Side 1/3

INSTRUCTION MANUAL

LED FLOOD LIGHT

TECHNICAL DATA

MODEL VT-44035 VT-44055 VT-44104 VT-44204

SKU 23599 23688, 23600

23689, 23690

23440,23441

23442,23443

23601

23602, 23603

POWER 30W 50W 100W 200W

LUMENS 2505Lm 8700 Lm 17540Lm4270Lm

COLOUR

TEMPERATURE 3000K 4000K

6500K

4000K

6500K

4000K

6500K

INPUT VOLTAGE AC: 220-240V, 50Hz

DF >0.9

CRI 70

LIFE SPAN 25,000 Hours

ON/OFF CYCLE 15,000 Times

BEAM ANGLE 115°

OPERATION

TEMPERATURE -20°C to +40°C

BODY TYPE Aluminium

MAX. MOUNT-

ING HEIGHT <5M

NET WEIGHT 0.35Kg 0.48Kg 0.97Kg 2.5Kg

PROJECTED

AREA (mm2)25168.5 31011.5 140673.7561473.75

DIMENSION 164.5x34x-

153mm

183.5x34x-

169mm

253.5x242.5

x40mm

402.5x349x5x-

44mm

In case of any query/issue with the product, please reach out to us at: support@v-tac.eu

For More products range, inquiry please contact our distributor or nearest dealers.

V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B

MULTI-LANGUAGE

MANUAL QR CODE

Please scan the QR code

toaccess the manual in

multiple languages.

INTRODUCTION & WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the

best. Please read these instructions carefully before starting the installation

and keep this manual handy for future reference. If you have any another

query, please contact our dealer or local vendor from whom you have pur-

chased the product. They are trained and ready to serve you at the best. The

warranty is valid for 5 years from the date of purchase. The warranty does

not apply to damage caused by incorrect installation or abnormal wear and

tear. The company gives no warranty against damage to any surface due to

incorrect removal and installation of the product. The products are suitable

for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would

void the warranty. This product is warranted for manufacturing defects only.

*This product contains a light source

of energy eciency class<F>,where

<F> shall be replaced by

the energy class of the contained

light source.

This marking indicates that this

product should not be disposed

of with other household wastes.

Caution, risk of electric shock.

Replaceable (LED Only) light

source by a professional

INSTALLATION DIAGRAM

INSTALLATION INSTRUCTION

• DO NOT USE IN AREAS WITH LIMITED VENTILATION OR OUTSIDE THE RATED AMBIENT TEM-

PERATURE RANGE. *CON- NECT WITH WATERPROOF CABLE HOUSE ONLY. *ENSURE ELEC-

TRICITY IS SWITCH OFF BEFORE INSTALLATION.

• Please do not mount to a surface that is prone to vibrations .*

Remove the screw and the bracket aerward. (Figure 1)Before drilling, mark the hole position for

ﬁxing the bracket onto the wall (Screw not supplied). (Figure 2)

• Screw the retaining bracket to the wall with a suitable quantity of screws. (Figure 4)

• Mount the bracket back to the ﬁxture. Adjust the ﬂoodlight according to the desired position.

Tighten the screw. (Figure 5) Connect your main cable (HO5RN-F3G1.0mm2 Recommended)

with the input lead of our product through the waterproof junction box. Note, the line (-) of the

lead. (Need to use the junction box of IP65 or above, ensure to tighten the waterproof screw)

Switch on the power to make sure if the product is working.

WARNING

1. Please make sure to turn o the power before starting the installation.

2. Installation must be performed by a qualiﬁed electrician.

3. The light source contained in this luminaire shall only be replaced by the

manufacturer or his service agent or a similar qualiﬁed person.

4. The external ﬂexible cable or cord of this luminaire cannot be replaced; if

the cord is damaged, the luminaire shall be destroyed.

5. Replace any cracked protective shield.

6. Terminal block not included.

7. Proper grounding should be ensured throughout the installation.

8. Minimum distance from lighted objects 1m.

9. For outdoor use.

NOTE: To reduce the risk of strangulation the ﬂexible wiring connected to this luminaire shall be eectively

ﬁxed to the wall if the wiring is within arm’s reach.
