The M-6 Extension Post allows you to extend the height of
your flash bracket to reduce red-eye or “steel eye” reflections in
people or animal subjects.
Wimberley, Inc.  Phone:  1-434-529-8385
1750 Broadway St  Toll Free:  1-888-665-2746 (USA & Canada)
Charlottesville, VA
22902  USA  www.tripodhead.com       info@tripodhead.com
About the M-6
Wimberley, Inc.  Phone:  1-434-529-8385
1750 Broadway St  Toll Free:  1-888-665-2746 (USA & Canada)
Charlottesville, VA
22902  USA  www.tripodhead.com       info@tripodhead.com
5 Year Warranty – See www.tripodhead.com/warranty.cfm for complete details
Package Contents:

•  M-6 Module: Extension Post (Qty 1)
Weight:  2.8 oz
Dimensions (Overall L x W x H):  6.0 x 0.95 x 1.6 in
Materials:  Anodized 6061 Aluminum, stainless steel fasteners
The M-6 gives you up to 5” of flash extension. You can combine
up to three extension posts to achieve the desired height.


Pairs fit together for compact storage.
Instructions continued on back>>
Connecting Flash Bracket Modules:

(The figure below shows the connection between M-3 and upright module; the same principle applies for other module connections.)
knob
cylindrical nub
Unscrew the knob so that
the upright module can fit
between the cylindrical
nub and the knob base
Forked end of
module
Slip the forked end of the
module over the exposed
threads. Locate one of the
enlarged areas in the forked
end over the cylindrical nub.
Tighten the knob
securely.
Tip: if you find the metal knobs difficult
to grip, try wrapping several layers of
self-fusing rubber grip tape (3M 2155)
around the knob to cushion it and make it
easier to grip in the field.
Feel free to contact us
if you have any questions.
M-6
Extension Post
Flash Bracket Module
M-3
M-6
M-1
M-2
F-1

Telephoto Bracket with M-6 Extension
