Operator's Manual
7/21/2023
H D D C
Thank you for purchasing this Vollrath® product! Save this manu-
al for reference and the packaging in case shipping is necessary.
SAFETY PRECAUTIONS
To help ensure safe use, please read and fully understand this
manual and all safety messages before operation!
WARNING
Warning indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Caution indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE: addresses practices not related to physical injury.
To reduce risk of injury or damage to the unit
• Use only properly grounded electrical outlets matching the
nameplate-rated voltage.
• Have a qualified person install the equipment in accordance
with local codes and ordinances.
• Use equipment in a flat, level position.
• Do not use an extension cord with this equipment. Do not plug
this equipment into a power strip or multi-outlet power cord.
• Unplug equipment and turn off before cleaning or moving.
• Do not spray controls or outside of equipment with liquids or
cleaning agents.
• Do not clean the equipment with steel wool.
• Keep equipment and power cord away from open flames,
electric burners or excessive heat.
• Do not operate unattended.
• Do not operate if equipment has been damaged or is
malfunctioning in any way.
FUNCTION AND PURPOSE
These 120V units are designed to illuminate and display
prepared, preheated food—deli (TCS-Time/Temperature Control
for Safety) products—at proper serving temperatures between
104 °F (40 °C) and 165 °F (74 °C). They may also be used at
ambient temperatures for displaying food that does not need
to remain hot. Heated Deli Display Cases are not intended or
designed to cook raw food or reheat prepared food—nor are
they intended for household, industrial or laboratory use.
UNPACKING THE UNIT
1. Remove all packing material and tape, as well as any
protective plastic; dispose of in an environmentally-
responsible way when no longer needed.
2. Remove bolts that secure the unit to the pallet.
3. Clean any glue residue left over from the plastic or tape.
4. If adjusting shelf positions, remove the screws above the
shelves and cover open slots with silicone plugs.
Curved
Countertop
Item Model Description
HDCCV-36 HDC9236 Curved Countertop—36"
HDCCV-48 HDC9248 Curved Countertop—48"
HDCCV-60 HDC9260 Curved Countertop—60"
HDCCB-36 HDC9336 Cubed Countertop—36"
HDCCB-48 HDC9348 Cubed Countertop—48"
HDCCB-60 HDC9360 Cubed Countertop—60"
Cubed
Countertop
OPERATION
WARNING
Burn Hazard.
Do not touch cookware, heating surface, food,
or liquid while heating or operating.
WARNING
Electrical Shock Hazard.
Keep liquids from getting inside the unit.
Do not immerse in or spray cord, plug, or
unit with liquid or foam—this could cause
an electrical shock. Do not use if the
power cord is damaged or modified.
NOTICE: Before operation, clean the unit as directed.
NOTICE: Food must be prepared and placed in display
cabinets at proper serving temperatures.
NOTICE: Monitor food temperature closely for food safety.
The United States Public Health Service recommends that hot
food be held at a minimum of 140 ºF (60 ºC) to help prevent
bacteria growth.
SHELF & BOTTOM PLATFORM WEIGHT CAPACITY
NOTICE: Distribute weight evenly over the shelves.
36" 48" 60"
40 lb (18.1 kg) 48 lb (21.7 kg) 55 lb (24.9 kg)
PREPARED, HOT FOOD DISPLAY USE
1. Press Up Triangle/Controller Power (
▲
) until unit turns
on and temperature displays (about 3 seconds).
2. Press
set
until the temperature flashes.
3. Adjust the temperature by pressing the Up Triangle (▲) to
increase or the Down Triangle (
▼) to decrease.
4. Press
set
; heating will resume at selected temperature.
5. Preheat for about 30 minutes, then place prepared, warm
food heated to proper serving temperature.
LIGHTS
1. Press Up Triangle/Controller Power (
▲
) and Down
Triangle/Heat (
▼ ) together to turn LED lights on or off;
Lt should display or flash.
AMBIENT TEMPERATURE, NON-HEATED DISPLAY USE
1. Press Up Triangle/Controller Power (
▲
) until unit turns
on and temperature displays (about 3 seconds).
2. Press
set
until temperature flashes.
3. Press Down Triangle (▼) to decrease temperature below
the ambient air.
NOTICE: Do not use this mode to store foods that could
be hazardous when not maintained at proper serving
temperatures.
2
Heated Deli Display Cases
INSTALLATION
Clearance Requirements
• Countertop cases allow for zero clearance.
• Operator side and top of unit must remain open and accessible
for proper operation and service.
• Leave a minimum of 2" of airspace between product on the top
shelf and the top glass.
• Sufficient air circulation is required so the unit operates as
intended. Do not cover vents on bottom platform or allow
product to overhang shelves.
NOTICE: Using voltage other than the nameplate-rated voltage
or modifying the power cord or electrical components will
damage unit and void the warranty.
1. Place the unit on a flat stable surface.
2. Ensure control panel is accessible for operation.
3. Seal base to the countertop with food-grade silicone.
Optional 4" adjustable legs are available through
Vollrath®.
4. Plug the equipment into a properly grounded electrical
supply matching the nameplate rating.
5. After installation, the thin breather wires on the top of the
side glass panels may be trimmed and crimped closed.
FEATURES AND CONTROLS
A. Heat On Indicator—( ) illuminates when unit is heating.
B. Number Display—shows the current temperature or the
temperature being programed.
C. Up Triangle/Controller Power—(
▲
) turns controller ON or
OFF or increases the temperature, dependent upon mode.
D. Set—
set
turns temperature setting mode ON or OFF.
E. Down Triangle/Heat—(▼ ) decreases temperature.
B
D
C
E
A
