TECHNICAL ASSISTANCE

When trouble is reported, verify there are no broken connections to the unit and

consult the Troubleshooting Chart. Assistance in troubleshooting is available from

the factory. When calling, you should have a Volt-Ohm meter and a lineman’s test

set available and be calling from the job site. Call (540) 563-2000 and ask for

Technical Support, or call (540) 767- -1555 for Valcom 24 hour Faxback System or

visit our website at http://www.valcom.com.

Valcom equipment is not field repairable. Valcom, Inc. maintains service facilities in

Roanoke, VA. Should repairs be necessary, attach a tag to the unit clearly stating

your company name, address, phone number, contact person and the nature of the

problem. Send the unit to:

Valcom, Inc.

Repair and Return Dept.

5614 Hollins Road

Roanoke, VA 24019-5056

VALCOM LIMITED WARRANTY

Valcom, Inc. warrants its products to be free from defects in materials and workmanship

under conditions of normal use and service for a period of one year from the date of

shipment. The obligation under this warranty shall be limited to the replacement, repair or

refund of any such defective device within the warranty period, provided that:

1. inspection by Valcom, Inc. indicates the validity of the claim;

2. the defect is not the result of damage, misuse or negligence after the original

shipment;

3. the product has not been altered in any way or repaired by others and that

factory sealed units are unopened (A service charge plus parts and labor will be

applied to units defaced or physically damaged);

4. freight charges for the return of products to Valcom are prepaid;

5. all units ‘out of warranty’ are subject to a service charge. The service charge will

cover minor repairs (Major repairs will be subject to additional charges for parts

and labor).

This warranty is in lieu of and excludes all other warranties, expressed or implied,

and in no event shall Valcom, Inc. be liable for any anticipated profits, consequential

damages, loss of time or other losses incurred by the buyer in connection with the

purchase, operation, or use of the product.

This warranty specifically excludes damage incurred in shipment. In the event a product is

received in damaged condition, the carrier should be notified immediately. Claims for such

damage should be filed with the carrier involved in accordance with the F.O.B. point.

Headquarters: In Canada

Valcom, Inc. CMX Corporation

5614 Hollins Road 35 Van Kirk Drive #11 and 12

Roanoke, VA 24019-5056 Brampton, Ontario L7A1A5

Phone: (540) 563-2000 Phone: (905) 456-1072

FAX: (540) 362-9800 FAX: (905) 456-2269

INSTALLATION INSTRUCTIONS FOR

AMPLIFIED DESK SPEAKER

MODEL NO. V-763

Issue 7 947163

VALCOM ONE-WAY AMPLIFIED DESK SPEAKER

Valcom Desk Speaker, V- -763, is self amplified and may be used to provide paging

from any one-way or talkback page control. The volume may be adjusted with the

knob on the front of the housing. The V- -763 requires 24VDC, 50mA (1 Valcom

power unit).

Model V- -763 BK Black

Model V- -763 W White

Model V- -763 GY Gray

NOMINAL SPECIFICATIONS

Input Impedance: 600 Ohm nominal

Input level: -10dBm nominal

Current at -24VDC: 45mA

Dimensions: 3.90" H x 5.10" W x 3.20" D

(9.91cm H x 12.95cm W x 8.13cm D)

Weight: .6 lbs. (.27 kg)

WIRING

Make connections as shown below using standard, twisted telephone cable. Limit the

number of speakers to five (5) per 500 foot run.

NOTE: Do not connect this speaker directly to 25/70/100V amplifier

as damage to both the amplifier and speaker may occur. A V-1095

may be used to allow the use of Valcom self-amplified speakers on

70V speaker lines.

MOUNTING

The V-763 can be used on a desk or wall mounted. The front cover may be rotated

to match positioning. Four rubber feet are included with the V-763 to prevent

movement on a desk surface.

Key hole patterns are located on the inside rear surface of the enclosure for wall

mounting. When wall mounting, remove the front cover, mount and replace the front

cover. Use a 11/32" drill bit to drill the center hole and a 3/16" bit to drill either of

the outer holes.

TROUBLESHOOTING CHART

Problems

Probable Causes and Corrections

No Audio from

Speaker

1. Check that volume control is turned up (Clockwise).

2. Using a lineman’s test set, check for the proper audio

level on the Tip/A & Ring/B leads, and if necessary at

the source.

Low Volume from

the Speaker

1. Check that volume control is turned up.

2. Check voltage at the speaker when in use (- -18 to 24

VDC required).

3. Using a lineman’s test set, check for proper audio level

on the Tip/A & Ring/B leads. It is possible some low

level audio will be heard with only one side of Tip/A

and Ring/B connected.

Loud Squeal

(feedback)

1. Lower volume of speaker.

2. Move speaker to location further from phone.

3. Install confidencer on phone in severe problem area.

Valcom Page

Control

Page

Out One-Way

Amplified

Speaker

Tip/A

Ring/B

-24VDC

Gnd

Valcom -24VDC

Power Supply

Ground

-24VDC

Tip

Ring

- Black

- Yellow

- Green

- Red

Typical Connections
