Whirlpool ADP 5310 WH Manual

Whirlpool Opvaskemaskine ADP 5310 WH

Læs gratis den danske manual til Whirlpool ADP 5310 WH (8 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Whirlpool ADP 5310 WH, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

-1-

Chart

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the

program. When the door is opened during a

washing cycle, the cycle is temporarely paused: the

Start indicator blinking. To restart the cycle close

the door and push Start button again.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute.

If pressed when the dishwasher is switched off it

drains any possible liquids from dishwasher (1

minute process).

If the indicator flashes repeatedly, see page 6 -

chapter ”What to do if ...”.

(see at right for options description)

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions

(without additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible

with sensor programs as a result of the appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for

detailed information on the EN/Standard loading comparison test and other tests, contact the following address:

“nk_customer@whirlpool.com”.

Table of programs

Deter-

gent

Consumption

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Pre-Wash cold

Delay Crockery to be washed later. — 5.0 0.02 10

Glasses 40°C

Delay

Light soiling, for example glasses

and cups.

X 13.0 0.90 97

Quickwash 40°C

Delay

Lightly soiled crockery, with no

dried-on food.

X 13.0 0.70 30

Eco

50°C

Delay

Half load

Normally soiled crockery. X 15.0 1.05 150

Intensive 70°C

Delay

Recommended program for

heavily soiled crockery, especially

suitable for pans and saucepans.

X 15.0 1.50 140

5019 396 01837/B

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ

THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING

ANY BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES

AUTOMATICALLY AFTER 30 SECONDS IF ANY CYCLE IS STARTED.

SALT INDICATOR

When lit (at the end of the

cycle), the salt reservoir

needs to be refilled.

HALF LOAD BUTTON

Half load cycle can be used

for the upper or lower rack.

Select the required program

then press the “Half Load”

button - the light comes on.

Turns off at the end of the

program. The “Half Load”

option can be used with the

programs indicated in the

table of programs.

TABLET SETTING

This setting allows to optimize the cycle performances

according the type of detergent used.

Push the Tablet button for 3 seconds (until the indicator

lights up) if you are using the combined detergents in

tablet (rinse aid, salt and deteregent in 1 dose).

If you are using powder detergent or liquid detergent,

the Tablet indicator on the control panel has to be off.

DELAYED START

BUTTON

The wash cycle can be

programmed to start

after 2, 4 or 8 hours.

Then press the Start

button. The wash

program will start after

the set time.

RINSE AID INDICATOR

When lit (at the end of the

cycle), the rinse aid

dispenser needs to be

refilled.

ADP 5310

Options and display description

Quick reference guide

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADP 5310 WH
Vekselstrømsindgangsspænding:	220 - 230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	597 mm
Dybde:	596 mm
Højde:	850 mm
Vægt:	58000 g
Ledningslængde:	1.5 m
Pakkevægt:	60000 g
Energieffektivitetsklasse (gammel):	A
Årligt energiforbrug:	231 kWh
Placering af apparat:	Fritstående
Tilsluttet belastning:	2200 W
Støjniveau:	51 dB
Antal vaskeprogrammer:	5
Forsinket start-timer:	Ja
Understøttede scanningstilstande:	1170 mm
Dør farve:	Hvid
Vaskeklasse:	A
Vandforbrug pr. cyklus:	15 L
Bestik rum type:	Kurv
Antal kuverter:	12 kuverter
Cyklustid:	150 min.
Forsinket start (maks.):	8 t
Opvaskeprogrammer:	Intensive, Pre-wash, Quick
Tørringsklasse:	A
Årligt vandforbrug:	3300 L
Energiforbrug pr. cyklus:	1.05 kWh
AquaSensor funktion:	Ja
Vandpåfyldning:	Kold
Selvrensende filter:	Ja
Tørresystem:	Statisk
