How
It Works
Wilson Electronics 4G Omni Antenna will collect the cell tower signal and send it through
the cable to a Signal Booster.
And
it
works
in
the
other direction, when the cell phone
transmits, the signal is transferred to a Signal Booster and transmitted back to the cell
tower.
Thank you for purchasing a Wilson Electronics Antenna
Please read all instructions before installing your antenna, and check the parts supplied
against those listed in this guide.
The
Wilson Electronics weatherproof antenna is
omni-
directional and ideal for many exterior building locations, such as homes, offices, stores
and warehouses.
Our
innovative design results in high
efficiency
and
low
signal loss, which means more
signal to your cell phone
or
cellular
data card.
This
wide-band
,
high-performance
,
Omni Antenna
supports
multiple frequencies (Specifications are
on
the
back
page).
It is backed by Wilson
Electronics
30-day
money-back
guarantee and 2-
year
limited
warranty
.
Package Contents
for
304424
1 -
4G
Omni Antenna
1 - L-Bracket
1 - U-bolt Assembly
Optional Antenna Kits
Kit 304421-1120
• 75 Ohm 4G Omni Antenna
• 20'
RG
11
cable
Kit 304421 -17410
• 75 Ohm 4G Omni Antenna
• 10' RG174 cable
• May need separate adapter
Kit 304421 -
061
0
• 75 Ohm 4G Omni Antenna
• 1 0' RG6 cable
Kit 304421-581 0
• 75 Ohm 4G Omni Antenna
• 1 0' RG6 cable
• May need separate adapter
Determine Your Mounting Location
Package Contents for 304421
1 - 4G Omni Antenna
1 - L-Bracket
2 -
U-bolt
Assembly
Kit 304424-40020
• 50 Ohm 4G Omni Antenna
• 20' Wilson400 cable
Kit 304424-5810
• 50 Ohm 4G Omni Antenna
• 1 0' RG58 cable
• May need separate adapter
Kit 304424-1120
• 50 Ohm 4G Omni Antenna
• 20'
RG11
cable
• May need separate adapter
The antenna should be mounted high on
the
building with no obstructions. There is a
compromise between installing the antenna as high as possible and keeping the cable
un
short
to reduce signal loss (the
longer
your
cable, the greater
the
signal loss will be).
ilson Electronics offers various cable lengths and connectors (sold separately).
sure your mounting location is
as
far
away
as possible from other antennas and
objects such as flagpoles. Be careful
not
to kink
or
crush the antenna cable
or
tightly during installation. This can lead to
poor
performance and signal loss. It
nt to mount the antenna vertically; mounting horizontally
or
at
an angle will
degrade performanc
e.
Wilson Electronics Technical Support
Tea
m with a
ny
questions at 866-294-1660
visit: https://www.weboost.com/us/support-center/ or email:
support@weboost.com
