Side 1/8

Whirlpool is a registered trademark of Whirlpool USA

EN -1-

Chart

(see at right for options

description)

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the

program. When the door is opened during a

washing cycle, the cycle is temporarily paused: the

Start indicator blinks.

To resume the cycle push the Start button and

close the door within 3 seconds.

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute.

If pressed when the dishwasher is switched off it

drains any possible liquids from dishwasher

(1 minute process).

If the indicator flashes repeatedly, see page 6 -

chapter ”What to do if...”.

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without any options) and may vary

depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic calibration

system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/

Standard loading comparison test and other tests, contact using following address: “contact@whirlpool.com”.

*Power consumption in: Left-on mode: 0.70 W / Off mode: 0.40 W.

Table of programs

Deter-

gent

Consumption

Drying

Phase

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Pre-Wash cold

Delay Crockery to be washed later. — 4.0 0.01 14-16 NO

Fragile 40°C

Delay

Light soiling, for example glasses

and cups.

X 10.5 0.85 105-114 Light

Rapid 45°C

Delay

Lightly soiled crockery, with no

dried-on food.

X 11.0 0.85 30-50 NO

Eco

50°C

Delay,

1/2 Load

Normally soiled crockery.

Standard program, the most

efficient in terms of its combined

energy and water consumption.

X 12.0 1.02 170 Full

Intensive 65°C

Delay

Recommended program for heavily

soiled crockery, especially suitable

for pans and saucepans.

X 15.0 1.60 165-175 Full

5019 300 02437

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS

QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

Options and display description

SALT INDICATOR

When lit (at the end of the

cycle), the salt reservoir

needs to be refilled.

RINSE AID INDICATOR

When lit (at the end of the

cycle), the rinse aid

dispenser needs to be

refilled.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY

BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES

AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

1/2 LOAD BUTTON

Half load cycle can be used

for the upper or lower rack.

Select the required program

then press the “Half Load”

button - the light comes on.

Turns off at the end of the

program.

The “Half Load” option can

be used with the programs

indicated in the table of

programs.

DELAYED START

BUTTON

The wash cycle can be

programmed to start

after 2, 4 or 8 hours.

Then press the Start

button. The wash

program will start after

the set time.

TABLET SETTING

This setting allows to optimize the cycle performances

according the type of detergent used.

Push the Tablet button for 3 seconds (until the indicator

lights up) if you are using the combined detergents in

tablet (rinse aid, salt and detergent in 1 dose).

If you are using powder detergent or liquid detergent,

the Tablet indicator on the control panel has to be off.

Quick reference guide

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADG 100
Bredde:	597 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	41000 g
Strøm:	13 A
Ledningslængde:	1.5 m
Pakkevægt:	42200 g
Pakkedybde:	660 mm
Pakkebredde:	640 mm
Pakkehøjde:	840 mm
Energieffektivitetsklasse (gammel):	A+
Årligt energiforbrug:	291 kWh
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fuldt indbygget
Installationsrum dybde:	560 mm
Støjniveau:	48 dB
Tilløbsslange, længde:	1.5 m
Antal vaskeprogrammer:	5
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Ikke anvendelig
Vaskeklasse:	A
Vandforbrug pr. cyklus:	12 L
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	12 kuverter
Forsinket start (maks.):	8 t
Tørringsklasse:	A
Årligt vandforbrug:	3360 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	1.02 kWh
Udøsslange længde:	2 m
Saltindikator:	Ja
