Side 1/4

In case of any query/issue with the product, please reach out to us at: support@v-tac.eu

For More products range, inquiry please contact our distributor or nearest dealers.

V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B

INSTRUCTION MANUAL

LED BULKHEAD

INTRODUCTION & WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions

carefully before starting the installing and keep this manual handy for future reference. If you have any another

query, please contact our dealer or local vendor from whom you have purchased the product. They are trained

and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty

does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no

warranty against damage to any surface due to incorrect removal and installation of the product. The products

are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This

product is warranted for manufacturing defects only.

TECHNICAL DATA

SENSOR SPECIFICATIONS

EMERGENCY SPECIFICATIONS

MODEL SKU BEAM

ANGLE CRI DF LIFE SPAN

(HOURS)

INPUT

VOLTAGE MATERIAl DIMENSION WARRANTY

VT-8603 801-24 110° >80 30,000 AC:200-240V, 50/60Hz PC 320x100mm 5 Year0.9

VT-8613 804-24 110° >80 30,000 AC:200-240V, 50/60Hz PC 320x100mm 5 Year0.9

VT-8623 806-24 110° >80 30,000 AC:200-240V, 50/60Hz PC 320x100mm 3 Year0.9

VT-8633 812-24 110° >80 30,000 AC:200-240V, 50/60Hz PC 320x100mm 3 Year0.9

MODEL

EMERGENCY

OPERATION

TIME

EMERGENCY

STANDBY WATTS

BATTERY

CHARGING

CURRENT

BATTERY

DISCHARGING

CURRENT

BATTERY TYPE TEST

BUTTON

CHARGING

INDICATOR

VT-8623 >3 Hours >1.2 Watts 250mA 410mA LiFePO4, 3.2V, 2Ah With Green LED

MODEL DETECTION

ANGLE

DETECTION

DISTANCE

DETECTION

RANGE MAX. HOLD TIME DAYLIGHT

SENSOR

DETECTION

MOTION SPEED

VT-8613

VT-8633

360° If Ceiling

Mounting

120° If Wall

mounting

3-6 M D6Mx3M 5s, 30s,90s,

3min,20min,30min

Day, 2LUX,10LUX-

,25LUX Optional 0.5-3m/s

INSTALLATION INSTRUCTIONS

3 4

Switch OFF the power

before starting the

installation.

Carefully press and unlock the screw

on the led hinged tray and hold the

tray at an upward 90Degree position.

Hold the product upside down.

Hold the product in place, mark & drill the holes

into the wall and nail the alligator into the hole.

Feed the supply cable into the luminaire through

the cable entry hole

Remove the cover by holding the luminaire upside down. Press 3

clips on the sides and pull the base upwards to open and set aside.

• Please make sure to turn o the power before start-

ing the installation.

• Installation must be performed by a qualiﬁed person.

• The light source of this luminaire is not replaceable,

when the light source reaches its end of life the

whole luminaire should be replaced.

• If the external ﬂexible cable or cord of this luminaire

is damaged, it shall be exclusively replaced by the

manufacturer or his service agent or a similar quali-

ﬁed person in order to avoid a hazard.

WARNING

This marking indicates that this

product should not be disposed

of with other household wastes.

Caution, Risk of electric shock

MULTI-LANGUAGE

MANUAL QR CODE

Please scan the QR code

to access the manual in

multiple languages.
