOT plug a surge protector, line

conditioner or UPS system into the Inverter. If you attach AC extension cords, use the heaviest

practical gauge.

• Before connecting a battery charger or adapter, check its manual to make sure that the Inverter’s

speciﬁcations (including output waveform) fall within its recommendations.

• Do not allow objects to contact the DC input terminals or battery For PV400USB model:

terminals. Do not short or bridge these terminals together. Serious personal injury or property

damage could result.

15-09-514-933411-EN-V2.indd 1 10/21/2015 11:49:08 AM

Operation

Step 1: Plug Inverter into vehicle lighter/accessory outlet.

PV400USB Model Only: This unit contains a pair of DC input terminals to connect a 3 ft. cigarette

lighter plug cable or optional 3 ft. battery cable with alligator connectors that directly attaches to a

battery’s DC terminals.

Note: Always connect red connectors to red battery terminals (POS, P, +) and black connectors to black battery

terminals (NEG, N, -). For unmarked terminals, the positive post usually has a larger diameter than the negative post.

When disconnecting the charger, reverse the order of the connecting steps.

Step 2: Turn on Inverter.

Step 3: Plug equipment into the Inverter.

Determine your equipment’s total wattage.* Do not connect more watts than your Inverter’s Output

Power (Maximum Continuous Watts); see Speciﬁcations. See back page for typical equipment

runtimes. Also see back page for important note concerning the limitations of vehicle electrical

systems.

* Wattage ratings are usually listed in equipment manuals or on nameplates. If your equipment is rated in amps,

multiply that number times AC utility voltage to determine watts. (Example: a ¼ in. drill requires 2½ amps. 2½ amps

× 120 volts = 300 watts.)

Maintenance

Your Inverter requires no maintenance and contains no user-serviceable parts (except for replaceable

DC fuses, where applicable).

Please check the following before sending the Inverter in for warranty replacement:

Symptom Possible Cause Correction

Inverter does not turn

ON when power switch is

turned ON.

Automatic Inverter shutdown due

to low battery voltage (<10V).

Turn Inverter OFF and start engine

to recharge vehicle battery. Only use

Inverter with engine running.

Automatic Inverter shutdown due

to output overload.

Turn Inverter OFF and remove

overload by unplugging high-wattage

devices. Load should not exceed

your Inverter’s maximum continuous

output power (see Speciﬁcations).

Blown fuse. Replace fuse with standard

automotive fuse of identical

amperage, where applicable (see

Speciﬁcations).

Inverter is unable

to power connected

equipment.

Battery running low. Low battery

voltage reduces Inverter power

output.

Turn Inverter OFF and start engine

to recharge vehicle battery. Only use

Inverter with engine running.

Connected equipment load

exceeds Inverter’s maximum

continuous output power.

Note: Fault LED will illuminate during

an overload (PV200USB

& PV400USB only).

Turn Inverter OFF and remove

overload by unplugging high-wattage

devices. Load should not exceed

your Inverter’s maximum continuous

output power (see Speciﬁcations).

Connected equipment

experiences audio/video

distortion.

Loose connections. Check and secure all connections.

Audio/video interference. Reposition equipment antennas and

Inverter.

Troubleshooting

15-09-514-933411-EN-V2.indd 2 10/21/2015 11:49:08 AM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Batteri
Model:	PV100USB
Bredde:	41 mm
Dybde:	83 mm
Højde:	100 mm
Vægt:	240 g
Antal pr. pakke:	1 stk
Pakkevægt:	370 g
Pakkedybde:	140 mm
Pakkebredde:	46 mm
Pakkehøjde:	105 mm
Husmateriale:	Plast
Strømforsyningstype:	Indendørs
Udgangsspænding:	120 V
Udgangsstrøm:	2.1 A
Kabellængde:	0.9 m
Harmoniseret systemkode (HS):	8504.40.9570
Kapacitet:	100 W
USB version:	2.0
Antal USB-porte:	2
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	12 V
Hovedkassen højde (udvendigt):	225 mm
Hovedkassens længde (udvendigt):	445 mm
Hovedkassens bruttovægt (udvendigt):	9130 g
Hovedkassens bredde (udvendigt):	215 mm
Oprindelsesland:	Kina
Indgangsstrøm:	12 A
Produkter pr. hovedkasse (udvendigt):	24 stk
Indgangsfrekvens:	- Hz
Stærkstrøm typen:	DC1-to-DC2
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332187885
AC udgange, antal:	1 AC stikkontakt(er)
Uddgående frekvens:	60 Hz
Udgangsspænding note:	120
