Side 1/28
8651853_020924 enUS
Installation and Assembly
m DANGER: This grill is not intended to be installed in or on
recreational vehicles or boats.
m WARNING: Do not use this grill unless all parts are in place
and the grill was properly assembled according to the
assembly instructions.
m WARNING: Do not build this model of grill in any built-in or
slide-in construction.
m WARNING: Do not modify the appliance (grill). Liquid
propane gas is not natural gas. The conversion or attempted
use of natural gas in a liquid propane gas unit or liquid
propane gas in a natural gas unit is unsafe and will void
your warranty.
m WARNING: Do not route the ten-foot hose under a deck. The
hose must be visible.
WE RECOMMEND THAT THE INSTALLATION OF
THIS NATURAL GAS GRILL BE PERFORMED BY A
PROFESSIONAL.
Confirm that the branch supply line from the house to the
grill is properly installed before using the grill.
In the United States, installation must conform with
local codes or, in the absence of local codes, with either
the National Fuel Gas Code, ANSI Z223.1/NFPA 54,
Natural Gas and Propane Installation Code, CSA B149.1;
or Propane Storage and Handling Code, B149.2; or the
Standard for Recreational Vehicles, ANSI A119.2/NFPA
1192, and CSA Z240 RV Series, Recreational Vehicle Code,
as applicable.
InCanada, the installation of this grill must comply with
local codes and/or the latest edition of Standard CAN/
CSA-B149.2 (Propane Storage and Handling Code).
These instructions, while generally acceptable, do not
necessarily comply with the Canadian installation codes,
particularly with piping above and below ground.
In Mexico, if there are local codes that apply to portable
gas appliances, you must comply with the latest edition of
Ocial Mexican Standard (NOM).
If an external electrical source is utilized (such as a
rotisserie) it must be electrically grounded in accordance
with local codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70, or the Canadian
Electrical Code, Part 1, CSA C22.1.
Operation
m DANGER: Only use the grill outdoors in a well-ventilated
area. Do not use in a garage, building, breezeway,
tent, any other enclosed area, or beneath overhead
combustibleconstruction.
• An appliance is considered to be outdoors if installed with
shelter no more inclusive than with walls on three sides, but
with no overhead cover; all openings must be permanently
open; sliding doors, garage doors, windows, or screened open-
ings are not considered as permanent openings.
• An appliance is considered to be outdoors if installed with
shelter no more inclusive than within a partial enclosure that
includes an overhead cover and no more than two sidewalls.
The sidewalls may be parallel, as in a breezeway, or at right
angles to each other; all openings must be permanently open;
sliding door, garage doors, windows, or screened openings are
not considered as permanent openings.
• An appliance is considered to be outdoors if installed with
shelter no more inclusive than within a partial enclosure that
included an overhead cover and three sidewalls, as long as
30% or more of the horizontal periphery of the enclosure is
permanently open. All openings must be permanently open;
sliding doors, garage doors, windows, or screened openings
are not considered as permanent openings.
• The minimum ambient operating temperature for safe use of
the appliance shall be 0° F (-17° C).
Keep this Owners Manual for future reference, thoroughly read
through it, and if you have any questions please contact us today.
NG Owners Manual
REGISTER TODAY
Register your gas grill and receive special content to make
you the ultimate backyard hero.
Scan the QR Code or register online at weber.registria.com
m DANGER
If you smell gas:
Shut o gas to the appliance
(grill).
Extinguish any open flame.
Open lid.
If odor continues, keep away
from the appliance (grill)
and immediately call your
gas supplier or your fire
department.
m WARNING
Do not store or use gasoline
or other flammable liquids or
vapors in the vicinity of this
(grill) or any other appliance.
An LP cylinder (tank) not
connected for use shall not
be stored in the vicinity of this
(grill) or any other appliance.
USE OUTDOORS ONLY.
READ THE INSTRUCTIONS BEFORE USING THE
APPLIANCE (GRILL).
NOTICE TO INSTALLER: These instructions
must be left with the consumer.
NOTICE TO CONSUMER: Retain these
instructions for future reference.
Important SafetyInformation
DANGER, WARNING, and CAUTION
statements are used throughout this
Owner's Manual to emphasize critical and
important information. Read and follow
these statements to help ensure safety and
prevent property damage. Thestatements
are defined below.
m DANGER: Indicates a hazardous situation
which, if not avoided,
will result in death or seriousinjury.
m WARNING: Indicates a hazardous situation
which, if not avoided,
could result in death or seriousinjury.
m CAUTION: Indicates a hazardous situation
which, if not avoided,
could result in minor or moderateinjury.
Write your grill's serial number in the box above for future reference.
The serial number is on the data label located on the grill.
Serial Number
S-315 • S-415 • E-325 • SA-E-325• SP-S-325
E-330 • SA-E-330
E-335 • S-335 • E-335C • S-335C
SP-E-335 • SP-S-335
2
Safety Information
m DANGER: Do not use the grill in any vehicle or in any
storage or cargo area of any vehicle. This includes, but
is not limited to, cars, trucks, station wagons, mini-vans,
sport utility vehicles, recreational vehicles, andboats.
m DANGER: Do not use the grill within 24 inches (61 cm)
of combustible materials. This includes the top, bottom,
back and sides of the grill.
m DANGER: Keep the cooking area clear of flammable
vapors and liquids such as gasoline, alcohol, etc., and
combustible materials.
m DANGER: This appliance (grill) must be kept away from
flammable materials during use.
m DANGER: Do not put a grill cover or anything flammable
on, or in the storage area under the grill while it is in
operation or is hot.
m DANGER: Should a grease fire occur, turn o all burners
and leave lid closed until fire is out.
m WARNING: Accessible parts may be very hot. Keepyoung
children away.
m WARNING: The use of alcohol, prescription drugs,
non-prescription drugs, or illegal drugs may impair the
consumer’s ability to properly and safely assemble,
move, store, or operate thegrill.
m WARNING: Never leave the grill unattended during pre-
heating or use. Exercise caution when using this grill.
The entire cookbox gets hot when in use.
m WARNING: Do not move the appliance (grill) duringuse.
m WARNING: Keep any electrical supply cord and the fuel
supply hose away from any heated surfaces.
m CAUTION: This product has been safety-tested and
is only certified for use in a specific country. Refer to
country designation located on outside of box.
Do not use charcoal or lava rock in the grill.
This natural gas grill is factory built to operate using
natural gas only. Never attempt to operate your grill
on gases other than the type specified on the grill
ratingplates.
Storage and/or Nonuse
m WARNING: Turn o the gas at the natural gas supply
valve when the grill in not in use.
m WARNING: After a period of storage and/or nonuse,
the grill should be checked for gas leaks and burner
obstructions before use.
Storage of the grill indoors is permissible only if the
grill is disconnected from the gas supply.
California Proposition 65
m WARNING: Combustion byproducts produced when
using this product contain chemicals known to the state
of California to cause cancer, birth defects, or other
reproductive harm.
m PROPOSITION 65 WARNING: Handling the brass material
on this product exposes you to lead, a chemical known to
the state of California to cause cancer, birth defects, or
other reproductive harm. Wash hands after handling this
product.
Limited Warranty
Thank you for purchasing a WEBER product. Weber-Stephen
Products LLC, 1415 S. Roselle Road, Palatine, Illinois 60067
(“WEBER”) prides itself on delivering a safe, durable, and
reliableproduct.
This is WEBER’s Limited Warranty (“Warranty”) provided to you
at no extra charge. It contains the information you will need to
have your WEBER product repaired in the unlikely event of a
failure or defect.
Pursuant to applicable laws, the customer has several
rights in case the product is defective. Those rights include
supplementary performance or replacement, abatement of
the purchasing price, and compensation. These and other
statutory rights remain unaffected by this warranty provision.
In fact, this warranty grants additional rights to the Owner
that are independent from statutory warranty provisions.
WEBER’S LIMITED WARRANTY
WEBER warrants, to the purchaser of the WEBER product (or
in the case of a gift or promotional situation, the person for
whom it was purchased as a gift or promotional item) ("Owner"),
that the WEBER product is free from defects in material and
workmanship for the period(s) of time specified below when
assembled and operated in accordance with the accompanying
Owner’s Manual, normal wear and tear excluded . (Note: If you
lose or misplace your WEBER Owner’s Manual, a replacement is
available online at www.weber.com.) WEBER agrees within the
framework of this warranty to repair or replace the part that is
defective in material or workmanship subject to the limitations,
and exclusions listed below. TO THE EXTENT ALLOWABLE BY
APPLICABLE LAW, THIS WARRANTY IS EXTENDED ONLY TO
THE ORIGINAL PURCHASER AND IS NOT TRANSFERABLE TO
SUBSEQUENT OWNERS, EXCEPT IN THE CASE OF GIFTS AND
PROMOTIONAL ITEMS AS NOTED ABOVE.
WEBER stands by its products and is happy to provide you with
the Warranty described for material defects in the grill or its
relevant components, normal wear and tear excepted.
• ‘Normal wear and tear’ includes cosmetic and other immaterial
deterioration that may come with ownership of your grill over
time, such as surface rust, dents / scratches, etc.
However, WEBER will honor this Warranty for the grill or its
relevant components where damage or dysfunction results from
a material defect.
• ‘Material defect’ includes rust through or burn through of
certain parts, or other damage or failure inhibiting your ability
to safely / properly use your grill.
OWNER’S RESPONSIBILITIES UNDER THIS WARRANTY
To ensure trouble-free warranty coverage, it is important (but it
is not required) that you register your WEBER product online at
www.weber.com. Please also retain your original sales receipt
and/or invoice. Registering your WEBER product confirms your
warranty coverage and provides a direct link between you and
WEBER in case we need to contact you. If you have not had time
to register your grill before calling for Warranty service, please
have the following information available when you do call:
Name – Address – Phone Number – Email – Serial Number –
Purchase Date – Purchase Dealer – Model – Color – Primary
Issue
The above warranty only applies if the Owner takes reasonable
care of the WEBER product by following all assembly
instructions, usage instructions, and preventative maintenance
as outlined in the accompanying Owner’s Manual, unless the
Owner can prove that the defect or failure is independent of
non-compliance with the above mentioned obligations. If you
live in a coastal area, or have your product located near a
pool, maintenance includes regular washing and rinsing of the
exterior surfaces as outlined in the accompanying Owner’s
Manual.
WARRANTY HANDLING / EXCLUSION OF WARRANTY
If you believe that you have a part which is covered by this
Warranty, please contact WEBER Customer Service using the
contact information on our website (www.weber.com, or such
country-specific website to which Owner may be redirected).
WEBER will, upon investigation, repair or replace (at its option)
a defective part that is covered by this Warranty. In the event
that repair or replacement are not possible, WEBER may choose
(at its option) to replace the grill in question with a new grill of
equal or greater value. WEBER may ask you to return parts for
inspection, shipping charges to be pre-paid by owner.
When you contact Customer Service, please have the following
information available:
Name – Address – Phone Number – Email – Serial Number –
Purchase Date – Purchase Dealer – Model – Color – Primary
Issue
This WARRANTY lapses if there are damages, deteriorations,
discolorations, and/or rust for which WEBER is not responsible
caused by:
Abuse, misuse, alteration, modification, misapplication,
vandalism, neglect, improper assembly or installation, and
failure to properly perform normal and routine maintenance;
Insects (such as spiders) and rodents (such as squirrels),
including but not limited to damage to burner tubes and/or gas
hoses;
Exposure to salt air and/or chlorine sources such as swimming
pools and hot tubs/spas;
Severe weather conditions such as hail, hurricanes,
earthquakes, tsunamis or surges, tornadoes or severe storms.
Acid rain and other environmental factors.
Using third party parts will not void this Warranty. However, any
parts that are used and/or installed on your WEBER product that
are not genuine WEBER parts are not covered by this Warranty.
In addition, any damages that result from the use and/or
installation of parts on your WEBER product that are not genuine
WEBER parts are not covered by this Warranty. Any conversion of
a gas grill not authorized by WEBER and performed by a WEBER
authorized service technician will void this Warranty.
PRODUCT WARRANTY PERIODS
Cookbox:
12 years, no rust through/burn through
(2 years paint excluding fading or discoloration)
Lid assembly:
12 years, no rust through/burn through
(2 years paint excluding fading or discoloration)
Stainless steel burner tubes:
10 years, no rust through/burn through
Stainless steel cooking grates:
10 years, no rust through/burn through
Stainless steel FLAVORIZER BARS:
10 years, no rust through/burn through
Porcelain-enameled cast iron cooking grates:
10 years, no rust through/burn through
WEBER CONNECT Components:
3 years
All remaining parts:
5 years
DISCLAIMERS
APART FROM THE WARRANTY AND DISCLAIMERS AS
DESCRIBED IN THIS WARRANTY STATEMENT, THERE ARE
EXPLICITLY NO FURTHER WARRANTY OR VOLUNTARY
DECLARATIONS OF LIABILITY GIVEN HERE WHICH GO
BEYOND THE STATUTORY LIABILITY APPLYING TO WEBER.
THE PRESENT WARRANTY STATEMENT ALSO DOES NOT
LIMIT OR EXCLUDE SITUATIONS OR CLAIMS WHERE WEBER
HAS MANDATORY LIABILITY AS PRESCRIBED BY STATUTE.
NO WARRANTIES SHALL APPLY AFTER THE APPLICABLE
PERIODS OF THIS WARRANTY. NO OTHER WARRANTIES
GIVEN BY ANY PERSON, INCLUDING A DEALER OR RETAILER,
WITH RESPECT TO ANY PRODUCT (SUCH AS ANY “EXTENDED
WARRANTIES”), SHALL BIND WEBER. THE EXCLUSIVE
REMEDY OF THIS WARRANTY IS REPAIR OR REPLACEMENT
OF THE PART OR PRODUCT.
IN NO EVENT UNDER THIS WARRANTY SHALL RECOVERY
OF ANY KIND BE GREATER THAN THE AMOUNT OF THE
PURCHASE PRICE OF THE WEBER PRODUCT SOLD.
YOU ASSUME THE RISK AND LIABILITY FOR LOSS, DAMAGE,
OR INJURY TO YOU AND YOUR PROPERTY AND/OR TO
OTHERS AND THEIR PROPERTY ARISING OUT OF THE MISUSE
OR ABUSE OF THE PRODUCT OR FAILURE TO FOLLOW
INSTRUCTIONS PROVIDED BY WEBER IN THE ACCOMPANYING
OWNER’S MANUAL.
PARTS AND ACCESSORIES REPLACED UNDER THIS
WARRANTY ARE WARRANTED ONLY FOR THE BALANCE OF
THE ABOVE MENTIONED ORIGINAL WARRANTY PERIOD(S).
THIS WARRANTY APPLIES TO PRIVATE SINGLE FAMILY HOME
OR APARTMENT USE ONLY AND DOES NOT APPLY TO WEBER
GRILLS USED IN COMMERCIAL, COMMUNAL OR MULTI-UNIT
SETTINGS SUCH AS RESTAURANTS, HOTELS, RESORTS, OR
RENTAL PROPERTIES.
WEBER MAY FROM TIME TO TIME CHANGE THE DESIGN OF
ITS PRODUCTS. NOTHING CONTAINED IN THIS WARRANTY
SHALL BE CONSTRUED AS OBLIGATING WEBER TO
INCORPORATE SUCH DESIGN CHANGES INTO PREVIOUSLY
MANUFACTURED PRODUCTS, NOR SHALL SUCH CHANGES
BE CONSTRUED AS AN ADMISSION THAT PREVIOUS DESIGNS
WERE DEFECTIVE.
Weber-Stephen Products LLC
Customer Service Center
1415 S. Roselle Road
Palatine, IL 60067
U.S.A.
For replacement parts, call:
1-800-446-1071
3
Getting Started
Important Information about
NaturalGas & Gas Connections
What is Natural Gas?
Natural gas (NG) is a combustible, gaseous mixture
of simple hydrocarbon compounds, usually found in
deep underground reservoirs formed by porous rock.
It is a fossil fuel composed almost entirely of methane.
Natural gas is delivered by your local utility through an
underground pipeline system.
General Specifications
Three burner grills are designed to operate at 7" of
water column pressure (0.2526 psi).
Four burner grills are designed to operate at 4.5" of
water column pressure (0.16245 psi).
The quick-disconnect fitting can be installed
horizontally or pointing downward, but never pointing
upward. Installing it with the open end pointing upward
can result in water and debris collecting in the quick-
disconnect fitting.
The dust covers (plastic plugs supplied with your grill)
help keep the open ends of the quick-disconnect fitting
clean while disconnected.
Hose Requirements
The grill is equipped with a model specific hose that
was attached during the manufacturing process. This
specific hose must be used for proper performance.
If the hose becomes worn or damaged, contact the
Customer Service Representative in your area using
the contact information on our website.
Pressure Testing the Gas Supply
Disconnect the gas grill when the gas supply is being
tested at high pressures. This appliance and its
individual shuto valve must be disconnected from the
gas supply piping system during any pressure testing
of that system at test pressures in excess of 1/2 psig
(3.5 kPa).
Turn o the gas grill when the gas supply is being
tested at low pressures. This appliance must be
isolated from the gas supply piping system by closing
its individual manual shuto valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2psig (3.5 kPa).
m DANGER: Do not line the slide-out grease tray or
cookbox with aluminum foil.
m DANGER: Check the slide-out grease tray and
catch pan for grease build-up before each use.
Remove excess grease to avoid a grease fire.
m WARNING: Use caution when removing catch pan
and disposing of hot grease.
m WARNING: Use heat-resistant barbecue mitts or
gloves when operating grill.
m WARNING: Grill brushes should be checked for
loose bristles and excessive wear on a regular
basis. Replace brush if any loose bristles are
found on cooking grates or brush. WEBER
recommends purchasing a new stainless steel
bristle grill brush at the beginning of every spring.
m WARNING: Keep ventilation openings around tank
clear and free of debris.
m WARNING: Keep any electrical supply cord and the
fuel supply cord away from heated surfaces.
Typical NG Grill Pipe Installation
INSIDE HOUSE
Gas supply
Shuto
OUTSIDE HOUSE
3/8" Quick-
disconnect
3/8" pipe nipple
Reducing coupling
1/2" pipe nipple
Locking shuto
Local codes may require
dierent installations.
Flare fittings should
never be used.
C
D
A
Hose Connection
Connect the Hose to the GasSupply
A quick-disconnect fitting connects your grill to the gas
supply. Gas will not flow unless the quick-disconnect is
properly engaged.
1) Check that all burner control knobs are in the o
position. Check by pushing in and turning knobs
clockwise (A).
2) Starting from inside the cabinet, route the flexible gas
hose out of the opening in the rear panel (B).
3) Slide the collar of the quick-disconnect back (C).
4) Push male fitting of the hose into the quick-disconnect
and maintain pressure. Slide the collar closed (D). If it
does not engage or lock, repeat procedure. Proceed to
”CHECKING FOR GAS LEAKS”.
B
4
Getting Started
D
C
LeakChecking
What is a Leak Check?
Once the hose is properly connected, it is necessary to
perform a leak check. A leak check is a reliable way to
verify that gas is not escaping after you connect the hose
to the gas supply. The fuel system in your grill features
factory-made connections that have been thoroughly
checked for gas leaks and the burners have been flame-
tested.
WEBER recommends performing a thorough leak check
after assembly, as well as annually. The following fittings
should be tested:
Where the gas hose connects to the gas supply.
Where the gas hose connects to the bulkhead.
Where the bulkhead connects to the corrugated gas
line.
Checking for Gas Leaks
1) Wet fittings (A) with a soap and water solution, using a
spray bottle, brush or rag. You can make your own soap
and water solution by mixing 20% liquid soap with 80%
water; or, you can purchase leak check solution in the
plumbing section of any hardware store.
2) Turn the gas supply valve on.
3) If bubbles appear there is a leak:
a) If the leak is at the gas supply (B). Turn o the gas.
DO NOT OPERATE THE GRILL.
b) If the leak is at any fittings indicated in
illustration (C), re-tighten fitting with a wrench and
recheck for leaks with soap and water solution. If
leak persists, turn o the gas. DONOT OPERATE THE
GRILL.
c) If the leak is at any fittings indicated in
illustration (D), turn o the gas. DO NOT OPERATE
THE GRILL.
If a leak is present, contact the Customer Service
Representative in your area using the contact
information on our website.
4) If bubbles do not appear, leak checking is complete.
Turn gas supply valve o and rinse connections
withwater.
NOTE: Since some leak test solutions, including soap and
water, may be slightly corrosive, all connections should be
rinsed with water after checking for leaks.
Disconnect the Hose from the GasSupply
1) Slide the collar back and pull out the plug.
Thisautomatically shuts o the gas.
m DANGER: Do not use a flame to check for gas
leaks. Besure there are no sparks or open flames
in the area while you check for leaks.
m DANGER: Leaking gas may cause a fire or
explosion.
m DANGER: Do not operate the grill if there is a gas
leak present.
A
B
A
Inspect the Hose
Routine inspection of the hose is necessary.
1) Confirm that the grill is o and cool.
2) Check hose for any signs of cracking, abrasions, or
cuts(A). If the hose is found to be damaged in any
way, do not use the grill.
m WARNING: If the hose is found to be damaged in
any way, do not use the grill. Replace using only
WEBER authorized replacement hose.
5
Using the sear zone
This feature is only available on select models.
Searing is a direct grilling technique used on meats, such
as steak, poultry parts, fish and chops. Searing browns
the surface of the food at a high temperature. By searing
both sides of the meat, you caramelize the food surface,
creating a more desirable flavor.
Ignition of the sear burner is the same as ignition of a
main burner, each burner ignites independently.
1) Open the lid and ignite all of the burners, including
the sear burner. Refer to IGNITING THE GRILL.
2) Preheat the grill with the lid closed and with all
burners on the start/high
position for 15 minutes.
3) After preheating, leave the sear burner control
knob and the adjacent burner control knobs in the
start/high
position (E). The sear burner works in
tandem with adjacent burners (F). The remaining
burner(s) can be turned to o or low.
4) Place meat directly over the sear zone
and close lid.
Sear each side anywhere from one to four minutes
(G), depending on the type and thickness of meat.
Once searing is complete, the meat can be moved
to moderate heat over and cooked to your desired
doneness.
Note: Always cook with the lid closed to achieve maximum
heat and to avoid flare-ups.
As you gain experience using the sear zone we
encourage you to experiment with dierent searing times
to find the results that work best for your taste.
To Extinguish Burners
1) Push each burner control knob in and then turn
clockwise all the way to the o position.
2) Turn gas supply o.
Operation
F
E
G
m WARNING: Open lid during ignition.
m WARNING: Do not lean over open grill while
igniting or cooking.
m WARNING: Each burner must be ignited
individually by pushing the electronic ignition
button.
m WARNING: If ignition does not occur within four
seconds of attempting to light the first burner,
turn the burner control knob to the o position.
Wait five minutes to allow accumulated gas to
dissipate, and then repeat the lighting procedure.
A
C
D
Igniting the Grill
Using the Electronic Ignition System to Ignite the
Grill
Each control knob operates an individual burner, and each
burner ignites independently. Ignite the burners starting
from left to right. All burners should be lit for preheating,
however, all burners do not have to be lit while grilling.
1) Open the grill lid (A).
2) Check that all burner control knobs are in the o
position. Check by pushing in and turning knobs
clockwise.
3) Turn the gas supply valve on (B).
4) Begin with the burner furthest to the left. Push the
burner control knob in and turn it counterclockwise to
the start/high
position (C).
5) Push and hold the electronic ignition button (D). Youwill
hear it ticking.
6) Check that the burner is lit by looking through the
cooking grates and through the half-circle cutout in the
FLAVORIZER BARS.
7) If the burner does not ignite, turn burner control knob
to the o
position and wait five minutes to allow the
gas to clear before attempting to light the burner again.
8) If the burner ignites, repeat steps 4 through 6 to light
the remaining burners.
Should the burners fail to ignite using the electronic
ignition, refer to the TROUBLESHOOTING section.
Thereyou will find instructions on igniting the grill with a
match to help determine the exact problem.
Preheat the Grill
Preheating the grill is critical to successful grilling.
Preheating helps to prevent food from sticking to the grate
and gets the grate hot enough to sear properly. Italso
burns o residue of a previously cooked meal.
1) Open the grill lid.
2) Ignite your grill according to the ignition instructions in
this Owner's Manual.
3) Close lid.
4) Preheat the grill with all burners on the start/high
position for 15 minutes(C).
To Extinguish Burners
1) Push each burner control knob in and then turn
clockwise all the way to the o position.
2) Turn gas supply valve o.
B
6
m WARNING: Open side burner lid during ignition.
m WARNING: Do not lean over side burner while
igniting or cooking.
m WARNING: If ignition does not occur within four
seconds of attempting to light the side burner,
turn the burner control knob to the o position.
Wait five minutes to allow accumulated gas to
dissipate, and then repeat the lighting procedure.
B
Operation
D
Cleaning and Maintenance
Cleaning the Inside of the Grill
Over time, the performance of your grill can diminish if
it has not been maintained properly. Low temperatures,
uneven heat, and food sticking to cooking grates are all
signs that cleaning and maintenance are overdue. When
your grill is o and cool, start by cleaning the inside, from
the top down. A thorough cleaning is recommended at
least twice a year. Consistent use may require quarterly
cleanings.
Cleaning the Lid
From time to time you may notice “paint-like” flakes on
the inside of the lid. During use, grease and smoke vapors
slowly change into carbon and deposit on the inside of
your lid. These deposits will eventually peel, and looks
very similar to paint. These deposits are non-toxic, but the
flakes could fall onto your food if you do not clean the lid
regularly.
1) Brush the carbonized grease from the inside of the lid
with a stainless steel bristle grill brush (A). To minimize
further build-up, the inside of the lid can be wiped with
a paper towel after grilling while the grill is still warm
(nothot).
Cleaning the Cooking Grates
Cleaned grates will prevent your next meal from sticking. If
you are cleaning your cooking grates regularly, the debris
on your grates will be minimal.
1) With grates installed, brush the debris o your cooking
grate with a stainless steel bristle grill brush (B).
2) Take the grates out and set aside.
Cleaning the FLAVORIZERBARS
FLAVORIZER BARS catch drippings that smoke and sizzle,
adding flavor to your food. Any drippings that are not
vaporized by the FLAVORIZER BARS are funneled away
from the burners. This helps prevent flare-ups inside of
your grill, and protects the burners from getting clogged.
1) Scrape the FLAVORIZER BARS with a plastic scraper
(C).
2) If necessary, brush the FLAVORIZER BARS with a
stainless steel bristle grill brush.
3) Remove FLAVORIZER BARS and set aside.
Cleaning the Burners
Two areas on the burners that are key to optimum
performance are the ports (small raised openings running
along the length of the burners) and the spider/insect
screens on the ends of the burner. Keeping these areas
clean is essential for safe operation.
Cleaning the Burner Ports
1) Use a clean stainless steel bristle grill brush to clean
the outside of the burners by brushing across the top of
the burner ports (D).
2) When cleaning the burners, avoid damaging the ignition
electrode by carefully brushing around it.
Cleaning the Spider Screens
1) Locate the ends of the burners on the underside of the
control panel where they meet the valves.
2) Clean the spider/insect screens on each of the burners
using a soft bristle brush (E).
Cleaning the Heat Deflectors
Located under the burners, the heat deflectors distribute
heat evenly throughout the cookbox while cooking.
Keeping heat deflectors clean will enhance the cooking
performance of your grill.
1) Scrape the heat deflectors with a plastic scraper.
2) If necessary, brush the heat deflectors with a stainless
steel bristle grill brush.
3) Remove heat deflectors and set aside.
Igniting the Side Burner
Using the Electronic Ignition to
Ignite the Side Burner
This feature is only available on select models.
If one or more of the main burners on your grill are already
lit and you would like to ignite the side burner, skip to step
3. If none of the main burners are lit and you are only using
the side burner, start with step 1.
1) Check that the side burner control knob is in the
o
position. Check by pushing in and turning knob
clockwise (A). Also check that all main burner control
knobs are in the o position.
2) Turn the gas supply valve on.
3) Open the side burner lid (B).
4) Push in and turn side burner control knob
counterclockwise to start/high
position (C).
5) Push and hold in the electronic ignition button (D). You
will hear the igniter clicking. Check that the side burner
is lit. The side burner flame may be dicult to see on a
bright sunny day.
6) Once side burner is ignited, continue turning the knob
counterclockwise until you reach the desired position.
7) If the side burner does not ignite within 4 seconds, turn
side burner control knob to the o
position and wait
five minutes to allow the gas to clear before attempting
to light the burner again.
Should the side burner fail to ignite using the electronic
ignition, refer to the TROUBLESHOOTING section.
Thereyou will find instructions on igniting the side burner
with a match to help determine the exact problem.
To Extinguish Side Burner
1) Push side burner control knob in and then turn
clockwise all the way to the o position.
2) Turn gas supply o.
7
Product Care
Cleaning the Cookbox
Look inside the cookbox for any grease accumulation or
leftover food particles. Excessive accumulation can cause
a fire.
1) Use a plastic scraper to scrape debris o the sides and
bottom of the grill into the opening in bottom of the
cookbox. This opening leads debris into the slide-out
grease tray.
Cleaning the Grease ManagementSystem
The grease management system consists of an angled
slide-out grease tray and a catch pan. These components
were designed to be easily removed, cleaned, and
replaced; an essential step every time you prepare to grill.
Cleaning the Outside of theGrill
The outside of your grill may include stainless steel,
porcelain-enameled, and plastic surfaces. WEBER
recommends the following methods based on the
surfacetype.
Cleaning Stainless Steel Surfaces
Clean stainless steel using a non-toxic, non-abrasive
stainless steel cleaner or polish designed for use on
outdoor products and grills. Use a microfiber cloth to clean
in the direction of the grain of the stainless steel. Donot
use paper towels.
Note: Do not risk scratching your stainless steel with abrasive
pastes. Pastes do not clean or polish. They will change the
color of the metal by removing the top chromium oxide film
coating.
Cleaning Painted, Porcelain-Enameled Surfaces and
PlasticComponents
Clean painted, porcelain-enameled and plastic
components with warm soapy water, and paper towels
or cloth. After wiping down the surfaces, rinse and dry
thoroughly.
Cleaning the Outside of Grills that are in Unique
Environments
If your grill is subject to a particularly harsh environment,
you will want to clean the outside more often. Acid rain,
pool chemicals, and salt water can cause surface rusting
to appear. Wipe down the outside of your grill with warm
soapy water. Follow up with a rinse and thorough drying.
Additionally, you may want to apply a stainless steel
cleaner weekly to prevent surface rust.
m WARNING: Turn your grill o and wait for it to cool
before thoroughly cleaning.
m WARNING: Over time, the development of rough
surfaces can form on the FLAVORIZER BARS.
Wearing gloves is recommended when handling.
Do not clean FLAVORIZER BARS or cooking grates
in a sink, dishwasher, or self-cleaning oven.
m WARNING: When cleaning the burners, never use
a brush that has already been used to clean the
cooking grates. Never put sharp objects into the
burner port holes.
m CAUTION: Do not place any grill components onto
the side tables as they may scratch the paint or
stainless steel surfaces.
m CAUTION: Do not use any of the following to clean
your grill: abrasive stainless steel polishes or
paints, cleaners that contain acid, mineral spirits
or xylene, oven cleaner, abrasive cleansers
(kitchen cleansers), or abrasive cleaning pads.
Spider Screens
The combustion air openings of the burners(D) are
fitted with stainless steel screens to prevent spiders
and other insects from spinning webs and building
nests inside the burners. Additionally, dust and
debris can accumulate on the outside of the spider/
insect screen and obstruct the oxygen flow to the
burners.
D
REPLACEMENT PARTS
To obtain replacement parts,
contact the local retailer
in your area or log onto weber.com.
A
B
C
D
E
8
GENESIS FEATURES
A Prep & Serve Table
Use the side tables to keep platters, seasonings, and tools
within arm’s reach. Hang your essential grilling tools
on the hooks for easy access and organization of your
backyard workspace.
B Built-In Thermometer
Being aware of the temperature inside of your grill allows
you to adjust the heat when needed.
C WEBER CRAFTED Outdoor Kitchen Collection
Cooking Grates and Frame
Your grill is Outdoor Kitchen Collection Ready with the
included cooking grates and frame. Additional Outdoor
Kitchen Collection accessories sold seperately.
D Top Cooking Grate
Keeps food warm, or toasts buns, while the main course
finishes grilling on the grate. Use it when you need a
secondary cooking surface.
E NIGHTVISION LED Lighting
NIGHTVISION lighting illuminates entire grilling surface
when lid is lifted.
F Side Burner
Use the side burner to simmer BBQ sauce or sauté veggies
while the main course grills under the lid.
G Sear zone
The sear zone is designed to create an intense heat zone to
quickly add sear marks to your meat.
H Grill Cabinet
The grill cabinet adds enclosed storage space for all of
your essential grilling tools and accessories.
I WEBER CRAFTED Grill Locker
Convenient side storage makes it easy to access and
remove cooking accessories.
The grills illustrated in this Owner’s Manual may vary
slightly from the model purchased.
Complete List of Features
The features listed below are only available on select models.
HIGH
PERFORMANCE
GRILLING
4 Grease Management System
Drippings that are not vaporized by the FLAVORIZER
BARS are funneled away from the burners into the
disposable drip tray, located within the removable catch
pan under the cookbox. Simply remove the catch pan and
replace the drip tray as needed.
The high performance grilling system sets the standard
in the world of gas grilling, and lands Weber in a class of
its own. This powerful grilling system is based on over
65 years of grilling experience, culinary expertise, and
most importantly, the wants and needs of the people who
matter most – our grilling community. Each component
was uniquely designed for ease-of-use and to provide
an unequaled satisfaction to your backyard grilling
experience.
1 INFINITY Ignition
The Infinity Ignition is guaranteed to ignite.
Rest assured that you’ll be up-and-grilling
the first time, every time.
2 PUREBLU Burners
The unique, tapered shape delivers a consistent gas
flow from front to back. This provides ultimate heat
distribution, ensuring that food grills evenly and
consistently anywhere on the cooking grates.
3 FLAVORIZER BARS
Stainless Steel FLAVORIZER BARS are angled just right
to catch drippings that smoke and sizzle, adding that
irresistible smoky flavor that we all know and love to
your food.
2
3
4
OFF
LOW
MEDIUM
START/
HIGH
Features
B
D
E
G
H
C
I
A
F
9
Features
Discover What's
Possible
WEBER CRAFTED Outdoor Kitchen Collection Ready
This feature is only available on select models.
Some models are Outdoor Kitchen Collection Ready with the included Grates and Frame.
Remove the right-hand cooking grate. Place the Frame on the right-hand side of the cookbox
for the widest range of heat control (A).
The Spacer included with your grill is used only when cooking with the WEBER CRAFTED
Outdoor Kitchen Collection (B).
Look for these and other accessories on weber.com.
B
Extra on the Side
WEBER CRAFTED Grill Locker
This feature is only available on select models.
The side storage area (A) is ideal for storing accessories
and grillware.
Adjustable condiment basket keeps smaller items close
at hand.
Always make sure the rubber mat is in place to protect
surfaces.
Storage Hooks
This feature is only available on select models.
Use the double-sided hooks on the side of the cabinet (B)
for convenient storage of cooking grates on the outside
of the grill. Additional hooks on the inside of the cabinet
store the WEBER CRAFTED spacer grate, which can be
used with WEBER CRAFTED Outdoor Kitchen Collection
grillware..
Note: Do not place hot cooking grates on storage hooks.
B
A
10
Preheat each and every time.
If the cooking grates aren’t hot enough, food will stick, and you will likely never have a
chance of searing properly or developing those handsome grill marks. Even if a recipe
calls for medium or low heat, always preheat the grill on the highest setting first. Open
the lid, turn up the heat, close the lid, and then let the cooking grate heat up for 15
minutes on high.
Don't grill on dirty grates.
Tossing food onto the cooking grates before they have been cleaned is never a good idea.
Leftover “stu” on the grates acts like glue, binding it to the grates and your new food. To
avoid tasting last night’s dinner on today’s lunch, make sure you are grilling on a clean
cooking grate. Once the grates are preheated, use a stainless steel bristle grill brush to
make a clean, smooth surface.
Be present in the process.
Before firing up your grill, make sure that everything you need is within arm’s reach.
Don’t forget your essential grilling tools, already oiled and seasoned food, glazes or
sauces, and clean cooking platters for cooked food. Having to run back to your kitchen
not only means missing out on the fun, but could also result in burning your food. French
chefs call this “mise en place” (meaning, “put in place”). We call it “being present”.
Create a little elbow room.
Packing too much food onto the cooking grates restricts your flexibility. Leave at least
one-quarter of the cooking grates clear, with plenty of space between each food item,
in order to get your tongs in there and easily move the food around. Sometimes grilling
involves split-second decisions and the ability to jockey food from one area to another.
Sogive yourself enough room to operate.
Try not to peek.
The lid on your grill is for more than just keeping the rain out. Most importantly, it’s for
preventing too much air from getting in, and too much heat and smoke from getting out.
When the lid is closed, the cooking grates are hotter, the grilling times are faster, the
smoky tastes are stronger, and the flare-ups are fewer. So put a lid on it!
Only flip once.
What’s better than a juicy steak with a deep sear and plenty of beautifully caramelized
bits? The key to accomplishing these results is to keep your food in place. Sometimes we
have the tendency to flip our food before it reaches the desirable level of color and flavor.
In nearly all cases, you should turn food just once. If fiddling with it more than that, you
are probably also opening the lid too much, which causes its own set of problems. So
step back and trust the grill.
Know when to tame the flame.
When grilling, sometimes the most important thing to know is when to stop. The most
reliable way to test doneness of your food is to invest in an instant-read thermometer.
This slim little gem will help you pinpoint that critical moment when your food is at its
best.
Don’t be afraid to experiment.
Back in the 1950s, grilling meant one thing: meat (and only meat) charred over open
flames. The modern day backyard chef doesn’t need a kitchen in order to prepare a full
course meal. Use your grill to make char-grilled appetizers, sides, and even desserts.
Register your grill to receive special content that will inspire you along the way. We’d love
to join you on your grilling adventures.
Features
GrillingDos andDonts
INDIRECT HEAT
SETUP
Use the indirect method for larger cuts of meat that require 20 minutes or more
of grilling time, or for foods so delicate that direct exposure to the heat would
dry them out or scorch them, such as: roasts, bone-in poultry pieces, whole fish,
delicate fish fillets, whole chickens, turkeys, and ribs. Indirect heat can also be
used for finishing thicker foods or bone-in cuts that have been seared or browned
first over direct heat.
With indirect heat, the heat is on both sides of the grill, or o to one side of the grill.
The food sits over the unlit part on the cooking gra
te.
The Flame -
Direct or Indirect
DIRECT HEAT
SETUP
Use the direct method for small, tender pieces of food that take less than 20
minutes to cook, suchas: hamburgers, steaks, chops, kabobs, boneless chicken
pieces, fish fillets, shellfish, and slicedvegetables.
With direct heat, the fire is right below the food. It sears the surfaces of the food,
developing flavors, texture, and delicious caramelization while cooking the food all
the way to thecenter.
HIGH
MEDIUM
OFF
11
Features
More Cooking
Space
This feature is only available on select models.
Using the Top Cooking Grate
Use it as a warming rack to keep food warm or
when you need a secondary cooking surface (A).
For storage, lift the entire grate from the cookbox
(B). Hang the grate vertically on the back edge of the
cookbox. Use heat-resistant mitts or gloves when
adjusting rack.
A
B
Grilling
atNight
This feature is only available on select models.
Using the NIGHTVISION Lighting
To activate the NIGHTVISION lighting, press the awake
button. The grill light has a tilt sensor that will turn
on the light if the grill lid is opened and turn o the
light when the grill lid is closed. If the lid is left open
or closed for more than 30 minutes, the grill light will
automatically deactivate. To turn the light back on, press
the awakebutton.
Replacing Batteries for the NIGHTVISION
Lighting
Use alkaline batteries only. Do not mix old and new
batteries or dierent types of batteries (standard,
alkaline, or rechargeable). If you do not plan to use
the grill for a month or more, remove the batteries.
1) Close the lid. Locate the battery housing on the
side of the lid handle and unscrew the cap (A). Do
not change batteries with the lid open.
2) Remove the battery sleeve.
3) Replace three size C batteries (B).
4) Line up graphic indicators (C) on the sleeve and
handle as you reinstall the sleeve. Tighten cap.
NOTE: Periodically wipe the lenses with a damp cloth to
keep the lights illuminating brightly.
A
C
12
CALL CUSTOMER
SERVICE
If you are still experiencing any
problems, contact the CustomerService
Representative in your area using the
contact information on weber.com.
Troubleshooting
MAIN BURNER(S) or SIDE BURNER WILL NOT IGNITE
SYMPTOM
Main burners or side burner do(es) not ignite when following the electronic ignition instructions in the “Operation” section of this owner's
manual.
CAUSE SOLUTION
There is a problem with gas flow. If any burner does not ignite, the first step is to determine if there is gas flowing to the burner(s). Tocheck this, follow
the instructions below for “Lighting Your Grill with a Match.”
If match lighting IS NOT successful, check if the fuel hose is bent or kinked or if the burner ports are dirty.
There is a problem with the electronic ignition system. If any burner does not ignite, the first step is to determine if there is gas flowing to the burner(s). Tocheck this, follow the
instructions below for “Lighting Your Grill with a Match.”
If match lighting IS successful, check the condition of the battery and check the wire connections of the Electronic
IgnitionSystem.
Lighting Your Grill with a Match
Using a Match to Determine if there is Gas Flow to
the Main Burners
1) Open the grill lid.
2) Check that all burner control knobs (including side
burner control knob) are in the o
position. Check by
pushing in and turning knobs clockwise.
3) Turn the gas supply valve on.
4) Begin with the burner furthest to the left. Put match
in the matchstick holder and strike match. (Matchstick
holder is located under left side table.) Insert lit match
down through the cooking grates, past the FLAVORIZER
bars and next to the burner(A).
5) Pushthe burner control knob in and slowly turn it
counterclockwise toward the start/high
position.
6) Check that the burner is lit by looking through
the cooking grates and through the cutout in the
FLAVORIZER bar.
7) If the burner does not ignite within 4 seconds, turn
burner control knob to the o
position and wait five
minutes to allow the gas to clear before attempting to
light the burner again.
8) If the burner ignites, the problem lies in the ignition
system. Check the condition of the battery and check
the wire connections of the Electronic Ignition System.
9) Replace the matchstick holder by hanging underneath
left side table (B).
Using a Match to Determine if there is Gas Flow to
the Side Burner
This feature is only available on select models.
1) Open the side burner lid.
2) Check that the side burner control knob is in the
o
position. Check by pushing in and turning knob
clockwise. Also check that all main burner control
knobs are in the o position.
3) Turn the gas supply valve on.
4) Put match in the matchstick holder and strike match.
(Matchstick holder is located under left side table.) Hold
lit match by the side burner(C).
5) Pushthe side burner control knob in and slowly turn it
counterclockwise toward the start/high
position.
6) Check that the side burner is lit. The side burner flame
may be dicult to see on a bright sunny day.
7) If the side burner does not ignite within 4 seconds, turn
side burner control knob to the o
position and wait
five minutes to allow the gas to clear before attempting
to light the burner again.
8) If the burner ignites, the problem lies in the ignition
system. Check the condition of the battery and check
the wire connections of the Electronic Ignition System.
A
B
C
13
Troubleshooting
GREASY GRILL (Resembles Peeling Paint & Flare-Ups)
SYMPTOM
• Inside of lid appears to have what resembles peelingpaint.
CAUSE SOLUTION
The flakes you see are accumulated cooking vapors that
have turned into carbon, and NOT paint.
This happens over time after repeated use of your grill.
This is not a defect. Clean the lid. Refer to the “Product
Care” section.
SYMPTOM
• Experiencing flare-ups when grilling or preheating.
CAUSE SOLUTION
There is leftover food from the previous meal. Always preheat the grill on the highest setting for 10 to 15
minutes.
The inside of the grill needs to be cleaned thoroughly. Follow the steps in the "Cleaning and Maintenance" section
to clean the grill inside from the top down.
Proper Burner Flame Pattern
The burners in your grill were factory set for the
correct air and gas mixture. When the burners are
performing correctly, you will see a specific flame
pattern. The tips may occasionally flicker yellow
(A), with a descending light blue (B) to dark blue
flame (C).
A
B
C
m WARNING: Do not attempt to make any repair to
gas carrying, gas burning, ignition components
or structural components without contacting
Weber-Stephen Products LLC, Customer Service
Department.
m CAUTION: The burner tube openings must be
positioned properly over the valve orifices.
GAS FLOW
SYMPTOM
• Grill does not reach desired temperature or heatsunevenly.
• One or more of the burners fail to ignite.
• Flame is low when burner is on high position.
• Flames do not run the whole length of the burner.
• Burner flame pattern is erratic.
CAUSE SOLUTION
Fuel hose is bent or kinked. Straighten fuel hose.
Burner ports are dirty. Clean burner ports. Refer to “Cleaning the BurnerPorts.”
SYMPTOM
• Gas is smelled in conjunction with burner flames that appear yellow andlazy.
CAUSE SOLUTION
Spider screens on the burners are obstructed. Clean spider screens. Refer to “Cleaning the Spider
Screens” in the Product Care section. Also refer to the
illustrations and information in this section about proper
flame pattern and spiderscreens.
14
Troubleshooting
Checking the Components of the Electronic Ignition
System
When pressing the ignition button you should hear a
ticking sound. If you cannot hear the ticking sound, check
the battery, then check the wires.
Checking the Battery
There are three potential issues with the battery that
supplies the power to your ignition module that need to be
checked:
1) Some batteries have a plastic protective wrap around
them. (Do not confuse this plastic with the battery
label.) Check that this plastic wrap is removed.
2) Confirm that the battery is installed correctly (C).
3) If the battery is old, replace it with a new battery.
Checking the Wires
There are two potential trouble spots that need to be
checked:
1) Check that the ignition wires are connected securely to
the terminals on the ignition button under the control
panel.
2) Make sure the ignition wires are properly attached
to the ignition module. The wire terminals are color
coded to correspond with the terminals on the ignition
module. The number of wires will vary per model.
Checking the Ground Wire
Models 315, 425s and 435 have a ground wire connected
to the manifold bracket. This is visible from beneath the
control panel (D):
1) Check that the ground wire is properly secured with a
screw.
335 Igniter Module Wire Chart
D
1 2 34 5
5
3
1
4
2
C
325s/330 Igniter Module Wire Chart
315 Igniter Module Wire Chart
1 2 3
3
1
2
1 2 34
3
1
2
4
415 Igniter Module Wire Chart
3
1
4
2
1 3 42
15
Replacement Parts
GENESIS S-315
7
11
12
13
14
15
16
17
18
23
25
24
19
27
8
9
1
5
4
2
3
6
26
10
20
22
21
GENESIS - S-315 NG - US 073023
32
35
36
37
33
34
28
29
30
31
39
40
41
42
44
43
38
16
Replacement Parts
GENESIS S-415
GENESIS - S-415 NG - US 073023
7
12
11
13
14
22
21
24
23
15
17
16
18
26
8
9
1
2
3
4
6
5
32
33
34
35
36
37
39
38
40
41
42
43
44
27
25
28
29
10
19
20
30
31
17
GENESIS E-325
Replacement Parts
7
11
12
13
14
15
16
17
18
23
25
24
19
28
8
9
1
5
4
2
3
6
26
27
10
20
22
21
GENESIS - E-325 NG - US 073023
33
36
37
38
34
35
29
30
31
32
40
41
42
45
44
43
39
18
GENESIS SA-E-325
Replacement Parts
7
11
12
13
14
15
16
17
18
23
25
24
19
28
8
9
1
5
4
2
3
6
26
27
10
20
22
21
GENESIS - SA-E-325 NG - US 073023
33
36
37
38
34
35
29
30
31
32
40
41
42
43
45
44
39
19
GENESIS SP-S-325
Replacement Parts
7
11
12
13
14
15
16
17
18
23
25
24
19
28
8
9
1
5
4
2
3
6
26
27
10
20
22
21
GENESIS - SP-S-325 NG - US 073023
33
36
37
38
34
35
29
30
31
32
40
41
42
43
45
44
39
20
GENESIS E-330
Replacement Parts
7
11
16
12
13
14
15
17
18
19
20
21
22
27
29
28
23
32
8
9
1
5
4
2
3
6
30
31
10
24
26
25
GENESIS - E-330 NG - US 073023
38
41
42
43
39
40
33
34
36
35
37
4
46
47
48
50
49
44
21
Replacement Parts
GENESIS SA-E-330
7
11
16
12
13
14
15
17
18
19
20
21
22
27
29
28
23
32
8
9
1
5
4
2
3
6
30
31
10
24
26
25
GENESIS - E-330 NG - US 073023
39
42
43
44
40
41
33
34
37
35
38
46
47
48
49
51
50
45
36
22
GENESIS E-335
Replacement Parts
GENESIS - E-335 NG - US 073023
7
16
11
12
13
14
15
17
18
19
20
22
23
21
24
25
26
27
28
30
31
29
36
38
37
32
41
8
9
1
2
3
5
4
6
39
40
10
33
35
34
47
50
51
52
48
49
42
43
44
45
46
54
55
56
59
58
57
53
23
Replacement Parts
GENESIS S-335
GENESIS - S-335 NG - US 073023
7
16
11
12
13
14
15
17
18
19
20
22
23
21
24
25
26
27
28
30
31
29
36
38
37
32
41
8
9
1
2
3
5
4
6
39
40
10
33
35
34
47
50
51
52
48
49
42
43
44
45
46
54
55
56
59
58
57
53
24
GENESIS E-335C
Replacement Parts
GENESIS - E-335C NG - US 073023
7
16
11
12
13
14
15
17
18
19
20
21
22
23
24
26
27
25
32
34
33
28
37
8
9
1
2
3
5
4
6
35
36
10
29
31
30
42
45
46
47
43
44
38
39
40
41
49
50
51
54
53
52
48
25
Replacement Parts
GENESIS S-335C
GENESIS - E-335C NG - US 073023
7
16
11
12
13
14
15
17
18
19
20
21
22
23
24
26
27
25
32
34
33
28
37
8
9
1
2
3
5
4
6
35
36
10
29
31
30
42
45
46
47
43
44
38
39
40
41
49
50
51
54
53
52
48
26
GENESIS SP-E-335
Replacement Parts
GENESIS - SP-E-335 NG - US 073023
8
17
12
13
14
15
16
18
19
20
21
23
24
22
25
26
27
28
29
31
32
30
37
39
38
33
42
9
10
1
2
3
5
4
6
7
40
41
11
34
36
35
48
51
52
53
49
50
43
44
45
46
47
55
56
57
60
59
58
54
27
Replacement Parts
GENESIS SP-S-335
GENESIS - SP-S-335 NG - US 073023
8
17
12
13
14
15
16
18
19
20
21
23
24
22
25
26
27
28
29
31
32
30
37
39
38
33
42
9
10
1
2
3
5
4
6
7
40
41
11
34
36
35
48
51
52
53
49
50
43
44
45
46
47
55
56
57
60
59
58
54
28
U.S.:
1-800-446-1071
Mexico:
01 800 0093237
Canada:
1-800-446-1071
Model: GEN1
PROBLEMS? QUESTIONS? Do Not Return Product to the Store. We Can Help.
If you have questions about the assembly, use, or maintenance of your grill or need replacement parts, please contact Weber
Customer Service. The serial number and model number can be
found on the cover of your owner’s manual and will be necessary for all service calls.
© 2024 Designed and engineered by Weber-Stephen Products LLC, 1415 S. Roselle Road, Palatine, Illinois 60067 USA.


Produkt Specifikationer

Mærke: Weber
Kategori: barbecue
Model: Genesis S-335
Type: Grill
Justerbar termostat: Ja
Bredde: 1570 mm
Dybde: 690 mm
Højde: 1230 mm
Vægt: 77990 g
Produktfarve: Sort, sølv
Kontroltype: Dreje
Indbygget skærm: Ingen
Formfaktor: Kurv
Husmateriale: Rustfrit stål
Termometer: Ja
Overfladetype: Rist
Nem at rengøre: Ja
Styrehjul: Ja
Varmekilde: Flydende petroliumsgas (LPG)
Antal hjul: 4 hjul
Antal hylder: 2 hylder
Total effekt: 11400 W
Låg: Ja
Lågfunktioner: Hængslet låg
Madlavningsoverflade form: Rektangulær
Bedste anvendelsesmuligheder: Udendørs
Svitse station: Ja
Madlavningsoverflade materiale: Rustfrit stål
Brænder - materiale: Støbejern
Side brændere kraft: 3500 W
Hovedbrænder effekt: 11400 W
Nem at flytte: Ja
Kroge inkluderet: Ja

Har du brug for hjælp?

Hvis du har brug for hjælp til Weber Genesis S-335 stil et spørgsmål nedenfor, og andre brugere vil svare dig
