Item No. 2350215-1 Rev 07/13

ENGLISH

Operator’s Manual

Fruit Cutter

403NH

Thank you for purchasing this Vollrath Food Processing Equipment. Before operating the equipment, read and familiarize yourself with

the following operating and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and

packaging. Use this packaging to ship the equipment if repairs are needed.

M F P eanual ood rocessing quiPMent

OperatOr s anual’ M

S Pafety recautionS

To ensure safe operation, read the following statements and understand

their meaning. This manual contains safety precautions which are

explained below. Please read carefully.

WARNING

Warning is used to indicate the presence of a hazard that can cause

severe personal injury, death, or substantial property damage if the

warning is ignored.

CAUTION

Caution is used to indicate the presence of a hazard that will or can

cause minor personal injury or property damage if the caution is

ignored.

NOTE

Note is used to notify people of installation, operation, or maintenance

information that is important but not hazard-related.

For Your Safety!

These precautions should be followed at all times. Failure to follow

these precautions could result in injury to yourself and others or

damage the equipment.

To reduce risk of injury or damage to the equipment:

Check equipment before each use to insure the equipment is clean.

Check for broken, nicked or dull blades and if found, replace the blade

assembly.

Check to insure that the pusher head sits down completely on the rubber

bumpers.

If necessary, lubricate guide rods using a light coating of mineral oil, Petro

Gel, or food grade lubricant. DO NOT USE COOKING OIL AS IT WILL

BECOME STICKY AND MAY PERMANENTLY DAMAGE THE PUSHER

HEAD BEARINGS

f Punction and urPoSe

Intended for cutting, dicing and wedging vegetables and fruits.

featureS and ontrolS c

Figure 1. Features and Controls Fruit Cutter.

BLADE ASSEMBLY. Houses the blades. Specically sized to

match the corresponding pusher head block.

HANDLE. Used to lower and raise the pusher head.

LEGS. Supports the equipment.

PUSHER HEAD ASSEMBLY. Made up of the guides and the

pusher head block (and the handle for tabletop models).

BUMPERS. Cushions the stop of the pusher head.

BASE ASSEMBLY. Holds the guide rods and parts of the

equipment.

unPacking the quiPment and nitial etuP e i S

Carefully remove crating or packaging materials from the equipment.

Dispose of all packaging ,materials in an environmentally responsible

manner.

Leg installation Fruit Cutter:

1. Install the rubber feet (E) on to the legs (C). See Figure 2.

2. Use the screws (A) and washers (B) to install legs (C) tightening with

wrench (D).
