Side 1/2

warranty information

Ultimate Support Systems offers a Limited Lifetime Warranty on TS-90 SERIES.

For Full Details, Exclusions and Limitations as well as information on Obtaining Warranty

Service, please see full warranty details available online at www.ultimatesupport.com.

To purchase the Ultimate Protection Plus Premium Service and Support Plan,

please visit www.ultimatesupport.com or call customer support at 800 - 525 - 5628

for more information.

warranty registration

Visit www.ultimatesupport.com for a quick and convenient process for registering your

new Ultimate Support product. Warranty Registration and Proof of Purchase are required

for warranty fulﬁlment. Full Limited Lifetime Warranty and Ultimate Protection Plus

Premium Service and Support Plan details are available online.

TS-90 SERIES

TELELOCK

™

Product Manual

for Ultimate Support

Revision 6, 03.21.09 . Product Manual Item #SPK90-M

STANDARD

SPEAKER STAND

TS- 90B ITEM #13908

TALL

SPEAKER STAND

TS- 99B ITEM #13910

TALL LEVELING LEG

SPEAKER STAND

TS- 99BL ITEM #13642

set-up

special

instructions

lighting tree

STEP 5

Line up arrow TeleLock® collar with “RAISE”. Then raise center tube

6-10”. Put speaker cabinet on top of the stand and raise the cabinet

to desired height. Set to “LOCK” position.

STEP 6

To lower speakers, SLOWLY rotate arrow on TeleLock collar to

“LOWER” position until speaker starts to lower. To slow descent,

turn collar toward the “RAISE” position. When ready to remove the

speaker, rotate collar to “LOCKED” position.

On TS-99BL Leveling Leg Stand, 3rd leg adjusts to level stand on uneven

surfaces. Untighten leg telescoping collar, lengthen leg and retighten knob.

1. Occasionally clean the stand with a damp

cloth or non-abrasive cleaner.

2. When loading the stand, ONLY add the

speaker when the stand is in a fully upright

position (all legs on the ﬂoor).

3. Do not drag the stand while it is loaded;

this could break the ﬁttings and result in

damage to the stand which will not be

covered under warranty.

4. Check that the leg collar is securely locked

when supporting equipment.

5. Always release the TeleLock collar with

caution and stand clear of the load.

6. The stand is equipped with a tube lock

which prevents accidentally pulling out the

center tube.

STEP 1

Open leg ﬁtting lock lever.

STEP 2

Turn stand upside down and pivot legs so Ultimate Support label

faces you.

STEP 3

Turn stand upright and slide leg ﬁtting to adjust diameter of leg

spread. Leg braces should be parallel to ﬂoor for maximum stability.

Close lock lever.

STEP 4

The built-in adapter ﬁts both 1-1/2” or 1-3/8” internal diameter speaker

sockets. Use the lower position for 1-1/2”. For 1-3/8” sockets, depress

push buttons and raise adapter until it locks in raised

position.

Turn a Tall TS-99B, or TS-99BL Speaker

Stand into a Lighting Tree.

For a Single-Tier Lighting Tree add:

LTB-48B (#14107)

48” Lighting Crossbar

For a Two-Tier Lighting Tree add:

LTV-24B (#14108) 24” Vertical Extension

LTB-48B (#14107) 48” Lighting Crossbar

LTB-24B (#14106) 24” Lighting Crossbar Pair

accessories

Zippered Tote Bags

Speaker Stand

Mounting Bracket

Speaker Stand Socket

Mounting Bracket

BMB-200K (#10766)

External bracket securely mounts any

speaker cabinet with a ﬂat bottom on

an Ultimate Support speaker stand.

TSM-150MK (#13421)

TSM-138MK (#13425)

Internal metal bracket securely mounts

any speaker cabinet with a ﬂat bottom

on an Ultimate Support speaker stand.

Heavy-duty, padded, zippered

Tote Bags

BAG-90 (#15691)

Holds one TS-90B Speaker Stand.

10.5” x 49.5” (267 mm x 1257 mm)

BAG-90D (#15693)

Holds two TS-90B Speaker Stands.

14.5” x 49.5” (368 mm x 1257 mm)

BAG-99 (#15692)

Holds one Speaker Stand.TS-99B/TS-99BL

10.5” x 60.5” (267 mm x 1537 mm)

BAG-99D (#15694)

Holds two Speaker Stands.TS-99B/TS-99BL

14.5” x 60.5” (368 mm x 1537 mm)
